TABLE OF CONTENTS:

Dynapac CC422 Spare Parts Catalogue SCC422-1EN3 – PDF DOWNLOAD

Vibratory Tandem Roller
CC422
Spare Parts Catalogue
SCC422-1EN3
Valid from roller serial number:
*62510424* – *62510800*
Diesel engines:
CUMMINS 4BTA 3.9 Elite
Published catalogue issues valid for these rollers:
Catalogue Issue date Valid for serial numbers
S422EN1 1997-03 Replaced by S422EN2
S422EN2 1999-05 Replaced by SCC422-1EN1
SCC422-1EN1 2000-05 Replaced by SCC422-1EN2
SCC422-1EN2 2002-06 Replaced by SCC422-1EN3
SCC422-1EN3 2004-12 See above

CC422 SN 62510424 – 62510800 2
Service kits 4
938551 Service kit 50 h From 62510434 6
938527 Service kit 250/750 h 8
938552 Service kit 500 h From 62540434 10
938553 Service kit 1000 h From 62510434 12
938558 Steering hitch kit 14
Repair kits 16
938904 Eccentric shaft kit Up to 62510684 18
938905 Eccentric shaft kit From 62510685 20
938891 Drum rotation kit 22
938917 Scraper kit CC322/422/432 24
938888 Shock absorber kit, drum 26
Frames 28
Frames 30
Covers, ladders 32
Scrapers, standard, front drum 36
Scrapers, standard, rear drum 38
Scrapers, spring loaded Foldable 40
Articulated link 42
Structure 44
Noise suppression 48
Sprinkler systems, tanks 50
Sprinkler system, front 54
Sprinkler system, rear 56
923690 Water pump Up to 62510478 60
903987 Sprinkling pump From 62510479 62
Sprinkler mats 64
Drum 66
Drum, standard, front/rear 68
Engine 72
Diesel engine CUMMINS 4BTA 3.9 74
Radiator/cooler Up to 62510433 78
Radiator/cooler From 62510434 80
Intake system 82
Fuel system CUMMINS 4BTA 3.9 84
Exhaust system 86
Pumpdrive and coupling 88
359151 Gear box Up to 62510716 90
373354 Gear box From 62510717 92
Hydraulic system 94
Propulsion system, pump 96
359142 Hydraulic pump, propulsion 98
Propulsion system, motors 102
359143 Hydraulic motor, propulsion, front Up to 62510509 104
374481 Hydraulic motor, propulsion, front From 62510510 Up to 62510515 108
359143 Hydraulic motor, propulsion, front From 62510516 104
359144 Hydraulic motor, propulsion, rear Up to 62510509 116
374482 Hydraulic motor, propulsion, rear From 62510510 Up to 62510515 120
TC 2
TABLE OF CONTENTS Page
Dynapac Compaction Equipment AB
359144 Hydraulic motor, propulsion, rear From 62510516 116
Shut-off valve Option 128
Vibration system, pump Up to 62510699 130
Vibration system, pump From 62510700 134
359141 Hydraulic pump, vibration 136
Vibration system, motors 140
370260 Hydraulic motor, vibration 142
Steering system Up to 62510434 144
Steering system From 62510435 Up to 62510700 148
Steering system From 62510701 152
Hydraulic oil tank 156
372991 Hydraulic pump steering 158
359145 Steering valve 160
373410 Hydraulic cylinder Up to 62510669 162
375031 Hydraulic cylinder From 62510670 164
Offset drum Up to 62510434 166
Offset drum From 62510435 168
Valve Offset drum 170
371438 Cylinder, offset drum 172
373406 Cylinder, offset drum 174
Brake system 176
Electrical equipment 178
Electrical equipment 180
Electrical equipment, additional for cab 184
Instrument box 186
Instrument panel, main 188
Speed and frequency, sensors 190
Instrument panel, upper left 192
Instrument panel, upper right 194
Instrument panel, lower left 196
Instrument panel, lower right 198
Instrument panel, relay, fuses 200
Emergency stop panel 202
Driving lights Direction & licenseplate light Up to 62510702 204
Driving lights Direction & licenseplate light From 62510703 Up to 62510703 206
Driving lights Direction & licenseplate light From 62510704 Up to 62510715 208
Driving lights Direction & licenseplate light From 62510716 206
Working lights with/without Rops Up to 62510702 212
Working lights with/without Rops From 62510703 Up to 62510703 214
Working lights with/without Rops From 62510704 Up to 62510715 216
Working lights with/without Rops From 62510716 214
Working lights, cab 220
Protection cover, Head light Option 222
Rotating beacon 224
Tachograph 226
Offset drum Electrical equipment 228
Drivers platform 230
Drivers platform 232
Drivers platform, for cab 234
Drivers seat, turn-over 236
Drivers seat, turn-over, in cab 238
359918 Steering column 240
Cross sliding Controls (version 1) 242
Cross sliding Controls 244
Cross sliding, carrier 246
Forward and reverse control Version 1 248
TC 3
Dynapac Compaction Equipment AB
Forward and reverse control Version 2 250
Speed limiter Option 252
Engine control 254
Rear mirror 256
Rops / fops 258
Cab, interior 260
Cab, inside panels 264
Cab, screens 266
Cab, wipers, front and rear 268
Cab, wipers, right side 270
Cab, water tank wipers 272
Cab, door, left side 274
Cab, heater and, fan system 276
Cab Roof mounted,electric switches 278
Interior rear mirror Sun curtain, first aid kit 280
Exterior rear mirrors 282
Radio and cassette player 284
Decals 286
Plates and decals 288
Standard equipment 290
Standard equipment 292
Optional equipment 294
Compaction meter 296
Edge cutter cpl 298
Edge cutter 300
Edge cutter Hydraulics without offset 302
Edge cutter Hydraulics with offset 304
Edge cutter Sprinkler system 306
Eyelet 308
SMV sign 310
Tool equipment 312
Brake release, prop. motors 314
Air conditioner assembly 316
370889 Air conditioner unit 318
Roof hatch 322
Asphalt temperature meter 324
