FIATALLS FD30B DOZER CAB & AIR CONDITIONING SERVICE MANUAL
FILE DETAILS:
FIATALLS FD30B DOZER CAB & AIR CONDITIONING SERVICE MANUAL
Size: 28.4 MB
Format: PDF
Language: English
Brand: Fiat
Type of document: Service Manual
Model: Fiat Allis FD30B DOZER
Number of Pages: 80 pages
Set Form No.: 73154528
DESCRIPTION:
FIATALLS FD30B DOZER CAB & AIR CONDITIONING SERVICE MANUAL
GENERAL INFORMATION:
- Study the Operation and Maintenance Instruction Manual before starting, operating, maintaining, fueling, or servicing machine. Read and heed all machine-mounted safety signs before star- ting, operating, maintaining, fueling or servicing machine. Machine-mounted safety signs have been color coded yellow «vrth black border and lettering tor WARNING and red with white border and lettering for DANGER points.
- Never attempt to operate the machine or its tools from any position other than seated in the operator’s seat. Keep head, body, limbs, hands and feet inside operator’s compartment at all times to reduce exposure to hazards outside the operator’s compartment. Do not allow unauthorized personnel to operate, service or namtaln this machine. Always check work area lor dangerous features.
- The following ere examples of dangerous work areas: slopes, overhangs, timber, demolitions, fire, high walls, dropoff, backfills, rough terrain, ditches, ridges, excavations, heavy traffic, crowded parking, crowded maintenance and closed areas. Use extreme care when in areas such as these. An operator must know the machine’s capabilities. When working on slopes or near dropoffs be alert to avoid loose or soft conditions tnat could cause sudden tipping or less of con- trol. Do not jump on or off machine.
- Keep two hands and one loot, or two feet and one hand, in contact with steps, grab rails and handles at all times. Do not use controls or hoses as handholds when climbing on or off machine. Hoses arid controls arc movable and do not provide a solid support. Controls also may be inadvertently moved causing accidental machine or equipment movement.
- Keep operator’s compartment, stepping points, grab-rails and handles clear ol foreign objects, oil, grease, mud or snow accumulation to minimize the danger of slipping or stumbling. Clean mud or grease from shoes before attempting to mount or operate the machine. Be careful of slippery’ conditions on stepping points, hand rails, and on the ground.
- Wear safely boots or shoes that have a high slip resistant sole material. For your personal protection, do not attempt to climb on or off machine while machine is in motion. Never leave the machine unattended with the engine running. Always lock up machine when leaving It unattended! Return -<eys to authorized security. Heed all shutdown procedures of the Operation and Maintenance Instruction Manual.
- Always set the parking brake when leaving the machine for any reason Do not wear rings, wrist watches, jewelry. loose or nanging apparel, such as ties, torn clothing, scarves, unbuttoned, or unzipped jackets that can catch on moving parts Wear proper safety equlpmenl as authorized for the job. Examples: hard hals, safety shoes, heavy gloves car protectors, safety
- glasses or goggles, reflector vests, or respirators. Consult your employer for specific safety equipment requirements. Do not carry loose objects in pockets that might fall unnoticed into open compartments.
- Oo net use machine to carry loose objects by means other than attachments for carrying such objects. 00 NOT CARRY RIDERS unless the machine Is equipped for carrying people to reduce personal exposure to being thrown off.
- Do not operate machinery in a condition of extreme fatigue or Illness. Be especially careful towards the end of the shift. Roll Over Protective Structures are required on wheel loaders, dozer tractors, track type loaders, g’aders and scrapers by .local or national requirements. DO NOT operate this machine without a Roll over Protective Structure. Do not operate a machine without a falling object protective structure (FOPS).
- Do not operate this machine without a rear canopy screen when machine is equipped with rear mounted towing winch. Seat belts are required to be provided with roll over protective structures or roll protection cabs by Iccal or national regulations. Keep the safety be.t fastened around you during opera- tion. Where noise exposure exceeds 90 CBA for S hours, wear authonzed ear protective equipment per local or national requirements that apply.
- Keep clutches and brakes on machine and attachments such as power control units, winches and master clutches adjusted according to Operation and Maintenance Instruction Manuals of the manufacturers at all times. DO NOT adjust machine with engine running except as specified. Do not operate a machine with brakes out of adjustment. See the Operation and Maintenance instruction Manual.
- Move carefully when under. In or near machine or implements. Wear required protective equipment, such as hard hat. safety glasses . safety shoes, ear protectors. To move a disabled machine, use a trailer or low boy truck if available.
- If towing Is necessary, provide warning signals as required by local rules and regulations and follow Operation and Maintenance Instruction Manual recommendations. Load and unload on a level area that gives full support to the frailer wheels.
- Use ramps of adequate strength, low angle and proper height. Keep trailer bee clean of clay, oil and all materials that become slippery. Tie machine down securely to truck or trailer bed and block tracks (or wheels) as required by Che carrier.
VIDEO PREVIEW OF THE MANUAL:
IMAGES PREVIEW OF THE MANUAL:
TABLE OF CONTENTS:
FIATALLS FD30B DOZER CAB & AIR CONDITIONING SERVICE MANUAL
Table of Contents 12
Topic 1 – General Description 13
Topic 2 – Tilting ROPS Cab 14
Topic 3 – Cab Accessories 17
Topic 4 – Electrical System 29
Topic 5 – Glass 30
Topic 6 – Air Conditioner 32
Topic 7 – Miscellaneous 51
Topic 8 – Special Tools 71
Topic 9 – Specifications 72
