Operation,

Load indicator|

• The load indicator can be found in the ab ofthe machine. Using an LED display, the load on the forks can be monitored. A green LED shows that the system is switched on.
• The 2’” LED (red) shows thatthe machine is 50% loaded. Each LED after that approx equates to 6.5% From 50% loading to 100%, there are a total of 9 LEDs (red).
• When 100% loading is achieved, then the LEDs flash and an additional buzzer is sounded. Should the top LED (red) illuminate, then the machine is loaded to 110%. For the indicator to work, there is a load cell that supplies the signal and is mounted on the rear axle.
• The resistance of the load cell changes when pressure or tension is applied to the rear axle. Using the “B” button, the load indicator needs to be checked on a daily basis. The load indicator is OK if when pressing the button, all the LEDs flash and the warning buzzer can be heard.

TABLE OF CONTENTS:

Class TARGO K50 K60 K70 Technical Tranning Manual – PDF DOWNLOAD

1.0 Technical data
2.0 Operation
3.0 Safety I load display
4.0 Engine
5.0 Gearbox
6.0 Drive shaft
7.0 Axle [steering
8.0 Brakes
9.0 Working hydraulics
10.0 Electrics
11.0 Diagnostics
12.0 Air conditioning [heating
13.0 Options
14.0 Frame, boom
15.0 Maintenance and care
