Cuyuna 2si Service Repair Manual Ultralight Aircraft Engine
VIDEO PREVIEW OF THE MANUAL:
IMAGES PREVIEW OF THE MANUAL:
DESCRIPTION:
- This manual contains maintenance and troubleshooting information for the various Cuyuna engines. The manual is designated to aid service personnel in service – oriented application.
- The manual is divided into sections. Each section of the manual covers a specific area of the engine in addition to the standard service procedures. which include disassembly. inspection and assembly procedures.
- The service technician should famliarize himself with the different areas of the engine by first carefully studying the appropriate section of this manual. This manual will assist the service technician in becoming more aware of and efficient with service procedures.
- Such efficiency not only helps build consumer confidence, but also saves time and labor. When servicing the Cuyuna engine, the technician should use discretion as to how much disassembly is needed to correct any given condition.
TABLE OF CONTENTS:
Engine Disassembly
Recoil & Flywheel Nut Remove!
Flywheel Remove!
Fan Housing & Stator Plate Remove!
Fan& Bearing Remove!
Crankshaft—an Seal Remove!
Intake Manifold Remove!
Cylinder Head Remove!
Cylinder Removal
Piston&Wrist Pin Remove!
Crankcase Disassembly
Main Bearing Replacement
Cleaning and Inspection
Cylinder Heads {Cleaning & Inspection)
Cylinders(Cleaning& Inspection)
Piston (Cleaning & Inspection)
Crankcase(Cleaning& Inspection)
Cylinder [Cleaning & Inspection)
Measuring Cylinder Trueness
Piston Skirt/Cylinder Clearance
Piston-Ring End Gap
Measuring Piston-Pin& Pistow Pln Bora
Measuring Connecting-Rod Small End Bora
Measuring Crank shaft Run out
Crankcase Assembly
End See! Installation
Piston installation
Piston Ring Installation
Cylinder Installation
Intake Mani fold instalization
Cylinder Head Gasket
Cylinder Head
Fan Housing & impeiller Bearing Assembly
Flywheel installation
Adjust Axial Fan Belt Tension
‘Engine Overhaul Procedure Summary
Recoil Starter(Mitsui)
Recoil Starter (Eaton)
Two Cycle Engine Troubleshooting
