CNH CX75C SR Midi Excavator Multi-Purpose Circuit Proportional Control Kit Installation Instructions Manual

Description

CNH CX75C SR Midi Excavator Multi-Purpose Circuit Proportional Control Kit Installation Instructions Manual 47573393 – PDF DOWNLOAD

FILE DETAILS:

CNH CX75C SR Midi Excavator Multi-Purpose Circuit Proportional Control Kit Installation Instructions Manual 47573393 – PDF DOWNLOAD

Language : English
Pages : 44
Downloadable : Yes
File Type : PDF
Size: 7.42 MB

TABLE OF CONTENTS:

CNH CX75C SR Midi Excavator Multi-Purpose Circuit Proportional Control Kit Installation Instructions Manual 47573393 – PDF DOWNLOAD

KG1AP075-00 – MULTI-PURPOSE CIRCUIT PROPORTIONAL CONTROL KIT
CASE CONSTRUCTION
CX75C SR

1 KIT CONTENT
Kit content . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
2 PRE-ASSEMBLY
PREPARING FOR ASSEMBLY
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
3 ASSEMBLY
MULTI-PURPOSE CIRCUIT PROPORTIONAL CONTROL
Boom line installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Upper main line installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Pilot line installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
Harness installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-21
Control lever installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-26
Port relief valve installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-30
Tank indicator sensor installation (filter clog warning) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-31
Installation of nameplate inside cab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-32
