CNH CX75C SR Midi Excavator Double-Acting Circuit Proportional Control Kit Installation Instructions Manual 47683006 – PDF

Description

CNH CX75C SR Midi Excavator Double-Acting Circuit Proportional Control Kit Installation Instructions Manual 47683006 – PDF DOWNLOAD

FILE DETAILS:

CNH CX75C SR Midi Excavator Double-Acting Circuit Proportional Control Kit Installation Instructions Manual 47683006 – PDF DOWNLOAD

Language : English
Pages : 32
Downloadable : Yes
File Type : PDF
Size: 4.57 MB

IMAGES PREVIEW OF THE MANUAL:

TABLE OF CONTENTS:

CNH CX75C SR Midi Excavator Double-Acting Circuit Proportional Control Kit Installation Instructions Manual 47683006 – PDF DOWNLOAD

KG1AP093-00 – DOUBLE-ACTING CIRCUIT PROPORTIONAL CONTROL KIT
CASE CONSTRUCTION
CX75C SR

1 KIT CONTENT
Kit content . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
2 PRE-ASSEMBLY
PREPARING FOR ASSEMBLY
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
3 ASSEMBLY
DOUBLE – ACTING CIRCUIT PROPORTIONAL CONTROL KIT
Installation of base boom seating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Installation of transverse boom seating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Boom line installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Upper main line installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
Pilot line installation – Proportional control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
Harness installation – proportion control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-19
Attachment of plate inside cab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-22
