Hyundai Forklift Truck HDF50.70-3 Service Manual – PDF DOWNLOAD

Description

Hyundai Forklift Truck HDF50.70-3 Service Manual

FILE DETAILS:

Hyundai Forklift Truck HDF50.70-3 Service Manual

Language : English
Pages : 600+
Downloadable : YES
Format : PDF
Size : 106 MB

DESCRIPTION:

Hyundai Forklift Truck HDF50.70-3 Service Manual

1. STRUCTURE:

This service manual has been prepared as an aid to improve the quality of repairs by giving the serviceman an accurate understanding of the product and by showing him the correct way to perform repairs and make judge ments. Make sure you understand the contents of this manual and use it to full effect at every opportunity. This service manual mainly contains the necessary technical information for operations performed in a service workshop.
For ease of understanding, the manual is divided into the following sections.

SECTION 1 GENERAL:
This section gives the general information of the machine and explains the safety hints for maintenance.
SECTION 2 REMOVAL & INSTALLATION OF UNIT:
This section explains the procedures and techniques of removal and installation of each component.
SECTION 3 POWER TRAIN SYSTEM:
This section explains the structure of the transmission as well as control valve and drive axle.
SECTION 4 BRAKE SYSTEM:
This section explains the brake piping, each component and operation.
SECTION 5 STEERING SYSTEM:
This section explains the structure of the steering unit, priority valve, trail axle as well as steering circuit and operation.
SECTION 6 HYDRAULIC SYSTEM:
This section explains the structure of the gear pump, main control valve as well as work equipment circuit, each component and operation.
SECTION 7 ELECTRICAL SYSTEM:
This section explains the electrical circuit and each component. It serves not only to give an understanding electrical system, but also serves as reference material for troubleshooting.
SECTION 8 MAST:
This section explains the structure of mast, carriage, backrest and forks. The specifications contained in this service manual are subject to change at any time and without any advance notice. Contact your HYUNDAI distributor for the latest information.

TABLE OF CONTENTS:

Hyundai Forklift Truck HDF50.70-3 Service Manual

Hyundai Forklift Truck HDF50.70-3 Service Manual

SECTION 1 GENERAL
Group 1 Safety hints 1-1
Group 2 Specifications 1-5
Group 3 Periodic replacement 1-13
SECTION 2 REMOVAL AND INSTALLATION OF UNIT
Group 1 Structure 2-1
Group 2 Removal and Installation of Unit 2-2
SECTION 3 POWER TRAIN SYSTEM
Group 1 Structure and operation 3-1
Group 2 Troubleshooting 3-24
Group 3 Disassembly and assembly 3-28
SECTION 4 BRAKE SYSTEM
Group 1 Structure and function 4-1
Group 2 Operational checks and troubleshooting 4-15
Group 3 Tests and adjustments 4-18
SECTION 5 STEERING SYSTEM
Group 1 Structure and function 5-1
Group 2 Operational checks and troubleshooting 5-11
Group 3 Disassembly and assembly 5-13
SECTION 6 HYDRAULIC SYSTEM
Group 1 Structure and function 6-1
Group 2 Operational checks and troubleshooting 6-15
Group 3 Disassembly and assembly 6-19
SECTION 7 ELECTRICAL SYSTEM
Group 1 Component location 7-1
Group 2 Electrical circuit 7-2
Group 3 Component specification 7-11
Group 4 Connector destination 7-12
Group 5 Troubleshooting 7-14
SECTION 8 MAST
Group 1 Structure 8-1
Group 2 Operational checks and troubleshooting 8-5
Group 3 Adjustment 8-8
Group 4 Removal and installation 8-9
