Hitachi ZAXIS 330 ZAXIS 350 ZAXIS 370 Equipment Components Parts Catalog Manual

Description

Hitachi ZAX1S330 ZAXIS330LC ZAXIS350LC ZAXIS 350 LCN ZAXIS350H ZAXIS 350 LCH ZAX1S350K ZAXIS 350 LCK ZAXIS370 ZAXIS 370 MTH Equipment Components Parts Catalog Manual – PDF DOWNLOAD

TABLE OF CONTENTS:

Hitachi ZAXIS 330 ZAXIS 350 ZAXIS 370 Equipment Components Parts Catalog Manual – PDF DOWNLOAD

ZAX1S330
ZAXIS330LC
ZAXIS350LC
ZAXIS 350 LCN
ZAXIS350H
ZAXIS 350 LCH
ZAX1S350K
ZAXIS 350 LCK
ZAXIS370
ZAXIS 370 MTH

ZX330_ZX370MTH FRONT COVER.......................  1
	FOREWORD.....................................  6
	CONTENTS..................................... 40
	PUMP......................................... 43
		PUMP:DEVICE.............................. 43
		PUMP;UNIT................................ 47
		REGULATOR................................ 51
		PUMP;GEAR................................ 53
		PUMP;GEAR................................ 55
	MOTOR;OIL.................................... 57
		MOTOR;OIL (SWING)........................ 57
		MOTOR;OIL (TRAVEL)....................... 59
		VALVE;BRAKE.............................. 63
		VALVE;RELIEF............................. 65
		PISTON;SERVO............................. 67
		MOTOR;OIL (TRAVEL)....................... 69
		VALVE;BRAKE.............................. 71
		VALVE;RELIEF............................. 73
		MOTOR;OIL (TRAVEL) <TRAVEL HEAT>......... 75
		VALVE;BRAKE.............................. 63
		VALVE;RELIEF............................. 65
		MOTOR;OIL (1/2).......................... 79
		MOTOR;OIL (2/2).......................... 81
	VALVE........................................ 85
		VALVE;CONTROL (1/6)...................... 85
		VALVE;CONTROL (2/6)...................... 89
		VALVE;CONTROL (3/6)...................... 91
		VALVE;CONTROL (4/6)...................... 93
		VALVE;CONTROL (5/6)...................... 95
		VALVE;CONTROL (6/6)...................... 97
		VALVE;CONTROL............................ 99
		VALVE;CONTROL............................101
		VALVE;CONTROL............................105
		BODY ASS'Y...............................107
		COVER ASS'Y..............................109
		VALVE;RELIEF.............................111
		VALVE;PILOT (FRONT & SWING)..............113
		VALVE;PILOT (TRAVEL).....................115
		VALVE;PILOT..............................119
		VALVE;FC.................................121
		VALVE;SOLENOID...........................123
		VALVE;SOLENOID...........................125
		VALVE;SOLENOID...........................129
		VALVE;SOLENOID...........................131
		VALVE;SLOW-RETURN........................133
		VALVE;SLOW-RETURN........................135
		VALVESHUTTLE.............................137
		VALVE;SHUTTLE............................139
		VALVE;LOCK...............................141
		VALVE;SELECTOR...........................143
		VALVE....................................145
	CYLINDER.....................................147
		CYL.;BOOM (R)............................147
		CYL.;BOOM (L)............................151
		CYL.;ARM (MONO BOOM).....................155
		CYL.;ARM (2P-BOOM).......................159
		CYL.;BUCKET..............................163
		CYL.;BUCKET (BEH BOOM)...................167
		CYL.;POSITIONING.........................171
		CYL.;POSITIONING [WITH HOLDING VALVE]....173
	PARTS INDEX..................................178
