Genie GTH-2506 AGRI-625 Parts Manual 645014 – PDF DOWNLOAD

Description

Genie GTH-2506 AGRI-625 Parts Manual 645014 – PDF DOWNLOAD

Language : English
Pages : 140
Downloadable : Yes
File Type : PDF

Table of Contents:

Genie GTH-2506 AGRI-625 Parts Manual 645014 – PDF DOWNLOAD

How to Read Your Serial Number 3
Parts Stocking List 7
How to Order Parts 8
Service Parts Fax Order Form 9
Electronic Version
Click on any page number to view the figure
100 Decals
101 1 605651 Decals, View 1 10
102 1 605652 Decals, View 2 12
103 1 606001 Decals, View 2 14
200 Drive Chassis Components
201 1 605821 Rear Chassis 16
202 1 605822 Left Chassis 18
203 1 605655 Right Chassis 20
204 1 605657 Hydraulic Oil Tank 22
205 1 605658 Driveline And Wheels 24
206 1 605659 Front Axle – Differential 26
207 1 605660 Front Axle – Reduction Gear 28
208 1 605661 Front Axle – Brake 30
209 1 605662 Front Axle – Steering Cylinder 32
210 1 605663 Rear Axle – Differential 34
211 1 605664 Rear Axle – Steering Axle 36
212 1 605665 Rear Axle – Steering Cylinder 38
300 Engine Components
301 1 605667 Diesel Engine – Engine Cooling System 40
302 1 606000 Diesel Engine – Engine Cooling System 42
303 1 605823 Diesel Engine – Exhaust System – Injection –
Accelerator 44
304 1 605824 Diesel Engine – Hydraulic Pumps 46
400 Cab Components
401 1 605670 Cabin, View 1 48
402 1 605671 Cabin, View 2 50
403 1 606002 Heater 52
404 1 605672 Dashboard 54
405 1 605825 Joystick Connections 56
500 Boom Components
501 1 605674 Boom (1st – 2nd Telescopic Element) 58
502 1 605826 Overload Warning Unit Up To Serial Number
20378 60
503 1 606003 Overload Waring Unit From Serial Number
20379 62
504 1 605827 Manual Fork Attachments 64
505 1 605677 Forks 66
506 1 605678 Cylinders 68
600 Hydraulic System
601 1 605679 Hydraulic System – Fork Balancing 70
602 1 605680 Hydraulic System – Auxiliary Circuits 72
603 1 605681 Hydraulic System – Lifting and Boom
Extension 74
604 1 605682 Hydraulic System – Negative Brake 76
605 1 605683 Hydraulic System – Hydraulic Switches 78
606 1 605684 Hydraulic System – Tank and Exchanger 80
607 1 605685 Hydraulic System – Suction System Hydraulic
Pumps 82
608 1 605686 Hydraulic System – Transmission 84
609 1 605687 Hydraulic System – Power Steering System 86
700 Electric Installation
701 1 605688 Cabin Fuse Box 88
702 1 605643 Complete rear lights 90
703 1 605689 Electric Installation 92
800 Optionals
801 1 58 0000 0000 Transport Locking Devices 94
802 1 58 0100 0001 T U V Kit 96
803 1 58 0402 5003 Concrete Mixing Bucket
Pre-arrangement 98
804 1 58 1002 9001A Second Hydraulic Circuit (Hydraulic
Part) 100
805 1 58 1002 9001B Second Hydraulic Circuit (Electrical
Part) 102
806 1 0 58 1401 1002 Special Air Filter 104
807 1 58 1600 9001 Windshield Protection Grid 106
808 1 58 1701 4004 Adjustable Spotlight on Boom 108
809 1 58 1900 7001 6-ton Towing Hitch 110
810 1 58 2504 6000 Additional Seat Armrest 112
811 1 58 2511 9600 Hydraulic Quick Coupling for
Attachment 114
812 1 58 2513 1008 Inching Valve 116
813 1 58 2900 0014 Lock Forks 118
814 1 58 2513 1033A Pressure Reducing Valve 120
815 1 58 2513 1033B Pressure Reducing Valve Combined
With Inching Valve 122
816 1 606261 Air Conditioning Cabin 124
817 1 58 0904 7002 Air Conditioning Deutz Engine 126
818 1 606262 air Conditioning Electrical Parts 128
Indices
Part Number Index 130
Part Description Index 134
Cross References
