Hyster Forklift T5ZA476 T7ZA477 C60AZA478 C80ZA479 T5Z ACB476 T7Z ACB477 C60Z ACB478 – PDF DOWNLOAD

Description

Hyster Forklift T5ZA476 T7ZA477 C60AZA478 C80ZA479 T5Z ACB476 T7Z ACB477 C60Z ACB478

File Details:

Hyster Forklift T5ZA476 T7ZA477 C60AZA478 C80ZA479 T5Z ACB476 T7Z ACB477 C60Z ACB478

Language : English
Pages : 402
Size : 42.2 MB
Downloadable : Yes
Format : PDF

HYSTER FORKLIFT T5ZA476 T7ZA477 C60AZA478 C80ZA479 T5Z ACB476 T7Z ACB477 C60Z ACB478 – PDF DOWNLOAD:

Image Preview:

Description:

Hyster Forklift T5ZA476 T7ZA477 C60AZA478 C80ZA479 T5Z ACB476 T7Z ACB477 C60Z ACB478

• AC Traction Motor The AC traction motor is a three-phase AC induction motor. The motor does not include motor brushes or a commutator. An AC induction motor operates on three-phase AC power provided directly by the controller. The motor speed is controlled by the motor controller and can be changed by the frequency of the AC power supplied to the motor. A speed sensor has been built into one of the motor bearings which provides feedback to the motor controller allowing software to continually monitor motor direction and revolutions per minute (RPM).
• Using this feedback system, the AC motor control can provide much better vehicle top speed control than the older DC SEMsystems. Controller The motor controller converts DC power from the truck battery to three-phase AC power at the frequencies and currents necessary to drive the traction motor. A bearing in the traction motor provides feedback of speed, rotation direction, and temperature directly to the motor controller.
• The motor controller receives power through the main contactor which is controlled by the key switch. The controller receives inputs from the control handle and the hand rail switches to control lift truck functions. NOTE: There are no serviceable parts in the motor controller. No attempt should be made to open repair, or otherwise modify the controller. Doing so may damage the controller and/or lift truck. Removing the cover from the controller will void the warranty.
• Service PC Connection The lift truck is equipped with a connection point to connect a laptop computer with ETACC software installed. This connection can be used to adjust certain lift truck parameters and to assist with troubleshooting the lift truck.
