Crown Forklift GPC2000 SL Series Parts Manual 812722-006 PDF

Description

Crown Forklift GPC2000 SL Series Parts Manual 812722-006 – PDF DOWNLOAD

FILE DETAILS:

Crown Forklift GPC2000 SL Series Parts Manual 812722-006 – PDF DOWNLOAD

Language : English
Pages :122
Downloadable : Yes
File Type : PDF

TABLE OF CONTENTS:

Crown Forklift GPC2000 SL Series Parts Manual 812722-006 – PDF DOWNLOAD

GPC2000 SL 1
TABLE OF CONTENT 5
INTRODUCTION 9
Model-Number 10
COVERS 11
COVERS 1 – 2 12
COVERS 2 – 2 16
CASTOR WHEEL 18
LOAD WHEEL 20
HYDRAULIC 23
TUBE / HOSE LAYOUT 24
PUMP MOTOR & PUMP 28
DRIVE UNIT 31
DRIVE UNITE 32
GEARBOX 34
DRIVE MOTOR 38
KNUCKEL 40
ELECTRIC 45
CONTACTOR PANEL 46
STEERING CONTROLLER GPC2040S 48
DRIVER BOARD 50
CONTACTOR / TRACTION 52
CONTACTOR / PUMP 54
QUICK PIC GPC2040S 56
ACCELERATOR SWITCH GPC2040S 58
LIFT/LOWER AND HORN GPC2040S 60
CONTROL HANDLE 62
HANDLE 64
CONTROL HANDLE 66
FOOT BRAKE 68
PLATFORM 70
SWITCH 72
BATTERY CONNECTOR / EMERGENCY DISCONNECT 74
DASH BOARD 76
STEER INDICATOR GPC 2040S 78
BRAKE SYSTEM 81
BRAKE 82
STEERING 85
STEERING GPC2040S 86
STEERING MOTOR GPC2040S 88
STEERING GPC2040S 90
STEERING GPC2040S 92
STEERING COLUMN 94
MAST- / LIFT STRUTURE 97
LIFT STRUCTURE 98
GUARD RAIL100
YOKE102
CYLINDER105
LIFT CYLINDER106
FREE LIFT CYLINDER108
CABIN / PLATFORM111
PLATFORM112
PLATFORM114
PLATFORM116
MISCELLANEOUS SERVICE INF119
LABELS AND DECALS120
