DESCRIPTION:

Hidromek HMK 102B Energy Series Backhoe Loader Parts Catalog Manual – PDF DOWNLOAD

FOREWORD:

• This manual has been prepared for ordering spare parts for Hidromek Backhoe Loaders. Spare parts catalogs are
  updated with modifications made on machines according to the developments.
• Due to some reasons this spare part catalog may not contain some of the final revisions. Please contact with authorized services or distributors for spare parts order and updated information.

TABLE OF CONTENTS: (English & Turkish – Both languages present)

Hidromek HMK 102B Energy Series Backhoe Loader Parts Catalog Manual – PDF DOWNLOAD

102B ENERGY YEDEK PARÇA KATALOĞU 1
ÖNSÖZ 2
KATALOG İÇERİĞİ 3
FABRIKA ve BOLGE MUDURLUKLERI 4
PARCA SIPARISI 5
KATALOG KULLANIMI 7
KISALTMALAR 11
MAKINA GENEL GORUNUSU 12
ICINDEKILER 13
A – ATAŞMANLAR 25
A1 – YÜKLEYİCİ ATAŞMANLAR 25
A1-1-1 KEPÇE, AÇILIR 26
A1-2-1 SABİT KEPÇE 28
A1-3-1 SABİT KEPÇE, FORKLİFT APARATLI 30
A1-4-1 AÇILIR KEPÇE, FORKLİFT APARATLI 32
A2- KAZICI ATAŞMANLAR 36
A2-1-1 KEPÇE, KAZICI 37
B – GOVDE 39
B1 – GOVDE MONTAJLARI 39
B1-1-1 ŞASİ 40
B1-2-1 KAPUT- MOTOR YAN KAPAĞI- PANEL- PANJUR- TAMPON- ŞASİ BAĞLANTILARI 42
B1-2-2 MOTOR KAPAĞI, YAN, SAĞ 46
B1-2-3 MOTOR KAPAĞI, YAN, SOL 48
B1-2-4 KAPUT 50
B1-3-1 ŞASİ İLE HİDROLİK ELEMANLARIN BAĞLANTILARI 52
B1-4-1 ŞASİ – KABİN – MOTOR BAĞLANTILARI 54
B1-5-1 DEPO, HİDROLİK YAĞ 56
B1-7-1 DEPO, YAKIT 58
B1-8-1 AKS – ŞASİ BAĞLANTI ELEMANLARI 60
B1-9-1 ÇAMURLUKLAR 62
B2 – KABİN 64
B2-1-1 KABİN 65
B2-1-2 KAPI VE CAMLAR, YAN, SAĞ 67
B2-1-3 KAPI VE CAMLAR, YAN, SOL 69
B2-1-4 CAMLAR, ÖN – ARKA 71
B2-1-5 CAM SİLECEKLERİ VE TESİSATLARI 73
B2-2-1 KABİN İÇ DÖŞEMESİ VE TAVAN 75
B2-3-1 ÖN GÖGÜS 77
B2-3-2 ÖN GÖGÜS GÖSTERGE PANELİ 79
B2-3-3 KUMANDA KOLLARI 81
B2-4-1 YAN GÖGÜS, SAĞ 83
B2-4-2 GÖSTERGE PANELI, YAN GÖĞÜS 85
B2-5-1 YAN GÖGÜS, SOL VE KABİN KONSOLLARI 87
B2-6-1 ARKA KUMANDA MUHAFAZA KUTUSU 89
B2-7-1 KABİN DONANIMI 91
B2-8-1 KOLTUK 93
B2-9-1 RADYO-KASETÇALAR DONANIMI 95
B2-10-1 FAR VE LAMBALAR 97
B2-10-2 STOP LAMBASI- KAZICI YÜKLEYİCİ 99
B3 – YÜKLEYİCİ 101
B3-1-1 YÜKLEYİCİ ATAŞMAN BAĞLANTISI 102
B3-2-1-1-OP1 YUKLEYICI MONTAJI-1 KUTU KESITLI KOL 104
B3-2-1-2-OP1 YUKLEYICI MONTAJI-2 KUTU KESITLI KOL 106
B3-3-1 KEPÇE KONUM MEKANİZMASI 108
B4 – KAZICI 110
B4-1-1 KAZICI GRUBU BAĞLANTILARI 111
B4-2-1 AYAK, KIZAK 113
B4-3-1 TABLA- KUTU- DONUS SILINDIRI BAGLANTILARI 641
B4-3-1-1 TABLA- KUTU- DONUS SILINDIRI BAGLANTILARI 115
B4-3-1-2 TABLA- KUTU- DÖNÜŞ SİLİNDİRİ BAĞLANTILARI 118
B4-3-3 DONUS TABLASI 641
B4-3-3-1 DONUS TABLASI 120
B4-3-3-2 DÖNÜŞ TABLASI 123
B4-3-4 DONUS KUTUSU 641
B4-3-4-OP1 DONUS KUTUSU CELIK 129
B4-3-4-OP2-1 DÖNÜŞ KUTUSU, DÖKÜM 131
B4-3-4-OP2-2 DÖNÜŞ KUTUSU, DÖKÜM 133
B4-4-1 KALDIRICI BOM 135
B4-5-1 DEVİRİCİ BOM- PALET- DEVEBOYNU VE SİLİNDİR BAĞLANTILARI 641
B4-5-1-OP1 DEVİRİCİ BOM- PALET- DEVEBOYNU VE SİLİNDİR BAĞLANTILARI 137
B4-5-1-OP2 DEVİRİCİ BOM- PALET- DEVEBOYNU VE SİLİNDİR BAĞL EŞ MERKEZLİ SİLİNDİR- PALET 139
B4-5-2 BOM, DEVİRİCİ 641
B4-5-2-OP1 BOM, DEVİRİCİ 141
B4-5-2-OP2 BOM, DEVİRİCİ, EŞ MERKEZLİ SİLİNDİR- PALET 143
B4-5-3 TELESKOPİK BOM 641
B4-5-3-OP1 TELESKOPİK BOM 145
B4-5-3-OP2 TELESKOPİK BOM, EŞ MERKEZLİ SİLİNDİR- PALET 147
C – ELEKTRİK 149
C1 – ELEKTRIK DONANIMLARI 149
C1-0-0 ELEKTRİK DEVRE ŞEMASI 150
C1-1-1 SİGORTA- ROLE TABLASI VE YERLEŞİM DÜZENİ 152
C1-1-2 ELEKTRİK DONANIMI, KABİN İÇİ 641
C1-1-2-OP1 ELEKTRİK DONANIMI, KABİN İÇİ, TEK FREN PEDALLI 154
C1-1-2-OP2 ELEKTRİK DONANIMI, KABİN İÇİ, ÇİFT FREN PEDALLI 156
C1-2-1 ELEKTRİK DONANIMI, MOTOR 641
C1-2-1-OP1 ELEKTRİK DONANIMI, MOTOR, TEK FREN PEDALLI 158
C1-2-1-OP2 ELEKTRİK DONANIMI, MOTOR, ÇİFT FREN PEDALLI 160
C1-3-1 ELEKTRİK DONANIMI, ÖN FAR VE SİNYAL 162
C1-4-1 ELEKTRİK DONANIMI, STOP- PARK- SİNYAL LAMBASI VE KIZAK AYAĞI SVİÇ 164
C1-5-1 KIZAK AYAĞI ELEKTRİK ANAHTARI MONTAJI- KORNA VE ROLESİ 166
C1-7-1 AKÜ VE ELEKTRİK BAĞLANTILARI 168
C1-8-1 FAN KABLOSU, KLİMA ÜNİTESİ 170
D – KONTROL 172
D1 – KONTROL MEKANIZMALARI 172
D1-1-1 ÖN KUMANDA MEKANİZMASI 641
D1-1-1-OP1 ÖN KUMANDA MEKANİZMASI- LEVYE KUMANDALI 173
D1-1-1-OP2 ÖN KUMANDA MEKANİZMASI- JOYSTİCK KUMANDALI 175
D1-2-1 ÖN KUMANDA LEVYELERİ 641
D1-2-1-OP1 ÖN KUMANDA LEVYELERİ 177
D1-2-1-OP2 ÖN KUMANDA LEVYELERİ, JOYSTİCK 179
D1-3-1 ARKA KUMANDA MEKANİZMASI 181
D1-4-1 ARKA KUMANDA LEVYELERİ 183
D1-5-1 PEDAL MONTAJI, NB+KT, TB, TB+KT 185
D1-6-1 BOM KİLİDİ VE MEKANİZMASI 641
D1-6-1-1 BOM KİLİDİ VE MEKANİZMASI 187
D1-6-1-2 BOM KİLİDİ VE MEKANİZMASI 191
D2 – MOTOR KONTROL 195
D2-1-1 EL GAZI KOLU VE GAZ PEDALI MEKANİZMASI 196
D2-2-1 EL FRENİ 200
D2-3-1 FREN PEDALI, ASMA AYAK 641
D2-3-1-OP1 FREN PEDALI, ASMA AYAK, TEK PEDALLI 202
D2-3-1-OP2 FREN PEDALI, ASMA AYAK ÇİFT PEDALLI 204
D2-4-1-OP1 KONTROL, DİREKSİYON 641
D2-4-1-OP1 KONTROL, DİREKSİYON 206
D2-4-1-OP2 KONTROL, DİREKSİYON AYARLI 208
E – HIDROLIK 210
E1 – HIDROLIK SISTEM 210
E1-1-1 HİDROLİK, ANA DAĞITIM 211
E1-1-3 HİDROLİK, ANA DAĞITIM, POMPA ORTAK 213
E1-1-4 HİDROLİK, EK TESİSAT, NB 641
E1-1-4-OP1 HİDROLİK, EK TESİSAT, NB, E2-1-1-OP1 ,ILE 215
E1-1-4-OP2 HİDROLİK, EK TESİSAT, NB, E2-1-1-OP2 ,ILE 217
E1-1-5 HİDROLİK, EK TESİSAT, NB+KT 641
E1-1-5-OP1 HİDROLİK, EK TESİSAT, NB+KT, E2-1-1-OP1 ,ILE 219
E1-1-5-OP2 HİDROLİK, EK TESİSAT, NB+KT,A K V, E2-1-1-OP2 İLE 221
E1-1-5-OP3 HİDROLİK, EK TESİSAT, NB+KT+E K K V, E2-1-1-OP1 VE OP2 İLE 223
E1-1-6 HİDROLİK, EK TESİSAT, TB 641
E1-1-6-OP1 HİDROLİK, EK TESİSAT, TB, E2-1-1-OP1 ,ILE 225
E1-1-6-OP2 HİDROLİK, EK TESİSAT, TB, E2-1-1-OP2 ,ILE 227
E1-1-7 HİDROLİK, EK TESİSAT, TB+KT 641
E1-1-7-OP2 HİDROLİK, EK TESİSAT, TB+KT/TB+DK, E2-1-1-OP2, İLE 229
E1-1-7-OP3 HİDROLİK, EK TESİSAT, TB+TK, BUCHER HDS30/2, E2-1-1-OP1, İLE 231
E1-1-7-OP4 HİDROLİK, EK TESİSAT, TB+TK, BUCHER HDS30/2, E2-1-1-OP2 İLE 233
E1-2-1 HİDROLİK, DİREKSİYON 235
E1-3-1 HİDROLİK, FREN 641
E1-3-1-OP1 HİDROLİK, FREN, TEK FREN PEDALLI 237
E1-3-1-OP2 HİDROLİK, FREN, ÇİFT FREN PEDALLI 239
E1-4-1 HİDROLİK, KALDIRICI SİLİNDİR, YÜKLEYİCİ 241
E1-4-2 HİDROLİK, DEVİRİCİ SİLİNDİR, YÜKLEYİCİ 245
E1-4-3 HİDROLİK, AÇILIR KEPÇE TESİSATI, YÜKLEYİCİ 247
E1-4-4 HİDROLİK, SABİT KEPÇE TESİSATI, YÜKLEYİCİ 249
E1-4-5-OP HİDROLİK, SARSINTISIZ YOL YÜRÜYÜŞ, YÜKLEYİCİ 251
E1-5-1 HORTUM TUTUCU SETİ 641
E1-5-1-OP1 HORTUM TUTUCU SETİ, HİDROLİK, NB, KAZICI 253
E1-5-1-OP2 HORTUM TUTUCU SETİ, HİDROLİK, NB+KT, KAZICI 255
E1-5-1-OP3 HORTUM TUTUCU SETİ, HİDROLİK, TB, KAZICI 257
E1-5-1-OP4 HORTUM TUTUCU SETİ, HİDROLİK, TB+KT, KAZICI 259
E1-5-2 HİDROLİK, AYAK SİLİNDİRİ 641
E1-5-2-OP1 HİDROLİK, AYAK SİLİNDİRİ, (DIS 10968, İLERİ AYAK FONK , KİLİT VALFLİ) 261
E1-5-2-OP2 HİDROLİK, AYAK SİLİNDİRİ, (DIS 10968, İLERİ AYAK FONK ,) 263
E1-5-3 HİDROLİK, SIKMA PİSTONU 265
E1-5-4 HİDROLİK, DÖNÜŞ SİLİNDİRİ, (DIS 10968) 267
E1-5-5 HİDROLİK, KALDIRICI SİLİNDİR 641
E1-5-5 HİDROLİK, KALDIRICI SİLİNDİR, (DIS 10968), KAZICI 269
E1-5-5-OP HİDROLİK, KALDIRICI SİLİNDİR, (DIS 10968, EMNİYET VALFLİ), KAZICI 271
E1-5-6 HİDROLİK, DEVİRİCİ SİLİNDİR 641
E1-5-6 HİDROLİK, DEVİRİCİ SİLİNDİR, (DIS 10968), KAZICI 273
E1-5-6-OP HİDROLİK, DEVİRİCİ SİLİNDİR, (DIS 10968, EMNİYET VALFLİ), KAZICI 275
E1-5-7 HİDROLİK, KIVIRICI SİLİNDİR, NB (DIS 10968) 277
E1-5-8 HİDROLİK, KIVIRICI SİLİNDİR, TB (DIS 10968) 279
E1-5-9 HİDROLİK, TELESKOPİK İTİCİ SİLİNDİR 641
E1-5-9-OP1 HİDROLİK, TELESKOPİK İTİCİ SİLİNDİR 281
E1-5-9-OP2 HİDROLİK, TELESKOPİK İTİCİ SİLİNDİR, BUCHER HDS30/2 283
E1-6-1 HİDROLİK, KIRICI TESİSAT, NK 641
E1-6-1-OP1 HİDROLİK, KIRICI TESİSAT, NK, ATAŞMAN KUMANDA VALFİ 285
E1-6-1-OP2 HİDROLİK, KIRICI TESİSAT, NK, ELEKTRİKLİ KIRICI KUMANDA VALFLİ 287
E1-6-2 HİDROLİK, KIRICI TESİSAT, TB 641
E1-6-2-OP1 HİDROLİK, KIRICI TESİSAT, TELESKOPİK BOMLU, SALAMİ VALF 289
E1-6-2-OP2 HİDROLİK, KIRICI TESİSAT, TELESKOPİK BOMLU, BUCHER- HDS30/2 VALF 291
E2 – VALF ve NIPEL BAGLANTILARI 293
E2-1-1 ÖN KUMANDA VALFİ VE NİPELLERİ 641
E2-1-1-OP1 ÖN KUMANDA VALFİ VE NİPELLERİ- LEVYE KUMANDALI 294
E2-1-1-OP2 ÖN KUMANDA VALFİ VE NİPELLERİ- JOYSTİCK KUMANDALI 296
E2-1-2 AKIŞ KONTROL VALFLERİ, YÜKLEYİCİ KUMANDA BLOĞU 298
E2-1-3 KÖRÜK VE KEÇE TAKIMI, YÜKLEYİCİ KUMANDA BLOĞU 300
E2-2-1 ARKA KUMANDA VALFİ VE NİPELLERİ, DIS10968 302
E2-2-2 AKIŞ KONTROL VALFLERİ, KAZICI KUMANDA BLOĞU 304
E2-2-3 KÖRÜK VE KEÇE TAKIMI, KAZICI KUMANDA BLOĞU 306
E2-3-1 ATAŞMAN KUMANDA VALFİ VE NİPELLERİ 641
E2-3-1-OP1 ATAŞMAN KUMANDA VALFİ VE NİPELLERİ, COMMERCIAL 308
E2-3-1-OP2 ATAŞMAN KUMANDA VALFİ VE NİPELLERİ, SALAMI 310
E2-3-1-OP3 ATAŞMAN KUMANDA VALFİ VE NİPELLERİ, BUCHER – HDS30/1 312
E2-3-1-OP4 ATAŞMAN KUMANDA VALFİ VE NİPELLERİ, BUCHER – HDS30/2 314
E2-4-1 PRIORITY VALVE VE NİPELLERİ 316
E2-5-1 HİDROLİK POMPA 641
E2-5-1-OP1 HİDROLİK POMPA, HEMA, (37/29 cc/dev ) 318
E2-5-1-OP2 HİDROLİK POMPA, HEMA, (46/23 cc/dev ) 320
E2-6-1 TOPLAMA TÜPÜ 322
E2-7-1 DİREKSİYON BEYNİ 324
E2-8-1 AKÜMÜLATÖR 326
E2-9-1 FREN PEDAL VALFİ 641
E2-9-1-OP1 FREN PEDAL VALFİ, TEK FREN PEDALLI 328
E2-9-1-OP2 FREN PEDAL VALFİ, ÇİFT FREN PEDALLI 330
E2-10-1 FREN POMPASI 332
E2-12-1-OP ELEKTRİKLİ KIRICI KUMANDA VALFİ & NİPELLER 334
E2-13-1 AYAK SİLİNDİRİ KİLİT VALFİ 336
E2-14-1-OP AKÜMÜLATOR -VALF, SARSINTISIZ YOL YÜRÜYÜŞ SİSTEMİ 338
E2-15-1 DAĞITICI NİPEL, AÇILIR KEPÇE 340
E2-16-1-OP EMNİYET VALFİ, KALDIRICI SİLİNDİR 342
E2-17-1-OP EMNİYET VALFİ, DEVİRİCİ SİLİNDİR 344
E3 – SILINDIRLER 346
E3-1-1 SİLİNDİR, KALDIRICI, SAĞ, YÜKLEYİCİ 347
E3-1-2 SİLİNDİR, KALDIRICI, SOL, YÜKLEYİCİ 349
E3-2-1 SİLİNDİR, DEVİRİCİ, SAĞ, YÜKLEYİCİ 351
E3-2-2 SİLİNDİR, DEVİRİCİ, SOL, YÜKLEYİCİ 353
E3-3-1 SİLİNDİR, AÇILIR KEPÇE, SAĞ – SOL, YÜKLEYİCİ 355
E3-4-1 SİLİNDİR, AYAK, SAĞ 357
E3-4-2 SİLİNDİR, AYAK, SOL 359
E3-5-1 SİLİNDİR, DÖNÜŞ, SAĞ – SOL 641
E3-5-1-1 SİLİNDİR, DÖNÜŞ, SAĞ – SOL 361
E3-5-1-2 SİLİNDİR, DÖNÜŞ, SAĞ – SOL 363
E3-6-1 SİLİNDİR, KALDIRICI, KAZICI 641
E3-6-1 SİLİNDİR, KALDIRICI, KAZICI 365
E3-6-1-OP SİLİNDİR, KALDIRICI, KAZICI, EMNİYET VALFLİ 367
E3-7-1 SİLİNDİR, DEVİRİCİ, KAZICI 641
E3-7-1 SİLİNDİR, DEVİRİCİ, KAZICI 369
E3-7-1-OP SİLİNDİR, DEVİRİCİ, KAZICI, EMNİYET VALFLİ 371
E3-8-1-OP1 SİLİNDİR, KIVIRICI, KAZICI 641
E3-8-1-OP1 SİLİNDİR, KIVIRICI, KAZICI 373
E3-8-1-OP2 SİLİNDİR, KIVIRICI, KAZICI, EŞ MERKEZLİ SİLİNDİR- PALET 375
E3-9-1 SİLİNDİR, TELESKOPİK İTİCİ, KAZICI 377
E3-9-2 SİLİNDİR, TELESKOPİK KIVIRICI, KAZICI 641
E3-9-2-OP1 SİLİNDİR, TELESKOPİK KIVIRICI, KAZICI 379
E3-9-2-OP2 SİLİNDİR, TELESKOPİK KIVIRICI, KAZICI, EŞ MERKEZLİ SİLİNDİR- PALET 381
F – TAHRIK ELEMANLARI 383
F1 – ON AKS 383
F1-1-1 AKS MONTAJI, ÖN (SD 55) 384
F1-2-1 AKS MONTAJI, ÖN, SD 55 386
F1-3-1 AKS BAŞI, ÖN AKS, SD 55 388
F1-4-1 PORYA MONTAJI, ÖN AKS, SD 55 390
F1-5-1 DİFERANSİYEL MONTAJI, ÖN AKS, SD 55 392
F1-6-1 SİLİNDİR, DİREKSİYON, ÖN AKS, SD 55 394
F1-7-1 DİREKSİYON SİLİNDİRİ MONTAJI, ÖN AKS, SD 55 396
F2 – ARKA AKS 398
F2-1-1 KOVAN MONTAJI, ARKA AKS, PD 70 399
F2-2-1 DİFERANSİYEL MONTAJI, ARKA AKS, PD 70 401
F2-3-1 AYNA MAHRUTİ MONTAJI, ARKA AKS, PD 70 403
F2-4-1 FREN SİSTEMİ, ARKA AKS, PD 70 405
F2-6-1 PARK FRENİ, ARKA AKS, PD 70 407
F3 – SANZUMAN 409
F3-1-1 ŞANZUMAN MONTAJI, PS760, 102B 410
F3-2-1 ŞANZUMAN DIŞ ELEMANLARI, PS760, 102B 412
F3-3-1 KAVRAMA, ŞANZUMAN, PS760, 102B 414
F3-4-1 GİRİŞ KAVRAMA, ŞANZUMAN, PS760, 102B 416
F3-5-1 GERİ VİTES KAVRAMA, ŞANZUMAN, PS760, 102B 418
F3-6-1 KAVRAMA- ANA ŞAFT VE ELEMANLARI, ŞANZUMAN, PS760, 102B 420
F3-7-1 KAVRAMA- ARA ŞAFT VE ELEMANLARI, ŞANZUMAN, PS760, 102B 422
F3-8-1 SELENOİD VALF MONTAJI, ŞANZUMAN, PS760, 102B 424
F3-9-1 YAĞ POMPASI, ŞANZUMAN, PS760, 102B 426
F4 – SANZUMAN ELEMANLARI 428
F4-1-1 TORK KONVERTOR, PS760, 102B 429
F5 – TEKER VE SAFTLAR 431
F5-1-1 ÖN- ARKA TEKERLEK 432
F5-2-1 ÖN ŞAFT 434
F5-2-2 ARKA ŞAFT 436
G – MOTOR 438
G1 MOTOR 438
G1-1-1 MOTOR, YEŞİL 2, 1104C-44T, RG38101 439
G1-2-1 SİLİNDİR BLOK VE GÖMLEĞİ, MOTOR 1104C-44T, RG38101 441
G1-2-2 KRANKMİLİ & ANA VE GEZİNTİ YATAKLARI, MOTOR 1104C-44T, RG38101 443
G1-2-3 PİSTON VE SEGMANLAR, MOTOR 1104C-44T, RG38101 445
G1-2-4 BİYEL KOLU, MOTOR 1104C-44T, RG38101 447
G1-2-5 KRANK ARKA KEÇE YUVASI, MOTOR 1104C-44T, RG38101 449
G1-2-6 SİLİNDİR KAPAĞI, MOTOR 1104C-44T, RG38101 451
G1-2-7 KÜLBÜTÖR, MOTOR 1104C-44T, RG38101 453
G1-2-8 EKSANTRİK (KAM) MİLİ, MOTOR 1104C-44T, RG38101 455
G1-3-1 YAKIT PÜSKÜRTME POMPASI, MOTOR 1104C-44T, RG38101 457
G1-3-2 YAKIT BORULARI, MOTOR 1104C-44T, RG38101 459
G1-3-3 ENJEKTÖRLER, MOTOR 1104C-44T, RG38101 461
G1-3-4 SOĞUK ÇALIŞTIRMA MÜŞÜRÜ, MOTOR 1104C-44T, RG38101 463
G1-3-5 YAKIT BESLEME KONTROL BORUSU, MOTOR 1104C-44T, RG38101 465
G1-3-6 YAKIT SIZINTI BORUSU, MOTOR 1104C-44T, RG38101 467
G1-3-7 İLK HAREKET MÜŞÜRÜ, MOTOR 1104C-44T, RG38101 469
G1-4-1 VOLAN VE MARŞ DİŞLİSİ, MOTOR 1104C-44T, RG38101 471
G1-5-1 MARŞ MOTORU, MOTOR 1104C-44T, RG38101 473
G1-6-1 FAN KASNAĞI BAĞLANTISI, MOTOR 1104C-44T, RG38101 475
G1-6-2 FAN KASNAK VE KAYIŞI, MOTOR 1104C-44T, RG38101 477
G1-7-1 KARTER, MOTOR 1104C-44T, RG38101 479
G1-7-3 YAĞ EMİŞ BORUSU, MOTOR 1104C-44T, RG38101 481
G1-8-1 KÜLBÜTÖR KAPAĞI, MOTOR 1104C-44T, RG38101 483
G1-8-2 KÜLBÜTÖR KAPAĞI, MOTOR 1104C-44T, RG38101 485
G1-8-3 YAĞ DOLDURMA BORUSU, MOTOR 1104C-44T, RG38101 487
G1-8-4 HAVALANDIRMA, MOTOR 1104C-44T, RG38101 489
G1-9-1 YAĞ SOĞUTUCU, MOTOR 1104C-44T, RG38101 491
G1-9-2 YAĞ FİLTRESİ, MOTOR 1104C-44T, RG38101 493
G1-9-3 KÖR KAPAK, MOTOR 1104C-44T, RG38101 495
G1-10-1 YAĞ FİLTRESİ, MOTOR 1104C-44T, RG38101 497
G1-11-1 KRANK KASNAĞI, MOTOR 1104C-44T, RG38101 499
G1-12-1 SU POMPASI, MOTOR 1104C-44T, RG38101 501
G1-12-2 SU POMPASI, MOTOR 1104C-44T, RG38101 503
G1-12-3 BORU, MOTOR 1104C-44T, RG38101 505
G1-13-1 TERMOSTAT VE BAĞLANTISI, MOTOR 1104C-44T, RG38101 507
G1-14-1 FAN BAĞLANTISI, MOTOR 1104C-44T, RG38101 509
G1-15-1 ALTERNATÖR, MOTOR 1104C-44T, RG38101 511
G1-15-2 ALTERNATÖR BAĞLANTILARI, MOTOR 1104C-44T, RG38101 513
G1-15-3 KASNAK, ALTERNATÖR, MOTOR 1104C-44T, RG38101 515
G1-16-1 YARDIMCI KASNAK, MOTOR 1104C-44T, RG38101 517
G1-17-1 ZAMANLAMA DİŞLİSİ MUHAFAZASI, MOTOR 1104C-44T, RG38101 519
G1-17-2 ZAMANLAMA DİŞLİSİ MUHAFAZASI, MOTOR 1104C-44T, RG38101 521
G1-17-3 ZAMANLAMA DİŞLİSİ KAPAĞI, MOTOR 1104C-44T, RG38101 523
G1-18-1 ADAPTÖR, MOTOR 1104C-44T, RG38101 525
G1-18-2 TAPA, MOTOR 1104C-44T, RG38101 527
G1-19-1 YAĞ POMPASI, MOTOR 1104C-44T, RG38101 529
G1-20-1 TÜRBOŞARJ, MOTOR 1104C-44T, RG38101 531
G1-20-2 BESLEME BORUSU, MOTOR 1104C-44T, RG38101 533
G1-20-3 SIZINTI BORUSU, MOTOR 1104C-44T, RG38101 535
G1-20-4 BORU VE BAĞLANTILARI, MOTOR 1104C-44T, RG38101 537
G1-20-5 EGSOZ MANİFOLDU, MOTOR 1104C-44T, RG38101 539
G1-20-6 EGSOZ DİRSEĞİ VE BAĞLANTILARI, MOTOR 1104C-44T, RG38101 541
G1-21-1 BAĞLANTILAR, MOTOR 1104C-44T, RG38101 543
G1-22-1 YAKIT TRANSFER POMPASI, MOTOR 1104C-44T, RG38101 545
G1-22-2 YAKIT BESLEME BORUSU, MOTOR 1104C-44T, RG38101 547
G1-22-3 BORU, PÜSKÜRTME POMPASI-YAKIT FİLTRESİ, MOTOR 1104C-44T, RG38101 549
G1-23-1 ISITMA BUJİSİ, MOTOR 1104C-44T, RG38101 551
G1-24-1 MOTOR KALDIRMA KULAKLARI, MOTOR 1104C-44T, RG38101 553
G1-25-1 YAĞ BASINÇ MÜŞÜRÜ, MOTOR 1104C-44T, RG38101 555
G1-25-2 YAĞ BASINÇ ÖLÇÜMÜ/BASINÇ HATTI, MOTOR 1104C-44T, RG38101 557
G1-26-1 SU HARARET MÜŞÜRÜ, MOTOR 1104C-44T, RG38101 559
G1-27-1 YARDIMCI DONANIMLAR, MOTOR 1104C-44T, RG38101 561
G1-27-2 YARDIMCİ DONANIMLAR, MOTOR 1104C-44T, RG38101 563
G1-28-1 ÜST CONTA TAMİR TAKIMI, MOTOR 1104C-44T, RG38101 565
G1-29-1 ALT CONTA TAMİR TAKIMI, MOTOR 1104C-44T, RG38101 567
G2 MOTOR MONTAJLARI 569
G2-1-1 MOTOR MONTAJI, YEŞİL 2 570
G2-1-2 MOTOR- ŞANZUMAN MONTAJI 572
G2-2-1 HAVA FİLTRESİ BAGLANTILARI 574
G2-2-3-OP YAĞLI FİLTRE 576
G2-3-1 YAKIT EMIS VE DONUS TESİSATI 578
G2-4-1 EGZOZ MONTAJI -YEŞİL 2 MOTOR 580
G2-5-1 KOMPRESÖR MONTAJI, KLİMALI, YEŞİL 2 MOTOR 582
H – ISITMA VE SOGUTMA 584
H1 – ISITMA ve SOGUTMA 584
H1-1-1 RADYATÖR-YAĞ SOĞUTUCU VE BAĞLANTILARI 585
H1-2-1 SOĞUTMA SİSTEMİ, MOTOR SUYU 587
H1-3-1 SOGUTMA SİSTEMİ, HİDROLİK VE ŞANZUMAN YAĞI 589
H1-4-1 KALORİFER, ISITMA SİSTEMİ 593
H1-5-1 KLİMA, SOĞUTMA SİSTEMİ 595
H1-6-1 KLİMA, KABİN DONANIMI, SOĞUTMA SİSTEMİ 597
K – ETIKET VE LEVHALAR 601
K1 – ETIKET ve LEVHALAR 0
K1-1-1 ETİKET VE LEVHALAR, KULLANIM VE BAKIM 602
K1-2-1 ETİKETLER, UYARI 604
K1-3-1 ETİKET VE LEVHALAR, MAKİNA MODELİ VE BİLGİ 606
PARCA NUMARASINA GORE ICINDEKILER 608
EK 2 631
EK 3 637
EK 4 639
102B SPARE PARTS CATALOG 1
FOREWORD 2
CONTENTS OF THE CATALOG 3
PART ORDERING 6
USE OF CATALOG 9
ABBREVIATIONS 11
MACHINE OVERVIEW 12
CONTENTS 19
A – ATTACHMENTS 25
A1 – LOADER ATTACHMENTS 25
A1-1-1 SHOVEL, CLAM, 4 IN 1 MULTIPURPOSE 26
A1-2-1 SHOVEL 28
A1-3-1 SHOVEL, FORKLIFT MOUNTED 30
A1-4-1 SHOVEL, CLAM, FORKLIFT MOUNTED 32
A2 – BACKHOE ATTACHMENTS 36
A2-1-1 BUCKET, BACKHOE 37
B – BODY 39
B1 – BODY PARTS MOUNTING 39
B1-1-1 CHASSIS 40
B1-2-1 BONNET- ENGINE PANEL- NOSE GUARD- BUMPER- FRONT GRILLE CHASSIS MOUNT 42
B1-2-2 PANEL, ENGINE, RIGHT SIDE 46
B1-2-3 PANEL, ENGINE, LEFT SIDE 48
B1-2-4 BONNET 50
B1-3-1 CHASSIS AND HYDRAULIC COMPONENTS MOUNTINGS 52
B1-4-1 CHASSIS – CAB – ENGINE MOUNTINGS 54
B1-5-1 TANK, HYDRAULIC 56
B1-7-1 TANK, FUEL 58
B1-8-1 AXLE – CHASSIS MOUNTINGS 60
B1-9-1 FENDERS 62
B2 – OPERATOR CAB 64
B2-1-1 OPERATOR CAB 65
B2-1-2 DOOR AND WINDOW, SIDE, RIGHT 67
B2-1-3 DOOR AND WINDOW, SIDE, LEFT 69
B2-1-4 WINDOWS, FRONT – REAR 71
B2-1-5 WIPER SYSTEM 73
B2-2-1 CAB INTERIOR TRIMMING AND ROOF 75
B2-3-1 COVER, FRONT, CONTROL 77
B2-3-2 INSTRUMENT PANEL, FRONT, CONTROL COVER 0
B2-3-3 CONTROL LEVERS 81
B2-4-1 COVER, SIDE, RIGHT 83
B2-4-2 INSTRUMENT PANEL, SIDE, RIGHT 0
B2-5-1 COVER, SIDE, LEFT AND CAB CONSOLES 87
B2-6-1 PROTECTION COVER, BACKHOE CONTROL MECHANISM 89
B2-7-1 ACCESSORIES, OPERATOR CAB 91
B2-8-1 OPERATOR SEAT 93
B2-9-1 RADIO-CASETTE PLAYER SYSTEM 95
B2-10-1 LIGHTS 97
B2-10-2 REAR LIGHTING UNIT, BACKHOE LOADER 99
B3 – LOADER 101
B3-1-1 LOADER ATTACHMENT MOUNTING 102
B3-2-1-1-OP1 LOADER MOUNTING-1, LOADER ARM WITH BOX SECTION 104
B3-2-1-2-OP1 LOADER MOUNTING-2, LOADER ARM WITH BOX SECTION 106
B3-3-1 SHOVEL LEVELLING MECHANISM 108
B4 – BACKHOE 110
B4-1-1 MOUNTINGS, BACKHOE COMPONENTS 111
B4-2-1 STABILISER, SIDESHIFT 113
B4-3-1 KINGPOST, CARRIAGE- SLEW/ SWING RAM MOUNTING 641
B4-3-1-1 KINGPOST, CARRIAGE- SLEW/ SWING RAM MOUNTING 115
B4-3-1-2 KINGPOST, CARRIAGE- SLEW/ SWING RAM MOUNTING 118
B4-3-3 KINGPOST CARRIAGE 641
B4-3-3-1 KINGPOST CARRIAGE 120
B4-3-3-2 KINGPOST CARRIAGE 123
B4-3-4 KINGPOST 641
B4-3-4-OP1 KINGPOST, STEEL 129
B4-3-4-OP2-1 KINGPOST, CASTING 131
B4-3-4-OP2-2 KINGPOST, CASTING 133
B4-4-1 MAIN BOOM 135
B4-5-1 DIPPER- TIPPING LINK- TIPPING LEVER AND RAM MOUNTINGS 641
B4-5-1-OP1 DIPPER- TIPPING LINK- TIPPING LEVER AND RAM MOUNTINGS 137
B4-5-1-OP2 DIPPER- TIPPING LINK/ LEVER- RAM MOUNT , COMMON CENTERED RAM & TIPPING LINK 139
B4-5-2 DIPPER 641
B4-5-2-OP1 DIPPER 141
B4-5-2-OP2 DIPPER, COMMON CENTERED RAM AND TIPPING LINK 143
B4-5-3 DIPPER, TELESCOPIC 641
B4-5-3-OP1 DIPPER, TELESCOPIC 145
B4-5-3-OP2 TELESCOPIC DIPPER, COMMON CENTERED RAM AND TIPPING LINK 147
C – ELECTRIC 149
C1 – HARNESS, ELECTRIC 149
C1-0-0 ELECTRIC CIRCUIT DIYAGRAM 151
C1-1-1 FUSE BOX & RELAYS AND LAYOUT 152
C1-1-2 HARNESS, CAB 641
C1-1-2-OP1 HARNESS, CAB, SINGLE BRAKE PEDAL 154
C1-1-2-OP2 HARNESS, CAB, DOUBLE BRAKE PEDAL 156
C1-2-1 HARNESS, ENGINE 641
C1-2-1-OP1 HARNESS, ENGINE, SINGLE BRAKE PEDAL 158
C1-2-1-OP2 HARNESS, ENGINE, DOUBLE BRAKE PEDAL 160
C1-3-1 HARNESS, HEADLIGHTS & TURN INDICATOR 162
C1-4-1 HARNESS, REAR LIGHTING UNIT & STABILISER SWITCH 164
C1-5-1 STABILISER SWITCH ASSEMBLY & WARNING HORN & RELAY 166
C1-7-1 ACCUMULATOR AND ELECTRIC CONNECTIONS 168
C1-8-1 FAN CABLE, AIR CONDITIONER 170
D – CONTROL 172
D1 – CONTROL MECHANISM 172
D1-1-1 CONTROL MECHANISM, LOADER 641
D1-1-1-OP1 CONTROL MECHANISM, LOADER- WITH LEVER CONTROL 173
D1-1-1-OP2 LOADER CONTROL VALVE BLOCK AND ADAPTERS- WITH JOYSTICK CONTROL 175
D1-2-1 CONTROL LEVERS, LOADER 641
D1-2-1-OP1 CONTROL LEVERS, LOADER 177
D1-2-1-OP2 CONTROL LEVERS, LOADER, JOYSTICK 179
D1-3-1 CONTROL MECHANISM, BACKHOE 181
D1-4-1 CONTROL LEVERS, BACKHOE 183
D1-5-1 PEDAL MOUNTING, NB+KT, TB, TB+KT- WITH SALAMI VALVE 185
D1-6-1 BOOM LOCKING AND MECHANISM 641
D1-6-1-1 BOOM LOCKING AND MECHANISM 187
D1-6-1-2 BOOM LOCKING AND MECHANISM 191
D2 – CONTROL, ENGINE 195
D2-1-1 HAND THROTTLE AND ACCELERATOR PEDAL 196
D2-2-1 PARKING BRAKE 200
D2-3-1 PEDAL, BRAKE, SUSPENDED 202
D2-3-1-OP1 PEDAL, BRAKE, SUSPENDED, SINGLE 202
D2-3-1-OP2 PEDAL, BRAKE, SUSPENDED,DOUBLE 204
D2-4-1 STEERING COLUMN 0
D2-4-1-OP1 STEERING COLUMN 0
D2-4-1-OP2 STEERING COLUMN ADJUSTABLE 0
E – HYDRAULIC 210
E1 – HYDRAULIC SYSTEM 210
E1-1-1 CIRCIUT, HYDRAULIC 211
E1-1-3 CIRCIUT, HYDRAULIC, PUMP, COMMON 213
E1-1-4 CIRCUIT, HYDR , ADDITIONAL, NB 641
E1-1-4-OP1 CIRCUIT, HYDR , ADDITIONAL, NB, WITH E2-1-1-OP1 215
E1-1-4-OP2 CIRCUIT, HYDR , ADDITIONAL, NB, WITH E2-1-1-OP2 217
E1-1-5 CIRCUIT, HYDR , ADDITIONAL, NB+KT 641
E1-1-5-OP1 CIRCUIT, HYDR , ADDITIONAL, NB+KT, A K V , WITH E2-1-1-OP1 219
E1-1-5-OP2 CIRCUIT, HYDR , ADDITIONAL, NB+KT, A K V, WITH E2-1-1-OP2 221
E1-1-5-OP3 CIRCUIT, HYDR , ADDITIONAL, NB+KT+E K K V, WITH E2-1-1-OP1&OP2 223
E1-1-6 CIRCUIT, HYDR , ADDITIONAL, TB 641
E1-1-6-OP1 CIRCUIT, HYDR , ADDITIONAL, TB, WITH E2-1-1-OP1 225
E1-1-6-OP2 CIRCUIT, HYDR , ADDITIONAL, TB, WITH E2-1-1-OP2 227
E1-1-7 CIRCIUT, HYDR , ADDITIONAL, TB+KT 641
E1-1-7-OP2 CIRCIUT, HYDR , ADDITIONAL, TB+KT/TB+DK, WITH E2-1-1-OP2 229
E1-1-7-OP3 CIRCUIT, HYDR , ADD , TB+KT, BUCHER HDS30/2, WITH E2-1-1-OP1 231
E1-1-7-OP4 CIRCUIT, HYDR , ADD , TB+KT, BUCHER HDS30/2, WITH E2-1-1-OP2 233
E1-2-1 CIRCIUT, HYDRAULIC STEERING 235
E1-3-1-OP1 CIRCIUT, HYDRAULIC BRAKE, WITH SINGLE BRAKE PEDAL 237
E1-3-1-OP2 CIRCUIT HYDRAULIC BRAKE WITH SINGLE BRAKE PEDAL 239
E1-4-1 CIRCUIT, RAM, LIFT, LOADER 241
E1-4-2 CIRCUIT, RAM, SHOVEL, LOADER 245
E1-4-3 HYDRAULIC, CLAMSHOVEL INSTALLATION, LOADER 247
E1-4-4 HYDRAULIC, SHOVEL INSTALLATION, LOADER 249
E1-4-5-OP HYDRAULIC, SOFT DRIVE SYSTEM, LOADER 251
E1-5-1 HOSE HOLDER SET, HYDRAULIC 641
E1-5-1-OP4 HOSE HOLDER SET, HYDRAULIC, TB+KT, BACKHOE 259
E1-5-1-OP3 HOSE HOLDER SET, HYDRAULIC, TB, BACKHOE 257
E1-5-1-OP1 HOSE HOLDER SET, HYDRAULIC, NB, BACKHOE 253
E1-5-1-OP2 HOSE HOLDER SET, HYDRAULIC, NB+KT, BACKHOE 255
E1-5-2 HYDRAULIC, RAM, STABILISER 641
E1-5-2-OP1 HYDRAULIC, RAM, STABILISER (DIS10968, FWD STABILISER F , WITH VALVE) 261
E1-5-2-OP2 HYDRAULIC, RAM, STABILISER (DIS10968, FWD STABILISER F ,) 263
E1-5-3 HYDRAULIC, HYDROCLAMP 265
E1-5-4 HYDRAULIC, RAM, SLEW/SWING, (DIS10968) 267
E1-5-5 HYDRAULIC, RAM, MAIN BOOM 641
E1-5-5 HYDRAULIC, RAM, MAIN BOOM, (DIS10968), BACKHOE 269
E1-5-5-OP HYDR , RAM, MAIN BOOM, (DIS 10968, WITH PROTECTION VALVE), BACKHOE 271
E1-5-6 HYDRAULIC, RAM, DIPPER 641
E1-5-6 HYDRAULIC, RAM, DIPPER, (DIS10968), BACKHOE 273
E1-5-6-OP HYDR , RAM, DIPPER, (DIS 10968, WITH PROTECTION VALVE), BACKHOE 275
E1-5-7 HYDRAULIC, RAM, BUCKET, NB, (DIS 10968) 277
E1-5-8 HYDRAULIC, RAM, BUCKET, TB, (DIS10968) 279
E1-5-9 HYDRAULIC, RAM, EXTENSION, TELESCOPIC 641
E1-5-9-OP1 HYDRAULIC, RAM, EXTENSION, TELESCOPIC 281
E1-5-9-OP2 HYDRAULIC, RAM, EXTENSION, TELESCOPIC, BUCHER HDS30/2 283
E1-6-1 HYDRAULIC, BREAKER INSTALATION, NK 641
E1-6-1-OP1 HYDRAULIC, BREAKER INSTALATION, NK, WITH ATTACHMENT CONTROL VALVE 285
E1-6-1-OP2 HYDRAULIC, BREAKER INSTALATION, NK, WITH ELECTRIC BREAKER CONTROL VALVE 287
E1-6-2 HYDRAULIC, BREAKER INSTALLATION, TELESCOPIC BOOM 641
E1-6-2-OP1 HYDRAULIC, BREAKER INSTALLATION, TELESCOPIC BOOM, SALAMI VALVE 289
E1-6-2-OP2 HYDRAULIC, BREAKER INSTALLATION, TELESCOPIC BOOM, BUCHER- HDS30/2 VALVE 291
E2 – VALVE & ADAPTER MOUNTINGS 293
E2-1-1 LOADER CONTROL VALVE BLOCK AND ADAPTERS 641
E2-1-1-OP1 LOADER CONTROL VALVE BLOCK AND ADAPTERS- WITH LEVER CONTROL 294
E2-1-1-OP2 LOADER CONTROL VALVE BLOCK AND ADAPTERS- WITH JOYSTICK CONTROL 296
E2-1-2 FLOW CONTROL VALVES, LOADER CONTROL BLOCK 298
E2-1-3 BOOT ASSEMBLY AND SEAL KIT, LOADER CONTROL BLOCK 300
E2-2-1 BACKHOE CONTROL VALVE BLOCK AND ADAPTERS, DIS10968 302
E2-2-2 FLOW CONTROL VALVES, BACKHOE CONTROL BLOCK 304
E2-2-3 BOOT ASSEMBLY AND SEAL KIT, BACKHOE CONTROL BLOCK 306
E2-3-1 ATTACHMENT CONTROL VALVE AND ADAPTERS 641
E2-3-1-OP1 ATTACHMENT CONTROL VALVE AND ADAPTERS, COMMERCIAL 308
E2-3-1-OP2 ATTACHMENT CONTROL VALVE AND ADAPTERS, SALAMI 310
E2-3-1-OP3 ATTACHMENT CONTROL VALVE AND ADAPTERS, BUCHER – HDS30/1 312
E2-3-1-OP4 ATTACHMENT CONTROL VALVE AND ADAPTERS, BUCHER – HDS30/2 314
E2-4-1 PRIORITY VALVE AND ADAPTERS 316
E2-5-1 PUMP, HYDRAULIC 641
E2-5-1-OP1 PUMP, HYDRAULIC, HEMA, ( 37/29 cc/rev ) 318
E2-5-1-OP2 PUMP, HYDRAULIC, HEMA, ( 46/23 cc/rev ) 320
E2-6-1 TUBE, COLLECTOR 322
E2-7-1 STEERING CONTROL 324
E2-8-1 ACCUMULATOR 326
E2-9-1 VALVE, BRAKE PEDAL 641
E2-9-1-OP2 VALVE, BRAKE PEDAL, WITH DOUBLE BRAKE PEDAL 330
E2-9-1-OP1 VALVE, BRAKE PEDAL, WITH SINGLE BRAKE PEDAL 328
E2-10-1 PUMP, BRAKE 332
E2-12-1-OP ELECTRIC BREAKER CONTROL VALVE & ADAPTERS 334
E2-13-1 OVER CENTRE VALVE, STABILISER RAM 336
E2-14-1-OP ACCUMULATOR-VALVE, SOFT DRIVE SYSTEM 338
E2-15-1 ADAPTER ASSY , CLAMSHOVEL 340
E2-16-1-OP PROTECTION VALVE, MAIN BOOM RAM 342
E2-17-1-OP PROTECTION VALVE, DIPPER RAM 344
E3 – RAMS 346
E3-1-1 RAM, LIFT, RIGHT, LOADER 347
E3-1-2 RAM, LIFT, LEFT, LOADER 349
E3-2-1 RAM, SHOVEL, RIGHT, LOADER 0
E3-2-2 RAM, SHOVEL, LEFT, LOADER 353
E3-3-1 RAM, CLAMSHOVEL, RIGHT – LEFT, LOADER 355
E3-4-1 RAM, STABILISER, RIGHT 357
E3-4-2 RAM, STABILISER, LEFT 359
E3-5-1 RAM, SLEW / SWING, RIGHT – LEFT 641
E3-5-1-1 RAM, SLEW / SWING, RIGHT – LEFT 361
E3-5-1-2 RAM, SLEW / SWING, RIGHT – LEFT 363
E3-6-1 RAM, MAIN BOOM, BACKHOE 641
E3-6-1 RAM, MAIN BOOM, BACKHOE 365
E3-6-1-OP RAM, MAIN BOOM, BACKHOE, WITH PROTECTION VALVE 367
E3-7-1 RAM, DIPPER, BACKHOE 641
E3-7-1 RAM, DIPPER, BACKHOE 369
E3-7-1-OP RAM, DIPPER, BACKHOE, WITH PROTECTION VALVE 371
E3-8-1 RAM, BUCKET, BACKHOE 641
E3-8-1-OP1 RAM, BUCKET, BACKHOE 373
E3-8-1-OP2 RAM, BUCKET, BACKHOE, COMMON CENTERED RAM AND TIPPING LINK 375
E3-9-1 RAM, EXTENSION, TELESCOPIC DIPPER, BACKHOE 377
E3-9-2 RAM, BUCKET, TELESCOPIC DIPPER, BACKHOE 641
E3-9-2-OP1 RAM, BUCKET, TELESCOPIC DIPPER, BACKHOE 379
E3-9-2-OP2 RAM, BUCKET, TELESCOPIC DIPPER, BACKHOE, COMMON CENTERED RAM & TIPPING LINK 381
F – TRANSMISSION COMPONENTS 383
F1 – FRONT AXLE 383
F1-1-1 AXLE ASSEMBLY, FRONT (SD 55) 384
F1-2-1 AXLE ASSEMBLY, FRONT (SD 55) 386
F1-3-1 KNUCKLE, FRONT AXLE (SD 55) 388
F1-4-1 HUB & COMPENENTS, FRONT AXLE (SD 55) 390
F1-5-1 DIFFERENTIAL, FRONT AXLE (SD 55) 392
F1-6-1 RAM, STEERING, FRONT AXLE, SD 55 394
F1-7-1 POWER TRACKROD, FRONT AXLE (SD 55) 396
F2 – REAR AXLE 398
F2-1-1 AXLE, DRIVE ASSEMBLY, REAR AXLE(PD 70) 399
F2-2-1 DIFFERENTIAL ASSEMBLY, REAR AXLE (PD 70) 401
F2-3-1 CROWN WHEEL & PINION, REAR AXLE (PD 70) 403
F2-4-1 BRAKES, REAR AXLE (PD 70) 405
F2-6-1 BRAKE, PARKING REAR AXLE, (PD 70) 407
F3 – TRANSMISSION 409
F3-1-1 TRANSMISSION ASSY, PS760, 102B 410
F3-2-1 TRANSMISSION, EXTERNAL COMPONENTS, PS 760, 102B 412
F3-3-1 CLUTCH UNIT, TRANSMISSION, PS760, 102B 414
F3-4-1 CLUTCH INPUT, TRANSMISSION, PS760, 102B 416
F3-5-1 CLUTCH REVERSE, TRANSMISSION, PS760, 102B 418
F3-6-1 CLUTCH-MAIN SHAFT&COMPONENTS, TRANSMISSION, PS760, 102B 420
F3-7-1 CLUTCH-LAYSHAFT&COMPONENTS, TRANSMISSION, PS760, 102B 422
F3-8-1 SELENOID SWITCHES+PIPEWORK, TRANSMISSION, PS760, 102B 424
F3-9-1 PUMP, TRANSMISSION, PS760, 102B 426
F4 – TRANSMISSION COMPONENTS 428
F4-1-1 TORQUE CONVERTER, PS760 0
F5 – WHEELS & SHAFTS 431
F5-1-1 WHEEL & TYRE ASSEMBLY, FRONT& REAR 432
F5-2-1 PROPSHAFT, TRANSMISSION TO FRONT AXLE 434
F5-2-2 PROPSHAFT, TRANSMISSION TO REAR AXLE 436
G – ENGINE 438
G1 – ENGINE 438
G1-1-1 ENGINE, GREEN 2, 1104C-44T, RG38101 439
G1-2-1 CYLINDER BLOCK &LINERS, ENGINE 1104C-44T, RG38101 441
G1-2-2 CRANKSHAFT MAIN & BIG END BEARINGS , ENGINE 1104C-44T, RG38101 443
G1-2-3 PISTONS & RINGS, ENGINE 1104C-44T, RG38101 445
G1-2-4 CONNECTING RODS, ENGINE 1104C-44T, RG38101 447
G1-2-5 REAR END OIL SEAL, ENGINE 1104C-44T, RG38101 449
G1-2-6 CYLINDER HEAD ASSY, ENGINE 1104C-44T, RG38101 451
G1-2-7 ROCKER ASSEMBLY, ENGINE 1104C-44T, RG38101 453
G1-2-8 TIMING GEAR & CAM SHAFT, ENGINE 1104C-44T, RG38101 455
G1-3-1 FUEL INJECTION PUMP, ENGINE 1104C-44T, RG38101 457
G1-3-2 HIGH PRESSURE FUEL PIPES, ENGINE 1104C-44T, RG38101 459
G1-3-3 ATOMISERS, ENGINE 1104C-44T, RG38101 461
G1-3-4 PICK-UP SENSOR, ENGINE 1104C-44T, RG38101 463
G1-3-5 BOOST CONTROL PIPE, ENGINE 1104C-44T, RG38101 465
G1-3-6 FUEL LEAK-OFF PIPE, ENGINE 1104C-44T, RG38101 467
G1-3-7 PICK-UP SENSOR, ENGINE 1104C-44T, RG38101 469
G1-4-1 FLYWHEEL & STARTER RING, ENGINE 1104C-44T, RG38101 471
G1-5-1 STARTER MOTOR, ENGINE 1104C-44T, RG38101 473
G1-6-1 FAN DRIVE, ENGINE 1104C-44T, RG38101 475
G1-6-2 PULLEYS, ENGINE 1104C-44T, RG38101 477
G1-7-1 SUMP, ENGINE 1104C-44T, RG38101 479
G1-7-3 OIL STRAINER, ENGINE 1104C-44T, RG38101 481
G1-8-1 CYLINDER HEAD COVER, ENGINE 1104C-44T, RG38101 483
G1-8-2 CYLINDER HEAD COVER, ENGINE 1104C-44T, RG38101 485
G1-8-3 FILLER, ENGINE 1104C-44T, RG38101 487
G1-8-4 BREATHER, ENGINE 1104C-44T, RG38101 489
G1-9-1 OIL COOLER, ENGINE 1104C-44T, RG38101 491
G1-9-2 OIL FILTER, ENGINE 1104C-44T, RG38101 493
G1-9-3 BLANKING PLATES, ENGINE 1104C-44T, RG38101 495
G1-10-1 REMOTE LUBRICATING OIL FILTER, ENGINE 1104C-44T, RG38101 497
G1-11-1 FRONT END DRIVE INPUT, ENGINE 1104C-44T, RG38101 499
G1-12-1 WATER PUMP, ENGINE 1104C-44T, RG38101 501
G1-12-2 WATER PUMP, ENGINE 1104C-44T, RG38101 503
G1-12-3 PIPES, ENGINE 1104C-44T, RG38101 505
G1-13-1 WATER OUTLET HOUSING, ENGINE 1104C-44T, RG38101 507
G1-14-1 FAN, ENGINE 1104C-44T, RG38101 509
G1-15-1 ALTERNATOR, ENGINE 1104C-44T, RG38101 511
G1-15-2 ALTERNATOR BRACKET & FIXINGS, ENGINE 1104C-44T, RG38101 513
G1-15-3 PULLEYS, ENGINE 1104C-44T, RG38101 515
G1-16-1 AUXILIARY DRIVE, ENGINE 1104C-44T, RG38101 517
G1-17-1 TIMING CASE, ENGINE 1104C-44T, RG38101 519
G1-17-2 TIMING CASE, ENGINE 1104C-44T, RG38101 521
G1-17-3 TIMING COVER, ENGINE 1104C-44T, RG38101 523
G1-18-1 DRIVE ADAPTOR, ENGINE 1104C-44T, RG38101 525
G1-18-2 BLANKING PLUGS, ENGINE 1104C-44T, RG38101 527
G1-19-1 LUBRICATIG OIL PUMP & DELIVERY HOUSING, ENGINE 1104C-44T, RG38101 529
G1-20-1 TURBOCHARGER, ENGINE 1104C-44T, RG38101 531
G1-20-2 FEED PIPES, ENGINE 1104C-44T, RG38101 533
G1-20-3 LEAK-OFF PIPES, ENGINE 1104C-44T, RG38101 535
G1-20-4 PIPEWORK & CONNECTIONS, ENGINE 1104C-44T, RG38101 537
G1-20-5 EXHAUST MANIFOLD, ENGINE 1104C-44T, RG38101 539
G1-20-6 PIPEWORK & CONNECTIONS, ENGINE 1104C-44T, RG38101 541
G1-21-1 PIPEWORK & CONNECTION, ENGINE 1104C-44T, RG38101 543
G1-22-1 LIFT PUMP, ENGINE 1104C-44T, RG38101 545
G1-22-2 FILTER TO INJECTION PUMP PIPE, ENGINE 1104C-44T, RG38101 547
G1-22-3 INJECTION PUMP TO FILTER PIPE, ENGINE 1104C-44T, RG38101 549
G1-23-1 HEATER PLUGS, ENGINE 1104C-44T, RG38101 551
G1-24-1 ENGINE LIFTING EYES, ENGINE 1104C-44T, RG38101 553
G1-25-1 LUBRICATION OIL PRESSURE SWITCH/GAUGE, ENGINE 1104C-44T, RG38101 555
G1-25-2 LUBRICATION OIL PRESSURE SWITCH/GAUGE, ENGINE 1104C-44T, RG38101 557
G1-26-1 TEMPERATURE GAUGE & SENDER, ENGINE 1104C-44T, RG38101 559
G1-27-1 MISCALLANEOUS & AUXILIARIES, ENGINE 1104C-44T, RG38101 561
G1-27-2 MISCELLANEOUS & AUXILIARIES, ENGINE 1104C-44T, RG38101 563
G1-28-1 TOP SERVICE KIT, ENGINE 1104C-44T, RG38101 565
G1-29-1 BOTTOM SERVICE KIT, ENGINE 1104C-44T, RG38101 567
G2 – ENGINE ASSEMBLY 569
G2-1-1 ENGINE ASSEMBLY, GREEN 2 570
G2-1-2 ENGINE & TRANSMISSION ASSEMBLY 572
G2-2-1 AIR FILTER AND MOUNTING 574
G2-2-3-OP AIR FILTER AND PRE-CLEANER, WITH OIL 576
G2-3-1 FUEL SUCTION AND RETURN LINE 578
G2-4-1 EXHAUST ASSEMBLY – GREEN 2 ENGINE 580
G2-5-1 COMPRESSOR ASSEMBLY, WITH AIR CONDITIONER, GREEN 2 ENGINE 582
H – HEATING AND COOLING 584
HEATING AND COOLING 0
H1-1-1 RADIATOR-OIL COOLER AND FITTINGS 585
H1-2-1 COOLING SYSTEM, ENGINE WATER 587
H1-3-1 COOLING SYSTEM, HYDRAULIC AND TRANSMISSION OIL 589
H1-4-1 HEATER, HEATING SYSTEM 593
H1-5-1 AIR CONDITIONER, COOLING SYSTEM 595
H1-6-1 AIR CONDITIONER, CAB, COOLING SYSTEM 597
K – DECAL & PLATES 601
K1 – DECAL & PLATES 601
K1-1-1 DECAL AND PLATES, OPERATING & MAINTENANCE 602
K1-2-1 DECALS, WARNING 604
K1-3-1 DECALS AND PLATES, MACHINE MODEL & INFORMATION 606
PART NO INDEX 608
APPENDIX 2 634
APPENDIX 3 638
APPENDIX 4 639

PLEASE NOTE:

• This is not a physical manual but a digital manual – meaning no physical copy will be couriered to you. The manual can be yours in the next 2 mins as once you make the payment, you will be directed to the download page IMMEDIATELY.
• This is the same manual used by the dealers inorder to diagnose your vehicle of its faults.
• Require some other service manual or have any queries: please WRITE to us at [email protected]

S.V
