Hitachi EX5500-5 Excavator Equipment Components Parts Catalog Manual (PI8B-EI-2) – PDF Download

Description

Hitachi EX5500-5 Excavator Equipment Components Parts Catalog Manual (PI8B-EI-2)

File Details:

Hitachi EX5500-5 Excavator Equipment Components Parts Catalog Manual (PI8B-EI-2)

• Manual Language:English
• Pages: 206
• Size: 7.14 MB
• Downloadable:Yes
• Format:PDF

HITACHI EX5500-5 EXCAVATOR EQUIPMENT COMPONENTS PARTS CATALOG MANUAL (PI8B-EI-2) – PDF DOWNLOAD:

Image Preview:

Description:

Hitachi EX5500-5 Excavator Equipment Components Parts Catalog Manual (PI8B-EI-2)

According to Hitachi’s continuous effort to improve the product quality, descriptions in the Parts Catalog may be slightly different from your machine. If any questionable points are found . feel free to contact your nearest Hitachi dealer.
1. HOW TO ORDER PARTS
When ordering parts, please specify the following items.
(1) Model/type
(2) Product Identification Number
(3) Part No.
(4) Part Name
(5) Q’ty
(6) Purchaser’s Name and Address
2. HOW TO USE THIS PARTS CATALOG
PART NAME: When the part is used as an inner part of an assembly part. the mark is shown in front of the part name.
Q’TY: Q’ty shows the quantity used for a particular single hydraulic unit, however quantity of components shows the quantity for one assembly part.

Table Of Contents:

Hitachi EX5500-5 Excavator Equipment Components Parts Catalog Manual (PI8B-EI-2)

COVER.............................................  1
	CONTENTS...................................... 17
	PUMP.......................................... 20
		PUMP;PISTON............................... 20
		REGULATOR (1/3)........................... 24
		REGULATOR (2/3)........................... 28
		REGULATOR (3/3)........................... 30
		PUMP;PISTON............................... 36
		REGULATOR ................................ 40
		PUMP;GEAR................................. 44
	MOTOR;OIL..................................... 48
		MOTOR;OIL................................. 48
		VALVE;RELIEF.............................. 52
		MOTOR;OIL (TRAVEL)........................ 54
		VALVE..................................... 58
		MOTOR;OIL (TRAVEL)........................ 60
		MOTOR;OIL (OIL-COOLER FAN)................ 64
		VALVE-BLOCK............................... 66
		MOTOR;PISTON.............................. 68
		ROTARY GROUP.............................. 70
		HYDRAULIC PARTS........................... 72
		MOTOR;OIL (COMPRESSOR).................... 74
	VALVE;CONTROL................................. 76
		VALVE;CONTROL (1/2)....................... 76
		VALVE;CONTROL (2/2)....................... 80
		VALVE;CONTROL (1/2)....................... 84
		VALVE;CONTROL (2/2)....................... 88
		VALVE;CONTROL (1/2)....................... 92
		VALVE;CONTROL (2/2)....................... 96
	VALVE.........................................100
		VALVE;PILOT (FRONT & SWING)...............100
		VALVE;PILOT (TRAVEL)......................102
		VALVE;PILOT (BUCKET OPENING & CLOSING)....104
		VALVE;SHUTTLE.............................106
		VALVE;SOLENOID............................114
		VALVE;CHECK...............................120
		VALVE;SELECTOR............................124
		VALVE;LOCK................................126
		VALVE;RELIEF..............................128
		VALVE;BRAKE...............................132
		VALVE;RELIEF..............................134
		VALVE;SLOWRETURN..........................136
		VALVE.....................................138
	CYLINDER......................................150
		CYL.;BOOM <LOADER>........................150
		CYL.;BOOM <BACKHOE>.......................154
		CYL.;ARM <LOADER>.........................158
		CYL.;ARM (R) <BACKHOE>....................162
		CYL.;ARM (L) <BACKHOE>....................166
		CYL.;LEVEL <LOADER>.......................170
		CYL.;BUCKET (R) <LOADER>..................172
		CYL.;BUCKET (L) <LOADER>..................176
		CYL.;BUCKET (R) <BACKHOE>.................180
		CYL.;BUCKET (L) <BACKHOE>.................184
		CYL.;DUMP <LOADER>........................188
		CYL.;LIFT.................................190
	PARTS INDEX...................................193
		PARTS INDEX...............................194

Please Note:

⦁ This is the SAME MANUAL used by the dealerships to diagnose your vehicle
⦁ No waiting for couriers / posts as this is a PDF manual and you can download it within 2 minutes time once you make the payment.
⦁ Your payment is all safe and the delivery of the manual is INSTANT – You will be taken to the DOWNLOAD PAGE.
⦁ So have no hesitations whatsoever and write to us about any queries you may have : heydownloadss @gmail.com
