Doosan Solar 130-III Operation & Maintenance Manual 2022-7115E-1 – PDF DOWNLOAD
DESCRIPTION:
Doosan Solar 130-III Operation & Maintenance Manual 2022-7115E-1 – PDF DOWNLOAD
2022-7115E-1
Serial Number 0022
Accessory Applications:
- The excavator has been primarily designed for moving earth with a bucket.
- For use as a grapple or for other object handling, contact Daewoo. Lifting work applications are permitted in approved lift configuration, to rated capacity only, with no sideloading.
- DO NOT use the machine for activities for which it was not intended.
- DO NOT use the bucket for lifting work, unless lift slings are used in the approved configuration.
Lifting:
- Lifting-mode capacity ratings that are printed at the end of this safety section are based on the machine being level, on a firm supporting surface, with hooks and slings attached in approved configuration.
- Loads must be balanced and supported evenly. Use taglines to keep the load steady if wind conditions and a large surface area are a problem.
- Work crew hand signals, individual tasks, and safe procedures, should all be universally understood before the lift is made.
Locations of Safety Labels:
- Always keep these labels clean.
- If they are lost or damaged, attach them again or replace them with a new label. T here are other labels in addition to the safety labels that follow, so handle them in the same way.
- Safety labels may be available in languages other than English.
- To find out what labels are available, contact your Daewoo distributor.
TABLE OF CONTENTS:
