Fiat Allis Wheel Loader FR10 FR12 FR15 Implement Hydraulics & Power Steering Service Manual – PDF DOWNLOAD

Description

Fiat Allis Wheel Loader FR10 FR12 FR15 Implement Hydraulics & Power Steering Service Manual

FILE DETAILS:

Fiat Allis Wheel Loader FR10 FR12 FR15 Implement Hydraulics & Power Steering Service Manual

Size : 6.46 MB
Format : PDF
Language : English
Brand: Fiat
Type of machine: Wheel Loader
Type of document: Service Manual
Model: Fiat Allis FR10 FR12 FR15 Wheel Loaders
Number of Pages: 76 pages
Form No.: 73142921

DESCRIPTION:

Fiat Allis Wheel Loader FR10 FR12 FR15 Implement Hydraulics & Power Steering Service Manual

FOREWORD:

Always furnish serial number if making an inquiry to dealer or factory about this machine. Many equipment owners employ the Dealer’s Service Department for all work other than routine lubrication and minor service. This prac- tice is encouraged. as our Dealers are well informed and equipped to render efficient service by factory trained mechanics. This manual may not be reprinted or reproduced, either in whole or In part, without written permission of Flatailis. illustrations show standard and optional Items.

GENERAL :

Study the Operation and Maintenance Instruction Manual before starting, operating, maintaining, fueling, or servicing machine. Read and heed all machine-mounted safety signs before star- ting, operating, maintaining, fuellng or servicing machine. Machine-mounted safety signs have been color coded yellow with black border and lettering for WARNING and red with white border and lettering for DANGER points. Never attempt to operate the machine or its tools from any position other than seated in the operator’s seat. Keep head, body, limbs, hands and feet Inside operator’s compartment at all times to reduce exposure to hazards outside the operator’s compartment.

• Do not allow unauthorized personnel to operate, service or maintain this machine. Always check work area for dangerous features. The following are examples of dangerous work areas: slopes, overhangs, timber, demolitions, fire, high walls. dropoff, backfills, rough terrain, ditches, ridges, excavations, heavy traffic, crowded parking, crowded maintenance and closed areas. Use extreme care when in areas such as these.
• An operator must know the machine’s capabilities. When working on slopes or near dropoffs be alert to avoid loose or soft conditions that could cause sudden tipping or loss of con- trol. ~ Do not jumpon or off machine. Keep two hands and one foot, or two feet and one hand, in contact with steps, grab rails and handles at all times. 00 not use controls or hoses as handholds when climbing on or off machine.
• Hoses and controls are movable and do not provide a solid support. Controls also may be inadvertently moved causing accidental machine or equipment movement. Keep operator’s compartment, stepping points, grab-rails and handles clear of foreign objects, oil, grease, mud or snow accumulation to minimize the danger of slipping or stumbling. Clean mud or grease from shoes before attempting to mount or operate the machine.
• Be careful of slippery conditions on stepping points, hand rails, and on the ground. Wear safety boots or shoes that have a high slip resistant sole material. For your personal protection. do not attempt to climb on or off machine while machine is In motion. Never leave the machine unattended with the engine running. Always lock up machine when leaving it unattended. Return keys to authorized security.
• Heed all shutdown procedures of the Operation and Maintenance Instruction Manual. Always set the parking brake when leaving the machine for any reason. Do not use machine to carry loose objects by means other than attachments for carrying such objects. DO NOT CARRY RIDERS unless the machine is equipped for carrying people to reduce personal exposure to being thrown off. Do not operate machinery in a condition of extreme fatigue or illness.
• Be especially careful towards the end of the shift. Roll Over Protective Structures are required on wheel loaders, dozer tractors, track type loaders, graders and scrapers by ,local or national requirements. DO NOT operate this machine without a Roll over Protective Structure.
• Do not operate a machine without a falling object protective structure (FOPS). Do not operate this machine without a rear canopy screen when machine is equipped with rear mounted towing winch. Seat belts are required to be provided with roll over protective structures or roll protection cabs by local or national regulations. Keep the safety belt fastened around you during operation. Where noise exposure exceeds 90 dBA for 8 hours, wear authorized ear protective equipment per local or national requirements that apply.
• Keep clutches and brakes on machine and attachments such as power control units, winches and master clutches adjusted according to Operation and Maintenance Instruction Manuals of the manufacturers at all times. DO NOT adjust machine with engine running except as specified. Do not operate a machine with brakes out of adjustment. See the Operation and Maintenance Instruction Manual.

TABLE OF CONTENTS:

Fiat Allis Wheel Loader FR10 FR12 FR15 Implement Hydraulics & Power Steering Service Manual

• Safety Rules
• Foreword
• Topic 1 – General Description
• Topic 2 – Lubrication Specifications
• Topic 3 – Performance Specifications
• Topic 4 – Troubleshooting and Testing The Hydraulic Systems
• Topic 5 – Implement and Steering Pumps
• Topic 6 – Implement and Steering Valves
• Topic 7 – Hydraulic Cylinder Repair
• Topic 8 – Hydraulic Tank
• Topic 9 – Service Tools

FIAT ALLIS WHEEL LOADER FR10 FR12 FR15 IMPLEMENT HYDRAULICS & POWER STEERING SERVICE MANUAL – PDF DOWNLOAD:

IMAGES PREVIEW OF THE MANUAL:

PLEASE NOTE:

• This is the same manual used by the DEALERSHIPS to SERVICE your vehicle.
• The manual can be all yours – Once payment is complete, you will be taken to the download page from where you can download the manual. All in 2-5 minutes time!!
• Need any other service / repair / parts manual, please feel free to contact us at heydownloadss @gmail.com . We may surprise you with a nice offer
