Heli Forklift CDD16-D920 Electric Pallet Trucks Parts Manual PDF

Fig.1 Steering control system
Fig.2 Handle assembly
Fig.3 Switch box assembly
Fig.4 Handle assembly
Fig.5 Switch box assembly
Fig.6 Stepped switch assembly
Fig.7 Driving system
Fig.8 Gear box assembly(old)
Fig.9 Gear box assembly(new)
Fig .10 Driving motor
Fig.11 Hydraulic system
Fig.12 Hydraulic system
Fig.13 Power system(old)
Fig.14 Powersystem(new)
Fig.15 Hydraulic power unit(old)
4′ Fig.16 Hydraulicpowerunit(new)
.-,. Fig.17 Valve assembly(new)
1′ Fig.18 Frame(old)

Fig.19 Frame(new)
Fig.20 Frame
Fig.21 Front wheel assembly
Fig.22 Front wheel assembly(detachable legs)
Fig.23 Balance wheel assembly
Fig.24 Electric panel assembly(old)
~ Fig.25 Electric panel assembly(new)
.Fig.26 Footboard assembly
Fig.27 Mast assy-outer(old)
e- Fig.28 Cylinder assembly(old)
Fig.29 Mast assy-outer(new)
Fig.30 Cylinder assembly(new)
Fig.31 Mast assy-inner
fig.32 Fork & Carriage & Backrest
Fig.33 Compartment(for footboard)
Fig.34 Battery assembly
