CLAAS Tractor Arion 430-410 TECHINCAL System MANUAL – PDF DOWNLOAD

Description

CLAAS Tractor Arion 430-410 TECHINCAL System MANUAL – PDF DOWNLOAD

FILE DETAILS:

CLAAS Tractor Arion 430-410 TECHINCAL System MANUAL – PDF DOWNLOAD

Language : English
Pages :340
Downloadable : Yes
File Type : PDF
Size:68.5 MB

TABLE OF CONTENTS:

CLAAS Tractor Arion 430-410 TECHINCAL System MANUAL – PDF DOWNLOAD

MAIN SHIMMING OF THE GEARBOX 9
TIGHTENING TORQUES AND SEALING COMPOUNDS OF THE GEARBOX 10
DISMANTLING PROCEDURE 15
TIGHTENING TORQUES AND SEALING COMPOUNDS OF THE REAR AXLE 17
MAIN SHIMMING OF THE REAR AXLE 19
TIGHTENING TORQUES AND SEALING COMPOUNDS OF THE “HD” SHAFT TUBE 21
MAIN SHIMMINGS OF THE “HD” SHAFT TUBE 21
TRANSMISSION KINEMATICS 22
OSCILLATION DAMPER
FITTING THE DAMPER HUB 24
“REVERSHIFT” HYDRAULIC REVERSER
TOOLING MANUFACTURED LOCALLY 26
REMOVING THE “REVERSHIFT” MODULE 30
REMOVING THE “REVERSHIFT” MODULE 32
REMOVING THE REVERSE CLUTCH 33
REMOVING THE FORWARD CLUTCH 34
REFITTING THE “REVERSHIFT” MODULE 35
REFITTING THE REVERSE CLUTCH 36
REFITTING THE “REVERSHIFT” MODULE 38
MECHANICAL REDUCER
TOOLING MANUFACTURED LOCALLY 42
ROBOT-DRIVEN RANGES 44
EXPLODED VIEW 44
REMOVING THE RANGES MODULE 46
REMOVING THE RANGES MODULE 46
REMOVING THE PRIMARY LINE 49
REFITTING THE PRIMARY LINE 50
REMOVING THE SECONDARY LINE 52
REFITTING THE SECONDARY LINE 52
ADJUSTING THE SHAFTS IN THE HOUSING 54
MEASURING SHAFT CLEARANCE IN THE HOUSING 55
REFITTING THE RANGES MODULE 56
EXTRA SLOW RANGE 62
REMOVING/REFITTING THE HOUSING 63
CONTROL LEVER 65
ADJUSTING THE CONTROL LEVER 66
02 34
“QUADRISHIFT” REDUCER UNDER LOAD
TOOLING MANUFACTURED LOCALLY 68
HOLDER OF THE (B)/(A) CLUTCH/BRAKE MODULE OF THE “QUADRISHIFT” 68
LOCATION CLUTCHES 69
“QUADRISHIFT” 70
REMOVAL OF “QUADRISHIFT” 72
REMOVING THE CLUTCH/BRAKE (D)/(C) 74
REFITTING THE CLUTCH/BRAKE (D)/(C) 76
REMOVING THE CLUTCH/BRAKE (B)/(A) 78
REFITTING THE CLUTCH/BRAKE (B)/(A) 80
REST OF “QUADRISHIFT” 82
CASING OF THE REAR AXLE AND FINAL REDUCERS
“HD” AXLE TUBE 84
REMOVING THE AXLE TUBE 85
REFITTING THE AXLE TUBE 86
Arion 430-410 – 022010 – GB
REMOVING THE PLANET CARRIER 87
REFITTING THE PLANET CARRIER 87
REMOVING THE ROLLER BEARINGS AND SEALS 88
REFITTING THE ROLLER BEARINGS AND SEALS 89
SHIMMING THE WHEEL SHAFT BEARINGS 90
REPLACING THE WHEEL STUD 91
DIFFERENTIAL AND BEVEL GEAR
EXPLODED VIEW OF BEVEL GEAR 94
EXPLODED VIEW OF DIFFERENTIAL 94
TOOLS FOR REMOVING THE CRAWLER RANGE PIN AND SLEEVE 96
DISASSEMBLY AND REASSEMBLY OF THE DIFFERENTIAL LOCK 97
REMOVAL OF HOUSING AND CROWN WHEEL 99
REMOVING AND REFITTING THE DIFFERENTIAL CASE AND THE RING GEAR 100
REMOVING THE DRIVE PINION 102
ADJUSTING PINION PROTRUSION 103
ADJUSTING THE PRELOAD OF THE DRIVE PINION BEARINGS 105
ADJUSTING THE PRELOAD OF THE DIFFERENTIAL BEARING BLOCK BEARINGS 106
ADJUSTING THE BACKLASH 108
FINAL REASSEMBLY 109
ELECTRO-HYDRAULIC PTO
EXPLODED VIEW OF UNIT 114
CROSS SECTIONAL VIEW OF UNIT 115
TORQUE SETTINGS AND SEALANTS 116
TOOLING MANUFACTURED LOCALLY 117
REMOVING THE CLUTCH FROM THE POWER TAKE-OFF UNIT 118
REMOVING THE CLUTCH 119
REFITTING THE CLUTCH 120
REFITTING THE CLUTCH 122
FINAL STEPS 123
