Claas Swathers Volto 740H 740HR 640H 640HR 64 Assembly Instruction Manual FR_DE_EN_IT

Description

Claas Swathers Volto 740H 740HR 640H 640HR 64 Assembly Instruction Manual FR_DE_EN_IT – PDF DOWNLOAD

DESCRIPTION:

Claas Swathers Volto 740H 740HR 640H 640HR 64 Assembly Instruction Manual FR_DE_EN_IT – PDF DOWNLOAD

INTRODUCTION :

This manual describes the safe and time-saving work procedure for assembly of the machine. Please read this manual thoroughly before starting work! Pay particular attention to the section »General Information« and the information on dangers in the operator’s manual.
The following machines can be assembled:
Rotary tedder:
VOLTO 740 H / 740 HR – Type 369
VOLTO 64 / 640 H / 640 HR – Type 368

TABLE OF CONTENTS:

Claas Swathers Volto 740H 740HR 640H 640HR 64 Assembly Instruction Manual FR_DE_EN_IT – PDF DOWNLOAD

1 Introduction
Introduction 11
2 Contents
3 General Information
Of special importance 31
Identification of warnings and dangers 31
Designated use 32
Safety decals with warning symbols 32
General safety instructions 32
4 Assembly instructions
General instructions for assembly 41
Assembly 41
Note the following during assembly! 42
Tine bar 42
Wheel brackets 42
Spreading angle adjustment 43
Before operation 44
5 Work sequence
VOLTO 740 H / 740 HR 53
VOLTO 64 / 640 H / 640 HR 57
