DAF Davie XD LF45 LF55 CF65 CF75 CF85 XF95 Diagnostics Manual – PDF DOWNLOAD
DESCRIPTION:
DAF Davie XD LF45 LF55 CF65 CF75 CF85 XF95 Diagnostics Manual – PDF DOWNLOAD
INTRODUCTION:
Customer parameters Customer parameters are the settings of an electronic system. The customer parameters permit adapting control functions of a system to the customer’s particular wishes andlor needs within certain limits. The customer parameters are stored in a list in the memory of the electronic unit Customer parameters can be modified using the programming feature of DAVIE XD. Programming using DAVIE X0 is only possible if the logged-in user has been registered as a “Master Technician’. Note: Erroneous settings of customer parameters may affect the action of control functions to such an extent that they function eratically or not at all.
- After modification of the wttings the (modified) customer parameters must be stored in the electronic unit using the programming function in the customer paranwter overview. Customer parameter names and codes Each customer parameter in a system has its own name and code. The following explanation of the customer parameters includes only the codes.
- The availabflity of a customer parameter in a system depends on the programmed software in the electronic unit. The programmed software depends on the vehicle configuration! identity card data. Standard values Standard values, options and setting ranges may vary according to the software variants of DAVIE XD and the system. This is why they have not been inciuded in the following explanation of the customer parameters.
