TM3160
ENGINE (E393-B06)
SHORT BLOCK ENGIASSY Fig 1
CYLINDER HEAD Fig 2
CYLINDER HEAD COVER Fig 3
INLET MANIFOLD Fig 4
EXHAUST MANIFOLD Fig 5
CYLINDER BLOCK Fig 6
BEARING/UNDER SIZE (OPTION) Fig 7
OIL PAN Fig 8
REAR PLATE Fig 9
TIMING GEAR CASE Fig 10
HANGER Fig 11
VALVE Fig 12
CAM SHAFT Fig 13
PISTON Fig 14
PISTON/OVER SIZE (OPTION) Fig 15
CRANK SHAFT Fig 16
OIL PUMP Fig 17
WATER PUMP Fig 18
COOLING FAN Fig 19
INJECTION NOZZLE Fig 20
INJECTION PUMP Fig 21
FUEL PIPE Fig 22
ADAPTER Fig 23
ELECTRIC (1) Fig 24
8
ELECTRIC (1) Fig 25
ELECTRIC (2) Fig 26
ELECTRIC (2) Fig 27
REPAIR PARTS(OPTION) Fig 28
COMPONENT PARTS
FOR 6215-300-037-00 ON Fig 20 Fig 29
COMPONENT PARTS
FOR 6215-600-109-30 ON Fig 21 Fig 30
COMPONENT PARTS
FOR 6281-100-014-00 ON Fig 24,25 Fig 31
COMPONENT PARTS
FOR 6281-200-005-00 ON Fig 24,25 Fig 32
9
C o n t e n t s
CHASSIS
RADIATOR SYSTEM(NO 1-2111) Fig 1
RADIATOR SYSTEM(NO 2112-)(1/2)(2/2) Fig 2
MUFFLER SYSTEM(NO 1-1183) Fig 3
MUFFLER SYSTEM(NO 1184-) Fig 4
CLEANER(AIR)SYSTEM(NO 1-2197) Fig 5
CLEANER(AIR)SYSTEM(NO 2198-) Fig 6
FILTER(FUEL)SYSTEM Fig 7
TANK(FUEL)SYSTEM Fig 8
BATTERY SYSTEM(NO 1-2111) Fig 9
BATTERY SYSTEM(NO 2112-) Fig 10
CABLE(PEDAL/ACCELERATOR)SYSTEM Fig 11
LEVER(ACCELERATOR)SYSTEM Fig 12
CLUTCH(MAIN)SYSTEM Fig 13
PEDAL(CLUTCH)SYSTEM Fig 14
SHAFT(INPUT)SYSTEM Fig 15
CASE(TRANSMISSION)SYSTEM Fig 16
GEAR(INPUT)SYSTEM Fig 17
PINION(DRIVE)SYSTEM Fig 18
GEAR(REVERSE)SYSTEM Fig 19
GEAR(4WD)SYSTEM Fig 20
LEVER(MAIN)SYSTEM Fig 21
PLUG(METAL/SHIFT)SYSTEM Fig 22
LEVER(SUB)SYSTEM Fig 23
CHANGE(4WD)SYSTEM Fig 24
CHANGE(MAIN/SUB)SYSTEM Fig 25
GEAR(PTO)SYSTEM Fig 26
SHAFT(PTO)SYSTEM Fig 27
10
LEVER(PTO)SYSTEM Fig 28
COVER(SHIELD)SYSTEM Fig 29
PTO(MID)SYSTEM(M TYPE)(NO 1-1466) Fig 30
COVER(CASE/TRANSMISSION)SYSTEM
(EXCEPT M TYPE) Fig 31
PTO(MID)SYSTEM(M TYPE)(NO 1467-) Fig 32
CASE(DIFFERENTIAL/REAR)SYSTEM
(NO 1-3160) Fig 33
CASE(DIFFERENTIAL/REAR)SYSTEM
(NO 3160-) Fig 34
HOUSING(AXLE/REAR)SYSTEM Fig 35
SHAFT(WHEEL/REAR)SYSTEM(NO 1-3160) Fig 36
SHAFT(WHEEL/REAR)SYSTEM(NO 3161-) Fig 37
PEDAL(DIFF-LOCK)SYSTEM Fig 38
BRAKE SYSTEM Fig 39
PEDAL(BRAKE)SYSTEM(1/2)(2/2) Fig 40
WHEEL(STEERING)SYSTEM Fig 41
STEERING SYSTEM Fig 42
BRACKET(AXLE)SYSTEM Fig 43
HITCH(FRONT)SYSTEM
(R TYPE/EXCEPT M TYPE) Fig 44
SHAFT(DRIVE/FRONT)SYSTEM Fig 45
CASE(DIFFERENTIAL/FRONT)SYSTEM Fig 46
HOUSING(AXLE/FRONT)SYSTEM Fig 47
CASE(GEAR/FRONT)SYSTEM(1/2)(2/2) Fig 48
SHAFT(DRIVE/FINAL)SYSTEM Fig 49
ROD(TIE)SYSTEM(NO 4327-) Fig 50
ROD(TIE)SYSTEM(NO 1-4326) Fig 51
CASE(CYLINDER)SYSTEM(NO 1-5245) Fig 52
CASE(CYLINDER)SYSTEM(NO 5246-) Fig 53
ARM(LIFT)SYSTEM Fig 54
CYLINDER SYSTEM(NO 808-) Fig 55
CYLINDER SYSTEM(NO 1-807) Fig 56
11
LEVER(POSITION)SYSTEM(NO 1-1270) Fig 57
LEVER(POSITION)SYSTEM(NO 1271-) Fig 58
COVER(VALVE)SYSTEM(NO 970-) Fig 59
PIPING SYSTEM Fig 60
LINK(3P)SYSTEM Fig 61
HITCH(DRAW BAR)SYSTEM
(R TYPE/EXCEPT M TYPE) Fig 62
HOOD SYSTEM(NO 1-2111)(1/2)(2/2) Fig 63
HOOD SYSTEM(NO 2112-)(1/2)(2/2) Fig 64
GRILLE SYSTEM Fig 65
COVER(DASH)SYSTEM Fig 66
FENDER SYSTEM Fig 67
BRACKET(SEAT)SYSTEM(NO 1-5245) Fig 68
BRACKET(SEAT)SYSTEM(NO 5246-) Fig 69
FRAME(REAR)SYSTEM Fig 70
STEP SYSTEM Fig 71
PLATE(REGISTRATION)SYSTEM
(R TYPE)(NO 5186-) Fig 72
LAMP(HEAD)SYSTEM Fig 73
LAMP SYSTEM Fig 74
BRACKET(LAMP)SYSTEM(EXCEPT R TYPE) Fig 75
PANEL SYSTEM Fig 76
SWITCH SYSTEM Fig 77
HARNESS SYSTEM Fig 78
ROPS SYSTEM(R TYPE) Fig 79
ORNAMENT Fig 80
LABEL(CONTROL)(EXCEPT M TYPE) Fig 81
LABEL(CONTROL)(M TYPE) Fig 82
LABEL(PTO/MID)(M TYPE)(NO 1-304) Fig 83
LABEL(CAUTION) Fig 84
LABEL(CE)
(EXCEPT R TYPE-NO 1-/R TYPE-NO 1-305,NO 6072-) Fig 85
TOOLS Fig 86
12
OPTIONAL PARTS
PTO(MID)SET
(EXCEPT M TYPE)(NO 1-1290)(OPTION) Fig 87
PTO(MID)SET
(EXCEPT M TYPE)(NO 1291-)(OPTION) Fig 88
WHEEL(REAR/TURF/212/80D-15)SYSTEM
(OPTION) Fig 89
WHEEL(REAR/AGR/8-16)SYSTEM(OPTION) Fig 90
HITCH(FRONT)SET(FM TYPE)(OPTION) Fig 91
WHEEL(FRONT/AGR/5-12)SYSTEM(OPTION) Fig 92
WHEEL(FRONT/TURF/20X8 00-10)SYSTEM
(OPTION) Fig 93
VALVE(AUX/SOL)SET(OPTION) Fig 94
HITCH(DRAW BAR)SET(FM TYPE)(OPTION) Fig 95
ROPS SET(EXCEPT R TYPE)(OPTION) Fig 96
PLATE(BUMPER)SET(OPTION) Fig 97
WEIGHT(15)SET(OPTION) Fig 98
GENERATOR(40A)KIT(OPTION) Fig 99
COMPONENT PARTS
COMPONENT PARTS
FOR K135-023-000-00 ON Fig 60 Fig 100
COMPONENT PARTS
FOR K211-001-000-00 ON Fig 55 Fig 101
COMPONENT PARTS
FOR 1682-406-210-10 ON Fig 42 Fig 102
COMPONENT PARTS
FOR 6281-200-005-00 ON Fig 99 Fig 103
13
WIRING DIAGRAM
WIRING DIAGRAM(1/2)
WIRING DIAGRAM(2/2)
14

DESCRIPTION:

Iseki TM3160 Tractor Parts Manual 1738-097-100-10 – PDF DOWNLOAD

Parts Order
1) When you order parts, please make sure of correct numbers.
2) When substitute parts is available, the part number ordered will be
automatically turned to a new part number.
3) Please be sure to use “ISEKI GENUINE PARTS”.
Any other similar parts other than ISEKI parts when used may cause a
trouble that makes us unable to repair or guarantee the warrant.

S.V 06/03/2025
