CLASS JAGUAR 900 – 830 Central lubrication system Conversion Instructions Manual DE_EN_FR

Description

CLASS JAGUAR 900 – 830 Central lubrication system Conversion Instructions Manual DE_EN_FR – PDF DOWNLOAD

DESCRIPTION:

CLASS JAGUAR 900 – 830 Central lubrication system Conversion Instructions Manual DE_EN_FR – PDF DOWNLOAD

General information
IMPORTANT :

The instructions contained in this manual should be carefully read and observed by all persons who are concerned with the operation, maintenance and inspection of this machine, in order to prevent accidents. Especially the «SAFETY RULES» in this manual should be read with the utmost care and adhered to.

• The use of spare parts, accessories and ancillary equipment, which are not originally manufactured by CLAAS, can change the specified design characteristics of this CLAAS machine or can detract from its functional performance, with a possible adverse affect on the active and/ or passive operational safety of the machine and its occupational safety standards (accident prevention).
• CLAAS are in no way liable for any damage or personal injury caused through the use of other than original or approved CLAAS parts, accessories and ancillary equipment.

TABLE OF CONTENTS:

CLASS JAGUAR 900 – 830 Central lubrication system Conversion Instructions Manual DE_EN_FR – PDF DOWNLOAD

1 Introduction
2 Contents
Contents 21
3 General information
Important 31
4 Safety rules
Safety rules 41
Identification of warning and danger signs 41
Correct use of combine 41
General safety and accident prevention regulations 41
Leaving the machine 42
Service 42
Basic rule 42
5 Shipping Package
Shipping Package 51
Converting Kit 069 3320 51
6 Fitting instructions
Fitting the central lubrication system 61
Preparing the assembly
[Anbau vorbereiten — Übersetzung fehlt] 61
Mark the non-marked line 61
Grease machine 61
Components of the central greasing system 63
Discharge chute bank 64
Fitting the grease reservoir 65
Fitting the main bank 65
Pre-assemble the coupling 65
Fitting Accelerator bank 66
Fitting coupling (31) 68
Fitting the cutting cylinder housing bank 69
Pre-assemble the cutting cylinder housing bank 69
Fitting the feed roller housing bank (38) 611
Fitting the Corn cracker bank (41) 613
Installation without corn cracker 614
Check the grease reservoir (8) 614
Checking the automatic control of the
central lubrication system 614
Check the bearings, lines and the distribution banks 614
