This is the complete 352-page official Grass Valley Kalypso HD/Duo Service Manual, written for Software Version 12.0. This is the definitive reference for broadcast engineers, system integrators, and technical operators who install, configure, maintain, or repair the Kalypso Video Production Center.

The manual provides exhaustive installation procedures, detailed system configuration workflows, advanced Kalypso 4-M/E resource sharing setups, comprehensive troubleshooting and diagnostics tools, and complete Field Replaceable Unit (FRU) service instructions.

It covers all system variants including 4-M/E, 2-M/E, and 1-M/E configurations, and supports both Kalypso HD and Kalypso Duo frames and control surfaces.

Appendices include full FRU listings, detailed interface documentation for routers, VTRs, Profile VDRs, editors, and GPI/PBus connections — making this manual an essential technical reference for any Kalypso facility.

SECTION 1 — SYSTEM OVERVIEW

• System Features (4-M/E, 2-M/E, Duo)

• Control Surface Components

• Video Processor Frame Components

• Power Supply Overview

• Remote Aux Panels & Shot Box Options

• Still Store & Transform Engine Options

• Functional Block Diagrams

• Video Signal Flow

• System Control Architecture

SECTION 2 — INSTALLATION

Pre-Installation

• Site survey

• Tools & safety precautions

• Bench test procedures

Frame & Panel Installation

• Video Processor Frame installation (airflow, filters, pinouts)

• Frame power supply installation

• Main Panel installation (4-M/E, 2-M/E, 1-M/E)

• Menu Panel installation (Standard & Original)

• Shot Box and Remote Aux Panel installation (24/32 crosspoint)

System Cabling

• LAN requirements

• Control cabling

• Video cabling

• Timing & delay setup (Timing Analyzer, Time Zones)

SECTION 3 — CONFIGURATION

• System power-up & initialization

• IP address setup for all components

• Engineering Setups (EIC login)

• Source definition

• Button mapping

• Output assignments

• Tally configuration (calculation, relay assignments)

• Sync/Timing menu settings

• Collaborative vs Independent Suite configuration

• Control surface definition

• Lever Arm calibration

• Joystick calibration

• Touchscreen (Menu Panel) display calibration

SECTION 4 — MAINTENANCE

Troubleshooting & Diagnostics

• Web Browser diagnostic access

• System diagnostics data interpretation

• LAN troubleshooting

Video Processor Frame Maintenance

• Air filter replacement

• Module replacement (FRUs)

• Frame recovery procedure

Main Panel Maintenance

• Fuse replacement

• Disk-On-Chip / Hard Drive replacement

• Board replacement

• Panel diagnostics

Local Aux Panel Maintenance

• Diagnostics & board replacement

Software Procedures

• Software installation

• Boot Dial Switch settings

• Clearing NV memory

• Software option authorization

• Hardware reset procedures

Still Store Maintenance

• Still Store recovery procedures

APPENDICES

Appendix A — Specifications

• Full system specifications

• Power, thermal, timing, and interface data

Appendix B — Field Replaceable Units (FRUs)

• Complete FRU list with module descriptions

Appendix C — External Interfaces

• DPM

• Krystal

• GVeous

• Profile VDR

• VTR

• PBus II

• GPI

• Editor

• Router
