DYNAPAC CA5500 Vibratory Roller Parts Catalog Manual 4812160195_B PDF DOWNLOAD

Description

DYNAPAC CA5500 Vibratory Roller Parts Catalog Manual 4812160195_B PDF DOWNLOAD

FILE DETAILS:

DYNAPAC CA5500 Vibratory Roller Parts Catalog Manual 4812160195_B PDF DOWNLOAD

Language : English
Pages : 580
Downloadable : Yes
File Type : PDF

TABLE OF CONTENTS:

DYNAPAC CA5500 Vibratory Roller Parts Catalog Manual 4812160195_B PDF DOWNLOAD

CA5500D/PD s/n 10000134xxA012974 – 020844
Engine: Deutz TDC 2012 L06 2V (IIIA/T3)

CA5500D/PD (IIIA/T3) SN 10000134xxA012974 – 020844 1
Service kits
4812156993 Service kit, 50h Plus 3
4812156994 Service kit, 500h 5
4812157363 Service kit, 500h Plus 7
4812156995 Service kit, 1000h 9
4812157277 Service kit, 1000h Plus 11
4812157254 Start up kit 13
4812158053 Service kit, 2000h 15
4812157255 Service kit, 2000h Plus 17
Repair kits
Eccentric shaft kit 19
4812157275 Drum rotation kit 21
4812158575 Shock absorber kit, drum 23
General – Keys and others
Fuses 25
Keys 27
Frame
Frame, front 29
Crossbeam 31
4812117507 Steering hitch, cpl 33
Scrapers, option
Scrapers, option 35
Scraper module Hardox 37
Scraper module Rubber 39
Scraper assy 41
Scraper module PD Hardox 43
Scraper module PD Heavy duty 45
Scraper mount 47
Frame, rear 49
Frame rear module 51
Cover assembly 53
Step module 55
Step assy 57
Tool box module, Option 59
Engine structure 61
Engine hood module 63
Engine hood mount 65
4812118994 Lock handle, cpl 67
Fender module 69
Hinge module 71
Gas spring module 73
Safety link module 75
Drum
Drum, cpl 77
4812111831 Drum gear, cpl 81
Drum cartridges (D-version)
4812157393 Drum cartridge, vibration side (D/PD version) 83
4812157394 Drum cartridge, vibration side (VM/VP 3-class) 85
4812157784 Drum cartridge with shaft nut, vibration side (D/PD version) 87
4812157785 Drum cartridge with shaft nut, vibration side (VM/VP 3-class) 89
4812157390 Drum cartridge, drive side (D/PD version) 91
4812157391 Drum cartridge, drive side (VM/VP 3-class) 93
Drum cartridges (PD-version)
4812157393 Drum cartridge, vibration side (D/PD version) See page 83
4812157784 Drum cartridge with shaft nut, vibration side (D/PD version) See page 87
4812157390 Drum cartridge, drive side (D/PD version) See page 91
Tooth wheel module 95
Vibration motor adapter 97
Engine
Engine 99
Diesel engine 102
Belt guard module 105
Bracket module 107
Cooling system 109
Cooler stand module 111
Hose kit 113
Hoses 115
Air cleaner 117
Air cleaner module 119
Fuel system
Fuel system 121
Fuel tank module 123
Fuel tank 125
Brackets assy 127
Hoses 129
Draining module 131
Exhaust system 133
Expansion tank module 135
Transmission
Rear axle and wheels 137
4812111833 Rear axle No-Spin
4812111833 Rear axle No-Spin 139
Differential with no-spin 141
Differential housing and brakes 143
Planet gear 145
4812111832 Rear axle Limited-Slip
4812111832 Rear axle Limited-Slip 147
Differential 149
Central housing and brakes 151
Hub reduction 153
Hydraulic systems
Hydraulic system, drum
Hydraulic system, drum 155
Hydraulic motor 157
4812116969 Hydraulic motor
4812116969 Hydraulic motor 159
Rotary group 161
4812157180 Flush & boost pressure valve 163
Lock ring 165
Hydraulic motor 167
4812112200 Hydraulic motor
4812112200 Hydraulic motor 169
Loop flushing 173
Hydraulic system, drum Anti-spin option
Hydraulic system, drum Anti-spin option 175
Hydraulic motor See page 157
4812116969 Hydraulic motor
4812116969 Hydraulic motor See page 159
Rotary group See page 161
4812157180 Flush & boost pressure valve See page 163
Lock ring See page 165
Hydraulic motor 177
4812112202 Drum motor
4812112202 Drum motor 179
Drum motor. Front section 181
Loop flushing 183
Drum motor. Rear section 185
Hydraulic system, rear axle
Hydraulic system, rear axle 187
Hydraulic motor 189
4812112211 Rear axle motor
4812112211 Rear axle motor 191
Loop flusing 195
4812122932 Hydraulic motor 197
Hose holder 201
Hydraulic system, rear axle Anti-spin option
Hydraulic system, rear axle Anti-spin option 203
Hydraulic motor 205
4812112213 Rear axle motor
4812112213 Rear axle motor 207
Front section 209
Loop flushing 211
Rear section 213
Hose holder See page 201
Hydraulic system, oil tank
Hydraulic system, oil tank 215
Hydraulic oil tank assembly 217
Hydraulic valve module 221
4812120840 Hydraulic valve 223
4812112238 Hydraulic valve 225
Hose holder assy kit 227
Fan module, front 229
4812117797 Hydraulic motor 231
Fan module, rear 233
4812117796 Hydraulic motor 235
Hydraulic system, engine room
Hydraulic system, engine room 237
Hydraulic pump module 239
4812112171 Hydraulic pump
4812112171 Hydraulic pump 241
End cap, cpl 245
Hydraulic pump module 247
4812112175 Hydraulic pump
4812112175 Hydraulic pump 249
Rotary group 251
Hydraulic adjustment 253
4/3 Pilot valve 255
Hydraulic oil filter assy 257
Hydraulic pump module 259
4812118150 Hydraulic pump, steering 261
Hydraulic system, engine room Adjustable frequency, Eco opti
Hydraulic system, engine room Adjustable frequency, Eco opti 263
Hydraulic pump module See page 239
4812112171 Hydraulic pump
4812112171 Hydraulic pump See page 241
End cap, cpl See page 245
Hydraulic pump 265
4812112181 Hydraulic pump
4812112181 Hydraulic pump 267
Rotary group 269
Control hydraulic 271
Sub plate 273
Cover with accessories 275
Control module 277
Hydraulic oil filter assy See page 257
Hydraulic pump module, Eco 279
4812118151 Hydraulic pump 281
Hydraulic pump module See page 259
4812118150 Hydraulic pump, steering See page 261
Hydraulic system, frame rear
Hydraulic system, frame rear 283
Connector kit 285
Connector kit 287
Hydraulic system, steering
Hydraulic system, steering 289
Hydraulic cylinder 291
4812121947 Hydraulic cylinder 293
4812120830 Hydraulic cylinder 295
Steering valve module 297
Hydraulic hoses, steering 299
Emergency steering option
Emergency steering option 301
4812112188 Hydraulic pump Emergency steering unit 303
4812112236 Hydraulic valve 305
Electrical equipment
Electric cables, power supply, 1-pole
Electric cables, power supply, 1-pole 307
Battery module 309
Battery disconnector module 311
Electric cables, power supply, 2-pole, option
Electric cables, power supply, 2-pole, option 313
Battery module See page 309
Battery disconnector, 2-pole 315
Electric cables, engine ECU, horn, back-up alarm
Electric cables, engine ECU, horn, back-up alarm 317
ECU, inclination sensor, power converter 319
Standard ECU assembly 321
Power converter module 323
Inclination sensor module 325
Inclination sensor module 327
Horn module 329
Back-up alarm module 331
Back-up alarm module, Quacker 333
Bracket module 335
Cable harness kit Power supply cab
Cable harness kit Power supply cab 337
Driving & side direction lights, number plate light, option
Driving & side direction lights, number plate light, option 339
Steering column switch module 341
Cable harness kit 343
Registration plate light module 345
Registration plate light 347
Holder, Registration plate light 349
Reversing light, option
Reversing light module 351
DCA/GPS equipment module, option
DCA/GPS equipment module, option 353
Holder 355
GPS equipment module 357
GPS equipment assy 359
Computer 361
Tachograph, option
Tachograph, option 363
Holder assy 365
Power supply module 367
Speed sensor, frequency sensor, option
Speed sensor, frequency sensor, option 369
Pulse sensor module (6-pol) 371
Pre-heater installation, option
Pre-heater installation, option 373
Rotating beacon, working light, option
Rotating beacon, working light, option 375
Rotating beacon module 377
Bracket, Rotating beacon 379
Working light module H3 381
Cable harness, emergency steering, option
Cable harness, emergency steering, option 383
Displacement shift
Displacement shift 385
Compaction meter, option
Compaction meter, option 387
Power supply 389
External emergency stop, option
External emergency stop, option 391
Drivers platform
Platform, rops
Platform, rops 393
4812120544 Platform with 4-post ROPS
4812120544 Platform with 4-post ROPS 395
Basic kit Rops, roof, front handrail 397
Rear cover 399
Handrail 401
Cab, basic kit 403
Manual box 405
Decals basic kit 407
Cab symmetric module
Cab symmetric module 409
4812119364 Cab, cpl Comfort
4812119364 Cab, cpl Comfort 411
Screens 413
4812115202 Cab door, cpl 415
4812115200 Sliding screen, left hand 417
Windshield wiper 419
Roof 421
Heater assy 423
Hose kit heater 425
Cab cable harness 427
Cab Interior 429
Heater controls 431
Cab, electrical equipment 433
Emergency hammer, hook 435
Cab, rear cover 437
Cab, front cover 439
Floor mat 441
Step light, front wiper switches 443
Cab, basic kit See page 403
Air channel 445
Sun-blind, inner light 447
4812119365 Cab, cpl Basic
4812119365 Cab, cpl Basic 449
Screens See page 413
4812115202 Cab door, cpl See page 415
4812115200 Sliding screen, left hand See page 417
Windshield wiper See page 419
Hose kit heater See page 425
Roof See page 421
Heater assy See page 423
Cab cable harness See page 427
Cab, electrical equipment See page 433
Cab Interior See page 429
Heater controls See page 431
Emergency hammer, hook See page 435
Cab, rear cover 451
Cab, front cover 453
Wiper switch, front 455
Cab, basic kit See page 403
Manual box See page 405
Decals basic kit See page 407
Car stereo module, option 457
Rear view mirror 459
Rear view mirror module 461
Hose assy kit, heater 463
Drivers seat
Drivers seat 465
Seat frame structure 467
4700391163 Steering column 469
Seat frame adapter module, rotating 471
Seat frame adapter module, fixed 473
Floor cassette module 475
Seat comfort, fabric suspensioned 477
Seat, galon suspensioned 479
Seat belts
Seat belt 2″ 481
Seat belt 3″ 483
Seat belt 2″ with reminder 485
Seat belt 3″ with reminder 487
Control module 489
Forward reverse control module 491
Display unit 495
Reading light 497
Control panel cover 499
Decals
Decals 501
Decals 505
Plain Dynapac decals, kit 507
Optional equipment
Air conditioning
Air conditioning 509
Drying filter module 511
4812114257 Drying filter assy 513
Condensor assembly 515
ACC module 517
4812113624 ACC kit 519
AC module 521
4812113623 Evaporator, cpl 523
Hose assy kit for AC 525
4812114973 Compressor kit 527
Compressor module AC 529
Hose assy kit for AC 531
Level sensor module, option
Level sensor module, option 533
Fire extinguisher/First Aid Cushion
Fire extinguisher/First Aid Cushion 535
Fire extinguisher 537
SMV-sign
SMV-sign 539
Cooling box module
Cooling box module 541
Lunch box
Lunch box 543
Dyn@Link module 545
4812013038 GPS module 547
Compaction meter (DCM) 549
Dyn@lyzer 551
Appendix B:Parts Index 553

IMAGES PREVIEW OF THE MANUAL:

PLEASE NOTE:

• This is the same manual used by the dealers to diagnose and troubleshoot your vehicle
• You will be directed to the download page as soon as the purchase is completed. The whole payment and downloading process will take anywhere between 2-5 minutes
• Need any other service / repair / parts manual, please feel free to contact [email protected] . We still have 50,000 manuals unlisted

G.P
