Genie lift Boom Z-45/25 Z-45/25J IC Power Parts Manual 1289073 – PDF DOWNLOAD

Description

Genie lift Boom Z-45/25 Z-45/25J IC Power Parts Manual 1289073 – PDF DOWNLOAD

FILE DETAILS:

Genie lift Boom Z-45/25 Z-45/25J IC Power Parts Manual 1289073 – PDF DOWNLOAD

Language : English
Pages :389
Downloadable : Yes
File Type : PDF

TABLE OF CONTENTS:

Genie lift Boom Z-45/25 Z-45/25J IC Power Parts Manual 1289073 – PDF DOWNLOAD

Z-45/25, Z-45/25J IC MC from SN Z4525D-1358 (1289073) 0
001 Parts Stocking List 12
0011 Parts Stocking List 12
100 Decals 18
1011 Decals with Words, Hydraulic Tank Side, ANSI, CSA, Australia 18
1021 Decals with Words, Engine Side, ANSI, CSA, Australia 22
1031 Decals with Words, Platform, ANSI & CSA 26
1041 Decals with Words, Platform, Australia 28
1051 Decals with Symbols, Hydraulic Tank Side, ANSI and CE 30
1061 Decals with Symbols, Engine Side, ANSI and CE 34
1071 Decals with Symbols, Platform, ANSI 36
1081 Decals with Symbols, Platform, CE 38
1091 Decals with Words, Hydraulic Tank Side, New ANSI & CE (From Sep 1st, 2020) 40
1101 Decals with Words, Engine Side, New ANSI & CE (From Sep 1st, 2020) 44
1111 Decals with Words, Platform, New ANSI &CE (From Sep 1st, 2020) 46
1121 Decals with Symbols, Hydraulic Tank Side, New ANSI & CE (From Sep 1st, 2020) 48
1131 Decals with Symbol, Platform, ANSI & CSA（ (From Sep 1st, 2020) 50
1141 Decals with Symbol, Platform, New ANSI & CE (From Sep 1st, 2020) 52
200 Chassis Components 54
2011 Steer-end Wheels and Hubs, 4WD Models 54
2021 Steer-end Wheels and Hubs, 2WD Models 58
2031 Steer Axle Linkage 60
2041 Non-steer End Wheels and Hubs 64
2051 Non-steer Axle 68
2061 Oscillate Valve 70
300 Turntable Components 72
3011 Turntable Rotator 72
3021 Fuel and Hydraulic Tank Installation 74
3031 Diesel Fuel Tank 78
3041 Function Manifold and Ground Control Box Installation 80
3051 Ground Control Box, Models with Hour Meter, View 1 84
3061 Ground Control Box, Models with Hour Meter, View 2 88
3071 Ground Control Box, Models with LCD Readout Screen, View 1(to SN Z4525D-3978) 92
3072 Ground Control BOX, Z-45 DIESE, TIRE IV, ANSI A9220 & CE, View1 (from SN Z4525D-3979) 96
3081 Ground Control Box, Models with LCD Readout Screen, View 2(to SN Z4525D-3978)100
3082 Ground Control BOX, Z-45 DIESE, TIRE IV, ANSI A9220 & CE, View2 (from SN Z4525D-3979)104
3091 Turntable Cover, Engine Side108
3092 Turntable Cover, Engine Side (Kubota engine option)114
3101 Turntable Cover, Tank Side118
3102 Turntable Cover, Tank Side (Kubota engine option)120
3111 Wire Harness Diagram122
3121 Ground Control BOX, Z-45 DIESE, CN3, CE, View1128
3131 Ground Control BOX, Z-45 DIESE, CN3, CE, View2132
3141 Ground Control BOX, D436, ANSI, View1134
3151 Ground Control BOX, D436, ANSI, View2136
400 Engine Components138
4011 Deutz D2011L03i Engine, View 1138
4021 Deutz D2011L03i Engine, View 2144
4031 Deutz D29L4 Engine, View 1148
4041 Deutz D29L4 Engine, View 2152
4051 Deutz D29L4 Engine, View 3156
4061 Deutz D29L4 Engine, View 4160
4071 Deutz D29L4 Engine, View 5162
4081 Perkins 404D-22 Engine, View 1168
4091 Perkins 404D-22 Engine, View 2174
4101 Engine Tray180
4111 Deutz D436-L3i-CN3 Engine, View 1186
4121 Perkins 404D-22 Engine, View 1190
4131 Kubota D1105 Engine, View 1194
4141 Kubota D1105 Engine, View 2196
4151 Kubota D1105 Engine, View 3200
4161 Engine Tray (Kubota D1105), View 4202
4171 Perkins 403J-11/403EA-11 Engine, View 1206
4181 Perkins 403J-11/403EA-11 Engine, View 2210
500 Boom Components214
5011 Boom Pins and Bearings214
5021 Boom Linkage216
5031 Upper Pivot Components220
5041 Primary and Extension Booms222
5051 Cable Track226
5061 Non-Jib Platform Leveling and Rotation , Z-45/25230
5071 Jib Boom and Platform Leveling, Z-45/25J234
5081 Platform Rotation and Support, Z-45/25J238
600 Platforms240
6011 Platform configurtion240
6021 Platform Components, Z-45/25J (to SN Z4525D-2105)242
6022 Platform Components (from SN Z4525D-2106)246
6023 Platform Installation, China Option250
6031 Platform Control Box, View 1254
6041 Platform Control Box, View 2260
6051 Joysticks262
700 Manifolds and Pumps264
7011 2WD Traction Manifold264
7021 4WD Traction Manifold266
7031 Function Manifold270
7041 Jib and Platform Rotate Manifolds276
7051 Pumps (To SN Z4525D-4409, from SN Z4525D-5434)278
7052 Pumps (From SN Z4525D-4410 to SN Z4525D-5433)282
800 Hydraulic Hoses and Fittings284
8011 Function Manifold, View 1(from SN Z4525D-4140 to SN Z4525D-5433)284
8012 Function Manifold, View 1 (to SN Z4525D-4409, from SN Z4525D-5434)288
8013 Function Manifold, View, 22kw Generator292
8021 Function Manifold, View 2296
8031 Drive and Steer, 2WD298
8041 Drive and Steer, 4WD300
8051 Boom Components, Z-45/25304
8061 Boom Components, Z-45/25J306
900 Accessories308
9011 Flashing Alarm Package308
9021 Platform Options310
9031 Air Line to Platform314
9041 Platform Mesh-Side Swing Gate316
9042 Platform Mesh-Front Single Entry318
9051 Hostile Environment Package – Engine Air Pre Cleaner (Deutz D2011L03i)322
9061 Hostile Environment Package – Engine Air Pre Cleaner ( Perkins and Deutz D29L4)324
9071 Hostile Environment Package – All Models View 1326
9081 Hostile Environment Package – All Models View 2328
9091 Aircraft Protection Package330
9101 Operator Protective Structure334
9111 Platform Overload Option336
9121 Cold Weather Package340
9131 Oil Cooler342
9141 Fall Arrest Bar344
9151 Operator Protection Alarm (to January 2017)346
9152 Lift Guard Contact Alarm (from January 2017 to Z4525D-6059)350
9153 Gen II Contact Alarm Option (from Z4525D-6060)354
9161 Auxiliary Rail Option356
9171 Pipe Cradle Option358
9181 Telematics Option360
9182 China Telematics Option, TZ200, STD362
9191 China Pre-filter Option(KUBOTA D1105)364
9201 Hydraulic Generator366
9211 RCBO Option370
