DESCRIPTION:

CLAAS RU 600 Contour Typ 661 RU 600 Contour Typ 903 Infeed Improvement Fitting instructions Manual_DE_EN_FR_IT

INTRODUCTION
These instructions describe the safe and time-efficient working procedure for fitting the mounting kit Spare Part No. 0498 742.0. Please read this manual thoroughly before starting work! Pay particular attention to the »General instructions « section. The following machines can be modified: CLAAS maize header: RU 600 Contour / RU 600 XTRA Typ 661 RU 600Contour / RU 600 XTRA Typ 9031 The shipping package is shown on page 4.1. Before starting work make sure that the mounting kit is complete. The “Shipping package” list is also considered a supplement to the spare parts list. Retain the old parts for later use!
TABLE OF CONTENTS:

CLAAS RU 600 Contour Typ 661 RU 600 Contour Typ 903 Infeed Improvement Fitting instructions Manual_DE_EN_FR_IT

1 Introduction
Introduction 11
2 Table of contents
3 General instructions
Of special importance 31
Identification of warnings and dangers 31
Designated use 32
Safety decals with warning symbols 32
General safety instructions 32
4 Shipping package
Fitting kit infeed improvement 0497 2660 41
5 Fitting the infeed improvement
Dismantling covers 51
Removing the tension springs 52
Mounting the tension springs 52
Increasing the hole 52
RU 600 Type 661 up to machine number 661 0 1804 52
RU 600 Type 661 from machine number 661 0 1805
and RU 600 Type 903 52
Fitting the tension springs 53
Fitting the cones 54
Fitting the carriers 55
Fitting the rails to the infeed auger 55
Check and observe the following before putting into operation 57
