Daewoo Doosan DD 80L Operation and Maintenance Manual 5022-7103E-R1 – PDF DOWNLOAD

Description

Daewoo Doosan DD 80L Operation and Maintenance Manual 5022-7103E-R1 – PDF DOWNLOAD

DESCRIPTION:

Daewoo Doosan DD 80L Operation and Maintenance Manual 5022-7103E-R1 – PDF DOWNLOAD

• Daewoo reserves the right to improve our products in a continuing process to provide the best possible product to the market place. These improvements can be implemented at any time with no obligation to change materials on previously sold products.
• It is recommended that consumers periodically contact their distributors for recent documentation on purchased equipment. This documentation may include attachments and optional equipment that is not available in your machine’s package.
• Please call your distributor for additional items that you may require. Illustrations used throughout this manual are used only as a representation of the actual piece of equipment, and may vary from the actual item.

TO THE OPERATOR OF A DAEWOO DOZER

• Unsafe use of the dozer could lead to serious injury or death. Operating procedures, maintenance and equipment practices or traveling or shipping methods that do not follow the safety guidelines on the following pages could cause serious, potentially fatal injuries or extensive damage to the machine or nearby property
• Please respect the importance of taking responsibility for your own safety, and that of other people who may be affected by your actions.The safety information on the following pages is organized into the following sections:

1. “General Safety Essentials” on page 1-2
2. “Locations of Safety Labels” on page 1-3
3. “Unauthorized Modifications” on page 1-6
4. “Work-site Precautions” on page 1-6
5. “Operation” on page 1-8
6. “Equipment” on page 1-12
7. “Maintenance” on page 1-15
8. “Shipping and Transportation” on page 1-17

LEARN THE SIGNAL WORDS USED WITH THE SAFETY ALERT SYMBOL

The words “CAUTION”, “WARNING”, and “DANGER” used throughout this manual and on decals on the machine indicate degree of risk of hazards or unsafe practices. All three degrees of risk indicate that safety is involved. Observe precautions indicated whenever you see the Safety Alert “Triangle,” no matter which signal word appears next to the “Exclamation Point” symbol

TABLE OF CONTENTS:

Daewoo Dooson DD 80L Operation and Maintenance Manual 5022-7103E-R1 – PDF DOWNLOAD

Safety................................................  7
	To the Operator of a Daewoo Dozer.................  7
	General Safety Essentials.........................  8
	Locations of Safety Labels........................  9
	Unauthorized Modifications........................ 12
	Work-site Precautions............................. 12
	Operation......................................... 14
	Equipment......................................... 18
	Maintenance....................................... 21
	Shipping and Transportation....................... 23
Operating Controls.................................... 25
	Component Locations............................... 26
	Operator’s Area................................... 27
	Instrument Panel.................................. 31
	Stereo............................................ 40
	Calibration Switch................................ 44
	Limp Home Switches................................ 44
	Miscellaneous Electrical Devices.................. 47
	Fuel Transfer Pump (If Equipped).................. 48
	Seat Adjustment................................... 49
	Seat Belt......................................... 50
	Door Side Latch................................... 51
	Miscellaneous Access Covers and Doors............. 52
Operation............................................. 53
	To Handle a New Dozer............................. 53
	Starting and Stopping the Engine.................. 54
	Travel............................................ 63
	Operating Instructions............................ 67
	Operating Precautions............................. 69
	Parking Dozer..................................... 71
	Towing Procedure.................................. 72
Inspection, Maintenance and Adjustment................ 73
	Preliminary Work Machine Setup for Maintenance.... 74
	Table of Recommended Lubricants................... 75
	Maintenance Intervals............................. 77
	10 Hour / Daily Service........................... 79
	50 Hour / Weekly Service.......................... 85
	150 Hour Service.................................. 88
	250 Hour / Monthly Service........................ 89
	500 Hour / 3 Month Service........................ 96
	1000 Hour / 6 Month Service....................... 99
	1500 Hour Service.................................102
	2000 Hour / Yearly Service........................102
	4000 Hour / Biennial Service......................103
	Electrical System.................................104
	Blade.............................................107
	Calibration Procedure for Micro Controller........108
	Track Tension.....................................118
	Bolt and Nut Inspection...........................120
	Maintenance In Special Conditions.................121
	Long Term Storage.................................122
Transportation........................................123
	Loading and Unloading.............................123
	Lifting with Sling................................124
Troubleshooting.......................................125
	Engine............................................125
	Hydraulic System..................................126
	Electrical System.................................127
	Travel System.....................................128
Specification.........................................135
	General Specifications............................135
	Overall Dimensions................................138
Index.................................................139
