Hyster H40FT–H70FT (L177) Frame Service Manual 100 SRM 1120 – PDF

Description

Hyster H40FT–H70FT (L177) Frame Service Manual 100 SRM 1120 – PDF DOWNLOAD

Description

This Hyster Frame Service Manual (100 SRM 1120) is a technician-focused PDF covering the frame and major chassis-mounted components for H40FT–H70FT (L177) forklifts. It includes step-by-step removal/installation procedures, safety precautions, and clear diagrams—ideal for workshops handling body panels, LPG tank systems, counterweight service, and overhead guard work.

✅ What this manual helps you do

• Safely support and service the truck when removing major assemblies

• Remove/install hood, seat, dash/cowl, floor plate, side covers

• Service LPG tank + swing-out or drop-down bracket setups

• Remove/install counterweight (includes weight reference tables)

• Replace/fit overhead guard and related tow pin hardware

• Follow correct cautions to prevent damage to harnesses, latches, and fasteners

🗂️ Table of Contents

FRAME (100 SRM 1120)

• General

• Description

• Hood, Seat, and Side Covers Replacement

• Hood Latch

• Frame

• LPG Tank and Bracket Replacement

  • LPG Tank

  • LPG Bracket

  • Counterweight

• Overhead Guard Replacement

• Tow Pin, Remove and Install

• LED Tail, Backup, and Brake Lights, Replace

• Operator Restraint System Replacement

  • Automatic Locking Retractor (ALR)

  • Emergency Locking Retractor (ELR)

• Engine Replacement

  • Remove Engine Only

  • Remove Engine and Transmission

  • Install Engine Only

  • Install Engine and Transmission

• Throttle Pedal and Cable Adjustment

• Exhaust System Repair

• Lift Truck With Counterweight Exhaust System

• Remove and Disassemble / Inspect / Assemble and Install (as listed in section)

• Cooling System

• Fuel and Hydraulic Tanks Repair

  • Cleaning

  • Steam Method of Cleaning

  • Chemical Solution Method of Cleaning

  • Additional Preparation for Repair

  • Small Leaks, Repair

  • Large Leaks, Repair

  • Preparation for Use After Repair

• Safety Labels

  821489882-h40f-h50f-h60ft-h70ft…

📌 File Details

Save time on teardown and reassembly—this official Hyster frame service section gives you the correct steps, safety cautions, and diagrams for counterweight, LPG bracket, and body/hood work. Buy now and download instantly to start servicing toda
