DESCRIPTION:

Daewoo Doosan MT36 MT41 Operation and Maintenance Manual MX515431 – PDF DOWNLOAD

• Doosan reserves the right to improve its products continuously, delivering the best possible product to the marketplace. These improvements can be implemented at any time with no obligation to change materials previously sold.
• It is recommended that consumers periodically contact their distributors for most recent documentation on purchased equipment. This documentation may include attachments and optional equipment not available in your machine’s package.
• Please call your distributor for additional items that you may require. Illustrations used throughout this manual are used only as a representation of the actual piece of equipment, and may vary from the actual item.

Foreword0

• This manual provides rules and guidelines which will help you use this dump truck safely and effectively. This manual describes procedures for operating, handling, lubricating, maintenance, checking and adjustment. It will help the operator to achieve peak performance through effective, economical and safe dump truck operation and maintenance.
• • Keep this manual in the dump truck at all times and ensure that all personnel read it carefully before operating the dump truck. • Continue studying the manual until proper operating are completely adopted as personal habit. • This manual describes the basic techniques. The operator’s skill will increase with correct knowledge of dump truck operation.
• • Operation, inspection and maintenance should be carefully carried out, and safety must be given first priority. If this manual has been lost or has become dirty and cannot be read, request a replacement manual from your local Moxy Dealer. If you sell the dump truck, be sure to give this manual to the new owners. Moxy Engineering AS cannot be held responsible for damage or injury caused through use of improper spare parts not specified by Moxy Engineering AS, improper handling, operation and utilisation of the dump truck in other ways than those described in this manual.
• Nor can Moxy Engineering AS be held responsible for unauthorised modifications or the non-adherence to local, national government or international regulations. This Operating & Maintenance Manual may contain standard extra equipment and optional accessories that are not available in your area. Please consult your local Moxy Dealer for those items you may require.
• Moxy Engineering AS aim to continuously improve the dump trucks and therefore retain the right to make design changes and improvements whenever we feel it will improve the efficiency of the dump truck. Moxy Engineering AS also reserve the right to change data and equipment without prior notice, as well as amending instructions for maintenance and other service measure
• • This dump truck complies with EC directives 98/37/EC with amendments and 89/336/EC with amendments. Dump trucks complying with the directives display the CE mark. The dump truck must not be modified in such a way that it no longer complies with the EC – directive. • Improper operation and maintenance of this dump truck can be hazardous and could result in serious injury or death.
• • Operators and maintenance personnel should read this manual through before operation or maintenance. • Some actions involved in operation and maintenance of the dump truck can cause serious accidents, if they are not carried out in a manner described in this manual.
• • The procedures and precautions given in this manual apply only to intended uses of the dump truck. If you use your dump truck for any unintended uses that are not specifically prohibited, you must be sure that it is safe for you and others. In no event should you or others engage in the prohibited uses or actions which are described in this manual.
• • Moxy Engineering AS delivers dump trucks that comply with all applicable regulations and standards of the country to which it has been shipped. If this dump truck has been purchased in another country or purchased from someone in another country, it may lack certain safety devices and specifications that are necessary for use in your country.
• If there is any question about whether your product complies with the applicable standards and regualtions of your country, consult your local Moxy Dealer before operating the dump truck.

TABLE OF CONTENTS:

Daewoo Doosan MT36 MT41 Operation and Maintenance Manual MX515431 – PDF DOWNLOAD

1 Foreword 5 – 8
Foreword 5
Safety information 6
Introduction 7
2 Safety instructions 9 – 40
3 Operating controls 41 – 78
Overview of the instruments and controls 43
Instruments 44
Warning / indicator lights 49
Switches 55
Controls 61
Cab ventilation 69
Other cabin equipment 73
4 Running-in period 79 – 84
Running-in operation 81
Running-in services 82
5 Operating instructions 85 -120
Precautions on worksites 87
Some simple rules to be observed prior to operation 90
Starting the engine 91
Operating the dump truck 93
Parking the dump truck 105
Stopping the engine 105
Checks after stopping the engine 106
Loading and tipping 106
Tyre handling 108
Cold weather 110
Long term storage 111
Battery power assistance 112
Towing the dump truck 113
Manual release of parking brake 113
Manual release of the tip valve 114
Troubleshooting 115
6 Lubricants 121 – 128
Lubrication schedule 123
Oil specification sheet 125
Filling capacities 126
Transmission oil list 127
7 Maintenance 129 – 188
Maintenance precautions 131
Maintenance table 133
8 Hours / Daily service 135
40 Hours / Weekly service 147
500 Hours Service 149
1000 Hours Service 165
2000 Hours Service 179
4000 Hours Service 185
Yearly recommended maintenance 187
8 Technical data 189 – 202
Measurements 191
Engine 192
Transmission 192
Hydraulic system 193
Tyre pressures 193
Electrical system 194
Metering conversion table 195
Tool kit content 195
Performance chart 196
Engine and retarder brake chart 197
Torque limit tables 198
Reference information (fill in tables) 198
Consumeable parts 198
Product signs 199
Periodic service (fill in tables) 200
9 Alphabetical Index 203 – 208
