📡 InnovAction JAZZ 500 2G / JAZZ 1000 2G – 500W to 1000W FM Transmitter Service Manual (V.3)

This is the official service manual for the InnovAction JAZZ 2G FM transmitter family, covering JAZZ 500 2G and JAZZ 1000 2G power configurations. It’s built for technicians who need board-level repair info, including complete schematics, layouts, wiring/diagrams, and BOM/component lists across the transmitter’s replaceable modules.

✅ Models / Power Range Covered

• JAZZ 500 2G (500W)

• JAZZ 1000 2G (1000W)

• Manual scope: 500W – 1000W FM Transmitter

🧩 Replaceable Subsystems (What the manual documents)

The transmitter is built from serviceable modules, including:

• AC/DC Power Supply (48V with PFC) + filtered power entry module

• Audio Filter Module, Stereo Coder Module, Audio Input Module

• I/O Board, optional RS485 & Web Server Board, optional RDS Module, optional AES/EBU Digital Audio Interface

• PLL Module, VCO Module

• 500W RF Power Amplifier, plus RF filtering and sensing boards

• Main Board + Logic & Display Board

📑 Table of Contents

✅ System Overview

• JAZZ 500 Subsystems – STF01850

• JAZZ 1000 Subsystems – SAFSF04200B

• Parts overview / internal layout diagrams

🔄 Firmware Update (Jazz 2G)

• Required instruments (serial/programming cable + Flash Magic software)

• Firmware loading steps & EEPROM reset notes

🔥 RF Power & Output Chain (Schematics + Layout + BOM)

• 500W RF Amplifier – SAF3400 (schematic 1/2, 2/2, layout, component list)

• RF 500W Low Pass Filter & Directional Coupler – SRF00900 (schematic, layout, BOM)

• 500W Forward & Reflected Detector Board – SPD1310 (schematic, layout, BOM)

• 1000W RF Amplifier – SAF04200B (schematic, layout, component list)

🧠 Control / Logic / Main Electronics

• Logic & Display Board – SDI3610

  • uP Board SDI03611 (schematic, layout, component list)

  • Display Board SDI03612 (schematic, layout, component list)

  • LED Board SDI03603 (schematic/layout, component list)

• Mainboard – SDM01010 / SDM01100 (multi-section schematics, layout, component list)

• I/O Board – SDI02800 (schematic 1/2, 2/2, layout, component list)

🎛️ RF Generation & Audio Chain

• VCO (87.5–108 MHz) – SDV00310 (schematic, layout, component list)

• PLL Module – STF01705 (schematic, layout, component list)

• Stereo Coder Module – STF01703 (schematic, layout, component list)

• Audio Filter – STF01702 (schematic, layout, component list)

• Audio Input Module – STF01701 (schematic, layout, component list)

⚡ Power & Optional Boards

• DC/DC Power Supply – SPD1800 (block diagram, layouts, optional variant)

• AC/DC Power Supply

• Optional: RS485 & Web Server Board – SDI02801

• Optional: RDS Coder Board – SDZ00110

• Optional: AES/EBU Audio Interface Board – SDI00710

📌 File Details

Skip guesswork—this manual gives you the exact schematics, PCB layouts, and BOMs needed for fast, correct repairs. Buy now and download instantly to get your JAZZ 2G transmitter back on-air with confidence.
