SCORPION 9040
SCORPION 7045
SCORPION 7040
SCORPION 7035
SCORPION 7030
Anbauanleitung
Anbau Bolzen Schnellwechselplatte
Fitting Instructions
Installing the quickhitch pin
Notice de montage
montage d’un axe sur l’attache rapide

Safety precautions
Work may be carried out only by specialist
workshops authorised by CLAAS and having
qualified personnel.
Observe the general safety, accident prevention and
environmental regulations.
Read and observe the Safety chapter in the
Operator’s manual.
Carry out work under the jacked-up/raised machine/
front attachment or under raised components only if
a safe support is provided.
Lower hydraulically actuated components down to
the ground before working on the hydraulic system.
Relieve the system pressure.
Carry out work on the machine only with the drive
disengaged and the engine stopped! Remove the
ignition key.
Relieve the pressure of pre-loaded accumulators
(springs, pressure accumulators, hydraulic cylinders)
or components loaded/pressurised by accumulators
properly prior to installation work.
After installation check if all bolts are tightly
seated.Carry out a function test.

TABLE OF CONTENTS:

CLAAS Telehandler SCORPION 9040 7045 7040 7035 7030 Installing the quickhitch pin Fitting Instructions Manual_DE_EN_FR – PDF DOWNLOAD

Montageanleitung Anbau Bolzen Schnellwechselplatte10
Beschreibung10
Qualifikation10
Benötigte Werkzeuge10
Vorbereitung Montage10
Demontage: Schnellwechselplatte11
Inbetriebnahme13
Assembly instructions: Installing the quickhitch pin14
Description14
Qualification14
Necessary tools14
Preparatory work14
Removing the quickhitch15
Putting into operation17
Instructions d’assemblage : montage d’un axe sur l’attache rapide18
Description18
Qualification18
Outils nécessaires18
Travaux préparatoires18
Dépose de l’attache rapide19
Mise en marche21
