Eaton Procision Dual Clutch Transmission Service Repair Manual PDF

Description

Eaton Procision Dual Clutch Transmission Service Repair Manual TRSM0990 PDF DOWNLOAD

Description:

Product Overview: The Eaton Procision Service Manual (TRSM0990) is the definitive technical resource for the Procision™ Dual Clutch Automated Transmission. Updated for June 2023, this manual provides factory-approved procedures for the “EDCO” series transmissions (e.g., EDCO-xx107A, EDCO-xx107A-P). Whether you are diagnosing a Procision transmission actuation control manifold service issue or performing a complete Eaton Procision dual clutch transmission service manual overhaul, this document guides you through every step with detailed illustrations and torque specifications.

Key Technical Coverage: The manual is divided into General Information, Service Procedures (Removal, Disassembly, Assembly, Installation), and Appendix. It features specific sections for Procision transmission calibration procedures using ServiceRanger software.

Detailed Table of Contents:

• General Information:

  • Serial Tag Information & Model Nomenclature (EDCO-06F107A, etc.)

  • Lubrication Specifications (PS-386 HD Synthetic).

  • Service Kits and Parts Index.

• Service Procedures – Components:

  • Dual Clutch Module (DCM): Removal, installation, and input seal replacement.

  • Control Modules: Transmission Control Module (TCM) and Actuation Control Manifold (ACM) service, including gasket replacement and solenoid connection.

  • Sensors: 3-Rail Position Sensor , Rail D Position Sensor , Engine Speed Sensor, and Triple Pressure Sensor diagnostics.

  • Sump Pan & Filter: Maintenance of the sump pan filter and cartridge filter.

• Disassembly & Assembly:

  • Clutch Housing: Front cover, pump drive gear, and clutch support manifold.

  • Main Housing: Upper/Lower shafts, gearing, and shift rail assembly.

  • Rear Housing: Output yoke, parking pawl mechanism (if equipped), and rear bearing covers.

  • Synchronizers: Detailed rebuild instructions for Rail A, B, C, and D synchronizers.

• Calibration & Setup:

  • ServiceRanger Routines: Rail Calibration, Line Pressure, Clutch Pressure (PI), and Clutch Touch Point (PTP) procedures.

  • Oil Fill: Correct procedures for filling and checking fluid levels.

File Details:

• Manual Name: Eaton Procision Service Manual (TRSM0990 EN-US)

• Models Covered: Eaton Procision Transmissions (EDCO-6F107A, EDCO-6F107A-B, EDCO-6F107A-P, etc.)

• Year: 2023 (June Edition)

• Manual PDF Quality: High Definition, Searchable Text, Vector Illustrations, Schematics

• No. of Pages: 930 Pages
