Genie Z-30/20 N Parts Manual 35533 – PDF DOWNLOAD

Description

Genie Z-30/20 N Parts Manual 35533 – PDF DOWNLOAD

Language : English
Pages : 112
Downloadable : Yes
File Type : PDF

Table of Contents:

Genie Z-30/20 N Parts Manual 35533 – PDF DOWNLOAD

100 Decals and Paint
101 1 Decals and Paint – View 1
102 1 Decals and Paint – View 2
200 Drive Chassis Components
201 1 Steer Axle Linkage, Wheels and Hubs
202 1 Steer / Brake Manifold
203 1 Battery Charger
204 1 Battery Packs
205 1 Non-steer Axle
206 1 Electronic Control Module
207 1 Hydraulic Hoses and Fittings
300 Turntable Components
301 1 Turntable Rotator
302 1 Turntable Components – Ground Controls Side
303 1 Function Manifold
304 1 Ground Controls
305 1 Turntable Components – Hydraulic Power Unit Side
306 1 Hydraulic Power Unit
306 2 Hydraulic Power Unit Retro Kit
307 1 Turntable Covers
308 1 Hydraulic Hoses and Fittings
400 Boom Components
401 1 Secondary Boom – View 1
402 1 Secondary Boom – View 2
403 1 Upper Mid-pviot
404 1 Primary and Extension Booms
405 1 Cable Track
406 1 Jib Boom and Platform Rotator
407 1 Hydraulic Hoses and Fittings
500 Platform Components
501 1 Platform
502 1 Platform Controls – View 1
503 1 Platform Controls – View 2
504 1 Joystick Controller – Drive / Steer Functions
505 1 Rotational Controller – Boom Function Speed
600 Accessories
601 1 Alarm and Beacon Package
602 1 Hour Meter and Battery Charge Indicator
Part Number Index
