Dynapac CA280D Spare Parts Catalogue SCA280D-2EN3 – PDF DOWNLOAD

Description

Dynapac CA280D Spare Parts Catalogue SCA280D-2EN3 – PDF DOWNLOAD

TABLE OF CONTENTS:

Dynapac CA280D Spare Parts Catalogue SCA280D-2EN3 – PDF DOWNLOAD

CA280D SN 68920361 – 2
Service kits 4
939563 Service kit 50 h 6
939566 Service kit 500 h 8
939565 Service kit 1000 h 10
Repair kits 12
938558 Steering hitch kit 14
938894 Eccentric shaft kit 16
938891 Drum rotation kit 18
938889 Shock absorber kit, drum 20
Frame 22
Frame 24
Scraper and beam 26
Scrapers, Urethan Rubber Option Up to 68X20404 28
Scrapers, Urethan Rubber Option From 68X20405 30
Scrapers, Spring Steel Option Up to 68X20404 32
Scrapers, Spring Steel Option From 68X20405 34
Hitch 36
Structure 38
Noise suppression 40
Drum shroud Option From 68X20405 42
Drum 44
Drum 46
Drum cartridge Drive side 48
Drum cartridge Vibration side 50
Engine 52
Engine Up to 68X2XXXX 54
Engine From 68X2XXXX 56
Cooling system 58
Combustion air system 60
Air cooler 62
Fuel system 64
Exhaust system 66
Transmission 68
Rear axle and wheels Up to 68X20707 70
Rear axle and wheels From 68X20708 72
Rear axle 74
Differential with limited slip 76
Differential housing and brakes 78
Planet gear 80
383856 Rear axle No-Spin, Option 82
Differential with No-Spin 84
Differential housing and brakes 78
Planet gear 88
Hydraulic system 90
Propulsion system, Front 92
371509 Propulsion motor 94
Propulsion system, Rear 96
TC 2
TABLE OF CONTENTS Page
Dynapac Compaction Equipment AB
Vibration system 98
380145 Vibration motor 100
Steering system 102
375031 Hydraulic cylinder 104
376000 Steering valve 106
Brake system 108
Hydraulic oil tank 110
Central test panel hydraulic Option 112
Variable rear axle motor Option 114
374137 Propulsion motor 116
Dual speed drum drive Option 120
Electrical equipment 122
Electric system 124
Control panel 126
Working lights Option 128
Rotating beacon Option 130
Back-up alarm Option 132
Back-up alarm Option 134
Compaction meter Option 136
Drivers platform 138
Drivers platform 140
Control panel 142
Throttle controls 144
Forward and reverse control 146
Steering column, cpl 148
Rops and fops 150
Cab mounting 152
Cab Screens 154
Cab, door, left side 158
Cab Interior rear mirror 160
Cab Exterior, rear mirror 162
Wiper arm with blade, front 164
Cab Work light 166
Cab Electric 168
Decals 170
Decals 172
Decals 174
Standard equipment 176
Standard equipment 178
Optional equipment 180
Tool equipment 182
Heater Simple cab 184
385222 Heater 186
