DESCRIPTION:

CLAAS TARGO K-SERIE Conversion instructions Manual_DE_FR_GB_ – PDF DOWNLOAD

INTRODUCTION

These instructions describe the safe and timesaving work sequence for conversion of the reduced speed fan. The teleporter TARGO K SERIES can be retrofitted with the conversion kit parts no. 349 332.0, from the following machine number range: 51200020 to 51200471. The standard mounting time is approx. 4 man hours. See page 4.1 for the shipping package. Observe the »Safety Rules« in the applicable operator’s manual

General information

IMPORTANT

• The instructions contained in this manual should be carefully read and observed by all persons who are concerned with the operation, maintenance and inspection of this machine/ front attachment in order to prevent accidents. Especially the »Safety Rules« in the operator’s manual should be read with the utmost care and adhered to.
• In addition, please also observe the accident prevention regulations that apply for your own country. Before commencing with the job, ensure that all the tools and service aids are available. Compare existing machine type/front attachment type with the list in the chapter »Shipping Package« and the parts kit supplied.
• The specification of the components, e.g. bolts, is shown on the shipping package. The shipping package shows the position number (pos. no.) of the components. Parts such as nuts and contact washers do not have a position number but belong to the bolt listed above which does have a position number. Additional part specifications are the part no., description, measurements, DIN and the quantity.
• In order to help with the assembly, existing components in the instructions are identified with letters, whereas new parts have been identified with a number (position number). Texts and pictures apply, in general, to all machine types covered by this book and the information given applies equally, except where reference is made to a particular model in captions to the pictures or in the main text. Technical data, dimensions and weights are given as an indication only.
• CLAAS reserve the right to make changes subsequently as technical developments continue. Responsibility for errors or omissions not accepted. Front, rear, right and left refer to the direction of forward travel.

TABLE OF CONTENTS:

CLAAS TARGO K-SERIE Conversion instructions Manual_DE_FR_GB_ – PDF DOWNLOAD

1 Introduction
Introduction 1 1
2 Contents
Contents 2 1
3 General
information
Important 3 1
Identification of warnings and danger signs 3 2
Correct use 3 2
4 Shipping Package
Shipping Package 4 1
Conversion kit 349 332 0 4 1
5 Conversion
Conversing the reduced speed fan 5 1
Preparing the installation 5 1
Removing the fan 5 1
Creating vacuum in the hydraulic oil tank 5 3
Disassembling the fan 5 4
Assembling the fan 5 5
Exchanging the hydraulic pump 5 6
Installing the fan 5 7
Preparing and performing the test run 5 9
