Daewoo Doosan Mega 200-V Mega 200-VTC Operation & Maintenance Manual – PDF DOWNLOAD

Description

Daewoo Doosan Mega 200-V Mega 200-VTC Operation & Maintenance Manual – PDF DOWNLOAD

DESCRIPTION:

Daewoo Doosan Mega 200-V Mega 200-VTC Operation & Maintenance Manual – PDF DOWNLOAD

WORK SITE PRECAUTIONS :

ATTACHMENT PRECAUTIONS :

• Options kits are available through your dealer. Contact Daewoo for information on available one-way (single-acting) and two-way (double-acting) piping / valving / auxiliary control kits.
• Because Daewoo cannot anticipate, identify or test all attachments that owners may wish to install on their machines, please contact Daewoo for authorization and approval of attachments, and their compatibility with options kits.
• AVOID HIGH-VOLTAGE CABLES Serious injury or death can result from contact or proximity to high-voltage electric lines. The bucket does not have to make physical contact with power lines for current to be transmitted. Use a spotter and hand signals to stay away from power lines not clearly visible to operator.

Below ground hazards also include natural gas lines, water mains, tunnels and buried foundations. Know what’s underneath work site before starting to dig.

BE AWARE OF HEIGHT OBSTACLES:

Any type of object in vicinity of boom could represent a potential hazard, or cause operator to react suddenly and cause an accident. Use a spotter or signal person working near bridges, phone lines, work site scaffolds, or other obstructions.

USE CARE ON LOOSE SUPPORT:

• Working heavy loads over loose, soft ground or uneven, broken terrain can cause dangerous side load conditions and possible tipover and injury. Travel without a load or balanced load may also be hazardous.
• If temperatures are changing, be cautious of dark and wet patches when working or traveling over frozen ground. Stay away from ditches, overhangs and all other weak support surfaces. Halt work and install support mats or blocking if work is required in an area of poor support.

USE SOLID SUPPORT BLOCKING:

• Never rely on lift jacks or other inadequate supports when work is being done. Block wheels fore and aft to   prevent any movement.

DIGGING BENEATH OVERHANGS:

• Digging beneath an overhang is dangerous. Overhand could collapse on top of operator and cause serious injury or death. Go onto another digging area before steep overhangs are formed. Know height and reach limits of wheel loader and plan ahead while working. Park wheel loader away from overhangs before work shut down.

TABLE OF CONTENTS:

Daewoo Doosan Mega 200-V Mega 200-VTC Operation & Maintenance Manual – PDF DOWNLOAD

Safety...........................................  7
	To the Operator of a Daewoo Wheel Loader.....  7
	General Safety Essentials....................  8
	Location of Safety Labels....................  9
	Unauthorized Modifications................... 16
	Work Site Precautions........................ 16
	Operation.................................... 18
	Equipment.................................... 23
	Maintenance.................................. 28
	Shipping and Transportation.................. 30
Operating Controls............................... 31
	Component Locations.......................... 32
	Control Identification....................... 38
	Steering Console and Pedals.................. 39
	Transmission Display......................... 46
	Front Instrument Panel....................... 48
	Right Side Switch Panel...................... 57
	Various Cabin Locations...................... 68
	Heater and Air Conditioner Operation......... 72
	Stereo....................................... 77
	Seat Adjustment.............................. 81
	Seat Belt.................................... 83
	Door Side Latch.............................. 84
	Fuse Box/Relay............................... 85
	Window Glass Breaking Tool................... 88
Operation........................................ 89
	Instrument Panel Control Functions........... 89
	New Machine Break-in Procedures.............. 89
	Engine Start and Stop........................ 90
	Machine Travel............................... 99
	Machine Shut Down............................101
	Additional Braking...........................103
	Boom Raise Kickout...........................104
	Bucket Angle Indicator.......................104
	Boom Lower Kickout (Option)..................105
	Adjustment of Bucket Position Switch.........106
	Towing Machine...............................107
	If Engine Stalls While Traveling.............108
	Allowable Water Depth........................108
Inspection, Maintenance and Adjustment...........109
	Table of Recommended Lubricants..............111
	Fluid Capacities.............................113
	Maintenance Intervals........................114
	10 Hour / Daily Service......................116
	50 Hour / Weekly Service.....................126
	250 Hour / Monthly Service...................135
	500 Hour / 3 Month Service...................142
	1,000 Hour / 6 Month Service.................145
	1,500 Hour / 9 Month Service.................151
	2,000 Hour / Yearly Service..................153
	12,000 Hour / Six Year Service...............156
	Severe Conditions Maintenance................157
	General Maintenance..........................158
	Parking Brake Adjustment.....................160
	Check Hydraulic Pressures....................161
	Tires and Wheels.............................165
	Electrical System............................167
	Bolt Torque Chart............................168
	Long Term Storage............................169
Transportation...................................171
	Loading Machine on a Trailer.................171
	Summary of Safety Precautions for Lifting....172
Troubleshooting..................................173
	Engine.......................................173
	Hydraulic System.............................176
	Travel System................................178
	Steering.....................................183
	Braking......................................184
	Electrical System............................184
Specifications...................................185
	Mega 200-V...................................185
	Mega 200-VTC.................................188
	Working Capacities...........................191
	Approximate Weight of Workload Materials.....191
Index............................................195
