CLAAS RU 600 Contour RU 600 Xtra RU 450 Xtra Double skids Fitting Instructions Manual_DE_EN_FR

Description

CLAAS RU 600 Contour RU 600 Xtra RU 450 Xtra Double skids Fitting Instructions Manual_DE_EN_FR

DESCRIPTION:

CLAAS RU 600 Contour RU 600 Xtra RU 450 Xtra Double skids Fitting Instructions Manual_DE_EN_FR

INTRODUCTION

This manual describes the safe and time-saving method of attachment with the mounting kits part no. 498 315.0 (down maize tips RU 600) and part no. 498 318.0 (down maize tips RU 450). Please read this manual thoroughly before starting work! Pay particular attention to the »General instructions « section. The following machines and devices can be converted

CLAAS maize headers:
RU 600 Contour
RU 600 Xtra
RU 450 Xtra

The shipping packages are listed in page 4.2. Before starting work make sure that the mounting kit is complete. The “Shipping package” list is also considered a supplement to the spare parts list. Dispose of old parts that are not required for the assembly in an environmentally correct manner
TABLE OF CONTENTS:

CLAAS RU 600 Contour RU 600 Xtra RU 450 Xtra Double skids Fitting Instructions Manual_DE_EN_FR

1 Introduction
Introduction 11
2 Table of contents
3 General instructions
Of special importance 31
Identification of warnings and dangers 31
Designated use 32
Safety decals with warning symbols 32
General safety instructions 32
4 Shipping package
Shipping package for double skids mounting kit for
RU 600 Contour / XTRA and RU 450 Xtra 42
Mounting kits: 498 3150 (RU 600) and
498 3180 (RU 450) 42
5 Assembly of down maize tips
Removal of divider points 51
Iinstallation of new supports 52
Installation of divider points 53
Installation of skids 55
Check and observe the following before
putting into operation 56
