DAF Truck XF Driver’s Manual DW53208206 – PDF DOWNLOAD

Description

DAF Truck XF Driver’s Manual DW53208206 – PDF DOWNLOAD

FILE DETAILS:

DAF Truck XF Driver’s Manual DW53208206 – PDF DOWNLOAD

Language : English
Pages : 345
Downloadable : Yes
File Type : PDF

IMAGES PREVIEW OF THE MANUAL:

TABLE OF CONTENTS:

DAF Truck XF Driver’s Manual DW53208206 – PDF DOWNLOAD

Preface............................................................................  4
Why this handbook is so important!.................................................  5
Table of contents..................................................................  6
1 Warnings and safety regulations.................................................. 14
	1.1 Warning symbols............................................................ 15
	1.2 Before you start driving................................................... 16
	1.3 Warnings and safety regulations............................................ 16
	1.4 Airbag safety instructions................................................. 22
	1.5 AEBS/ACC sensor............................................................ 25
	1.6 Technical items of special importance...................................... 26
2 Alarm system..................................................................... 30
	2.1 The theft prevention system................................................ 31
	2.2 Using the ignition key or hand-held transmitter............................ 31
	2.3 Self-diagnosis............................................................. 32
	2.4 Use when staying in the cabin.............................................. 32
	2.5 Deactivating the superstructure or trailer cargo space detection........... 33
	2.6 The system LED............................................................. 34
	2.7 Loss of the ignition key................................................... 35
	2.8 System does not respond to the transmitter in the ignition key............. 35
	2.9 Battery for the transmitter in the ignition key............................ 36
	2.10 Maintenance............................................................... 36
	2.11 Disconnecting the vehicle batteries....................................... 36
	2.12 Insurance company......................................................... 36
3 Instruments and controls......................................................... 38
	3.1 Cabin...................................................................... 39
		3.1.1 Cabin................................................................ 39
		3.1.2 Entering and leaving the cabin....................................... 40
		3.1.3 Doors................................................................ 41
		3.1.4 Night lock........................................................... 42
		3.1.5 Steering lock/ignition/starter switch................................ 43
		3.1.6 Steering column adjustments.......................................... 44
		3.1.7 Mirrors.............................................................. 45
		3.1.8 Setting the mirrors.................................................. 45
		3.1.9 Electrical mirror and window control................................. 46
		3.1.10 Interior lighting................................................... 48
		3.1.11 Bunks............................................................... 50
		3.1.12 Bunk lamps.......................................................... 52
		3.1.13 Cool box............................................................ 53
		3.1.14 Ashtray............................................................. 54
		3.1.15 Accessory plug connectors and air connection........................ 55
		3.1.16 Window shade........................................................ 57
		3.1.17 Roof console lockers................................................ 58
		3.1.18 Roof hatch.......................................................... 58
		3.1.19 Stepwell lighting................................................... 60
		3.1.20 Windscreen wiper blades............................................. 60
		3.1.21 Tool/storage compartments........................................... 61
		3.1.22 Adjusting the roof spoiler.......................................... 61
	3.2 Seats and safety belts..................................................... 62
		3.2.1 Seats................................................................ 62
		3.2.2 Safety belts......................................................... 72
	3.3 Instruments and controls................................................... 74
		3.3.1 Instrument panel..................................................... 74
		3.3.2 Control panel........................................................ 80
		3.3.3 Centre console....................................................... 88
		3.3.4 Roof console......................................................... 91
		3.3.5 Bunk panel........................................................... 95
		3.3.6 Steering Wheel Switches.............................................. 96
		3.3.7 Left-hand steering column switch..................................... 97
		3.3.8 Right-hand steering column switch.................................... 98
		3.3.9 Installing and removing Bluetooth enabled telephones.................100
		3.3.10 Activating the truck phone..........................................102
		3.3.11 Operating the telephone using the steering wheel switches...........102
		3.3.12 Main switch.........................................................106
	3.4 Radio......................................................................107
		3.4.1 Basic radio..........................................................107
		3.4.2 Truck Navigation Radio (TNR).........................................108
	3.5 Cabin climate control......................................................111
		3.5.1 Heating ventilation and air conditioning system......................111
		3.5.2 Auxiliary heater (air heater)........................................118
		3.5.3 Auxiliary heater (water heater)......................................119
		3.5.4 Auxiliary heater (timer unit operation)..............................121
4 Master display...................................................................124
	4.1 General....................................................................125
	4.2 Master display.............................................................125
	4.3 Start-up phase.............................................................127
	4.4 Menu Control Switch (MCS)..................................................129
	4.5 Menu overview..............................................................130
	4.6 System warnings............................................................136
	4.7 Warning indicators on master display.......................................138
	4.8 Warning indicators on instrument panel.....................................145
	4.9 Overview of system abbreviations...........................................152
5 Inspections and maintenance......................................................158
	5.1 Checks.....................................................................159
		5.1.1 Overview of daily checks.............................................159
		5.1.2 Overview of weekly checks............................................159
		5.1.3 Opening the front panel..............................................160
		5.1.4 Coolant level........................................................160
		5.1.5 Engine oil level.....................................................161
		5.1.6 Windscreen washer fluid level........................................163
		5.1.7 Exterior lighting....................................................164
		5.1.8 Air filter indicator.................................................165
		5.1.9 Wheels and tyres.....................................................166
		5.1.10 Brake system air dryer..............................................166
		5.1.11 Batteries...........................................................166
	5.2 Maintenance................................................................168
		5.2.1 General maintenance..................................................168
		5.2.2 Cabin maintenance....................................................168
		5.2.3 Cleaning.............................................................168
		5.2.4 Bug screen...........................................................171
		5.2.5 Auxiliary heater.....................................................171
		5.2.6 Lubricating fifth wheel or trailer coupling..........................172
6 Coupling and uncoupling..........................................................174
	6.1 Opening and closing the fender.............................................175
	6.2 Fifth wheel................................................................175
	6.3 Trailer coupling...........................................................178
	6.4 Connecting the ABS or EBS connector of a trailer...........................181
7 Driving..........................................................................184
	7.1 Before a drive.............................................................185
	7.2 Refuelling diesel and refilling AdBlue.....................................185
	7.3 Starting procedure.........................................................189
	7.4 Stopping procedure.........................................................192
	7.5 Regenerating DPF, Emission Aftertreatment System...........................194
	7.6 Driver Performance Assistant (DPA).........................................202
	7.7 Fuel consumption display...................................................204
	7.8 Engine idle shutdown.......................................................208
	7.9 Engine Speed Control.......................................................209
	7.10 Cruise control............................................................210
	7.11 Variable speed limiter....................................................214
	7.12 Traction aid..............................................................215
	7.13 Differential lock.........................................................215
	7.14 Brakes....................................................................216
	7.15 Engine brake..............................................................219
	7.16 Retarder..................................................................223
8 Safety systems...................................................................226
	8.1 Adaptive Cruise Control (ACC)..............................................227
		8.1.1 Introduction.........................................................227
		8.1.2 Traffic situations...................................................228
		8.1.3 Engaging and disengaging Adaptive Cruise Control (ACC)...............230
		8.1.4 Distance setting to the vehicle ahead................................233
		8.1.5 ACC system warning...................................................235
	8.2 Forward Collision Warning (FCW)............................................235
		8.2.1 Forward Collision Warning (FCW)......................................235
	8.3 Advanced Emergency Braking (AEBS)..........................................236
		8.3.1 Introduction.........................................................236
		8.3.2 Engaging and disengaging Advanced Emergency Braking System (AEBS)....238
		8.3.3 Detection and intervention...........................................239
	8.4 Lane Departure Warning System (LDWS).......................................243
		8.4.1 LDWS (Lane Departure Warning System).................................243
	8.5 Anti Slip Regulation (ASR).................................................244
		8.5.1 Anti Slip Regulation (ASR)...........................................244
	8.6 Vehicle Stability Control (VSC)............................................244
		8.6.1 Vehicle Stability Control (VSC)......................................244
9 Driver assist systems............................................................246
	9.1 Predictive cruise control (PCC)............................................247
		9.1.1 Predictive Cruise Control (PCC)......................................247
	9.2 Downhill speed control (DSC)...............................................248
		9.2.1 Downhill Speed Control...............................................248
	9.3 EcoRoll function...........................................................250
		9.3.1 EcoRoll function.....................................................250
	9.4 Eco drive function.........................................................251
		9.4.1 Eco drive function...................................................251
	9.5 Hill Start Aid.............................................................252
		9.5.1 Hill Start Aid.......................................................252
	9.6 Tyre Pressure Indication (TPI).............................................254
		9.6.1 TPI (Tyre Pressure Indication).......................................254
	9.7 Camera system..............................................................256
		9.7.1 Camera system........................................................256
10 Manual gearbox ZF...............................................................260
	10.1 General...................................................................261
	10.2 Changing gear with the 12-speed gearbox...................................261
	10.3 Changing gear with the 16-speed gearbox...................................262
	10.4 Changing to low or high speed range.......................................262
	10.5 Changing half gears (splitting)...........................................263
	10.6 Changing gear on an incline...............................................263
	10.7 Clutch protection.........................................................263
11 AS Tronic gearbox...............................................................266
	11.1 Introduction..............................................................267
	11.2 Driving off on a flat road................................................269
	11.3 Automatic gear control....................................................271
	11.4 Manual gear control.......................................................272
	11.5 Manoeuvring...............................................................273
	11.6 Driving on a gradient.....................................................274
	11.7 Off-road mode.............................................................277
	11.8 Liquid transport application..............................................278
	11.9 Clutch protection.........................................................279
12 Air suspension..................................................................280
	12.1 General...................................................................281
	12.2 Remote control............................................................282
	12.3 Engaging air suspension...................................................284
	12.4 Stop key..................................................................284
	12.5 Setting memory keys (M keys)..............................................284
	12.6 Axle Load Monitoring......................................................285
	12.7 Axle load calibration.....................................................289
13 Emergency repairs...............................................................292
	13.1 Tilting the cabin.........................................................293
	13.2 Replacing the poly-V-belt.................................................296
	13.3 Replacing the fuel filter.................................................298
	13.4 Starting after fuel tank has run dry......................................301
	13.5 Gearbox low-range protection..............................................302
	13.6 Releasing the park brake..................................................303
	13.7 Spare wheel winch.........................................................303
	13.8 Jacking up the leaf-sprung front axle.....................................304
	13.9 Jacking up the air sprung front axle......................................304
	13.10 Jacking up the rear axle.................................................305
	13.11 Changing wheels..........................................................306
	13.12 Tyre inflating connection................................................308
	13.13 Towing...................................................................309
	13.14 Jump-starting............................................................312
	13.15 Charging batteries.......................................................313
	13.16 Replacing bulbs..........................................................315
	13.17 Fuses....................................................................317
14 Technical data and identification...............................................320
	14.1 Technical data............................................................321
		14.1.1 Engine..............................................................321
		14.1.2 Electrical system...................................................323
		14.1.3 Symbols label fuse box..............................................324
		14.1.4 Wheels..............................................................326
		14.1.5 Tyre pressure table.................................................326
		14.1.6 Lubricant, coolant and fuel specifications..........................329
		14.1.7 AdBlue..............................................................330
		14.1.8 Engine oil..........................................................331
		14.1.9 Coolant.............................................................331
		14.1.10 Diesel fuel........................................................333
		14.1.11 Clutch.............................................................333
		14.1.12 Steering gear......................................................333
		14.1.13 Cabin tilt mechanism...............................................333
		14.1.14 Chassis............................................................334
	14.2 Identification............................................................334
		14.2.1 Chassis number......................................................334
		14.2.2 Vehicle identification plate........................................334
		14.2.3 Paint identification plate..........................................335
		14.2.4 Engine number.......................................................336
		14.2.5 Engine identification plate.........................................336
15 Alphabetical index..............................................................338
Data to be entered by the DAF dealer...............................................344

DESCRIPTION:

DAF Truck XF Driver’s Manual DW53208206 – PDF DOWNLOAD

PREFACE:

• This handbook consists of sections which describe the driving and care of the truck.
  At the end of the handbook, there is a general alphabetical index, so that you can locate
  quickly what you are looking for.
• This text has been translated from the English source. Translation may lead to
  interpretation differences regarding contents and meaning of the written text.
  Therefore, in case of dispute, the English version of this document shall always be
  considered the sole and authentic source for determining the contents and meaning of
  the written text.
• In the interest of continuing product development, DAF reserves the right to change
  specifications or products at any time without prior notice.
• No part of this publication may be reproduced and/or published by printing, by
  photocopying, on microfilm or in any way whatsoever without the prior written consent
  of DAF Trucks N.V.

WHY THIS HANDBOOK IS SO IMPORTANT!
This handbook contains the information which you, the driver, need for optimum
efficiency, safety and comfort when operating this vehicle.
Besides giving instructions about operation and use, it also pays attention to
maintenance and minor repairs which you may be able to carry out yourself.
For more serious problems, DAF has its own service organisation in Europe:
International Truck Service (ITS). For drivers stranded abroad, the ITS switchboard in
Eindhoven (the Netherlands) is only a phone call away. It is manned 24 hours a day,
365 days a year, to provide assistance to limit the downtime of the vehicle to a
minimum.
To make use of the services of ITS (and to find out under which conditions ITS services
are available), please see the European Service Network directory.

Questions? Email us: [email protected]

S.V
