John Deere E130 & E140LC Excavator Operator’s Manual OMT437138X019 PDF

Description

John Deere E130 & E140LC Excavator Operator’s Manual OMT437138X019 – PDF DOWNLOAD

Part Number (P/N): OMT437138X019_44
Language: English
Division: Construction
Product Lines: Excavators
Publication Type: Operator’s Manuals
Associated Models: E130, E140LC
Serial Numbers (Serial):

• PIN: 1YNE13BS_ _DXXXXXX—
• PIN: 1YNE14BL_ _DXXXXXX—

TABLE OF CONTENTS:

John Deere E130 & E140LC Excavator Operator’s Manual OMT437138X019 – PDF DOWNLOAD

Contents 29
Safety—Safety and Operator Conveniences 33
Safety and Operator Convenience Features 33
Safety—General Precautions 35
Information for Eurasian Economic Union Technical Regulations Compliance 35
Recognize Safety Information 37
Follow Safety Instructions 37
Operate Only If Qualified 38
Wear Protective Equipment 38
Protect Against Noise 38
Avoid Unauthorized Machine Modifications 38
Control Pattern 39
Inspect Machine 39
Stay Clear of Moving Parts 39
Avoid High-Pressure Fluids 39
Work In Ventilated Area 40
Avoid Static Electricity Risk When Refueling 40
High Debris Applications 40
In Case of Machine Fire 41
Prevent Fires, Clean Debris From Machine 41
Clean Debris from Machine 42
Prevent Battery Explosions 42
Handle Chemical Products Safely 42
Handle Starting Fluid Safely 43
Decommissioning — Proper Recycling and Disposal of Fluids and Components 43
Prepare for Emergencies 44
Add Cab Guarding for Special Uses 44
Safety—Operating Precautions 45
Use Steps and Handholds Correctly 45
Start Only From Operator’s Seat 45
Use and Maintain Seat Belt 45
Heated and Ventilated Operator’s Seat 46
Operating or Traveling On Public Roads 46
Prevent Unintended Machine Movement 47
Avoid Work Site Hazards 48
Keep Riders Off Machine 48
Avoid Backover Accidents 49
Avoid Machine Tip Over and Machine Damage 49
Use Special Care When Lifting Objects 50
Use Care When Swinging Machine 50
Operate Boom With Care 50
Avoid Power Lines 51
Use Special Care When Operating 51
Inspect and Maintain ROPS 51
Travel Safely 52
Prevent Acid Burns 52
Add and Operate Attachments Safely 52
Safety—Maintenance Precautions 53
Park and Prepare for Service Safely 53
Service Cooling System Safely 53
Service Machines Safely 54
Service Accumulator Systems Safely 54
Use Proper Lifting Equipment 54
Remove Paint Before Welding or Heating 55
Make Welding Repairs Safely 55
Drive Metal Pins Safely 55
Safety—Safety Signs and Other Instructions 56
Safety Signs and Other Instructions 56
Operation—Operator’s Station 70
Primary Display Unit (PDU) 70
Pedals, Levers, and Panels 71
Engine Speed Dial 71
Sealed Switch Module (SSM) 72
Sealed Switch Module (SSM) Functions 73
Left Control Lever 74
Right Control Lever 75
Pilot Enable Lever 75
Opening Upper Front Window 76
Alternative Exit Tool 76
Removing and Storing Lower Front Window 77
Opening Cab Door Window 77
Unfolding and Folding Sunshade 78
Opening and Closing the Roof Hatch 78
Fire Extinguisher Mounting Location 79
Cab Dome Light 79
Adjusting the Mechanical Suspension Seat 80
Adjusting the Air Suspension Seat—If Equipped 81
Seat Heater—If Equipped 82
Adjusting Armrest Height 82
Operating the Radio 83
Operating the Premium Radio—If Equipped 84
Cab Heater and Air Conditioner 85
Operation—Monitor Operation 86
Primary Display Unit (PDU) 86
Navigation Buttons 86
Monitor—Runtime Screen 87
Monitor—Indicators 89
Main Menu 91
Main Menu—Diagnostics 92
Main Menu—Fuel Consumption 93
Main Menu—Display Settings 94
Main Menu—Job Timer 94
Main Menu—Maintenance 95
Main Menu—Aux—If Equipped 95
Main Menu—Machine Setup 96
Main Menu—Machine Fan 96
Main Menu—About 97
Main Menu—Security 98
Main Menu—Camera—If Equipped 99
Main Menu—Software Update 100
Operation—Operating the Machine 101
Before Starting Work 101
Inspect Machine Daily Before Starting 101
Battery Disconnect Switch 102
Engine Break-In Period 102
Starting the Engine 103
Cold Weather Warmup 105
Control Lever Operation 105
Operating in Water and Mud 106
Travel Pedals and Levers 106
Parking the Machine 107
Loading and Unloading for Transport 109
Light-Duty Towing Procedure 111
Recovering the Machine 112
Lifting 113
Controlled Load Lowering Device (CLLD)—If Equipped 114
Lowering Boom—Hydraulic System or Engine Malfunction 115
Lifting the Machine 116
Hydraulic Circuit Pressure Release 116
Installing Attachments 120
Maintenance—Machine 121
Required Emission-Related Information 121
Diesel Fuel 121
Lubricity of Diesel Fuel 122
Handling and Storing Diesel Fuel 122
Biodiesel Fuel 123
Testing Diesel Fuel 123
Supplemental Diesel Fuel Additives 124
Fuel Filters 124
Minimizing the Effect of Cold Weather on Diesel Engines 125
Diesel Engine Break-In™ Oil 126
Diesel Engine Oil — Tier 3 and Stage IIIA 127
Engine Oil and Filter Service Intervals—Tier 3 and Stage IIIA Engines 128
Diesel Engine Oil and Filter Service Interval for Operation at High Altitude—Stage III Engines 129
Diesel Engine Coolant (engine with wet sleeve cylinder liners) 130
Water Quality for Mixing with Coolant Concentrate 131
Operating in Warm Temperature Climates 131
Testing Coolant Freeze Point 132
Disposing of Coolant 132
Alternative and Synthetic Lubricants 133
Lubricant Storage 133
Mixing of Lubricants 133
Hydraulic Oil 134
Swing Gear Case Oil 134
Track Drive Gear Case Oil 135
Grease with Molybdenum Disulfide 135
Maintenance—Periodic Maintenance 136
Service Machine at Specified Intervals 136
Check the Hour Meter Regularly 136
Prepare Machine for Maintenance 136
Fuel Tank 136
Fluid Analysis Program Test Kits and 3-Way Coolant Test Kit 136
Hydraulic Hammer Attachment 137
Service Intervals 138
Required Parts 140
Maintenance Legend 141
Maintenance—As Required 143
Check and Adjust Track Tension 143
Inspect or Replace Bucket Joint O-Ring 144
Inspect or Replace Cab Fresh Air and Recirculating Air Filters 144
Drain Auxiliary Fuel Filter Water Separator 145
Drain Primary Fuel Filter Water Separator 146
Lubricate Cab Door Hinges 146
Replace Engine Air Filters 147
Maintenance—Every 10 Hours or Daily 148
Check Engine Oil Level 148
Check Hydraulic Tank Oil Level 149
Check Engine Coolant Level 150
Check and Clean Air Filter Dust Unloader Valve 150
Maintenance—Every 50 Hours 151
Lubricate Boom, Arm, Bucket, and Cylinders 151
Lubricate Boom Cylinder Base Ends 152
Maintenance—Every 250 Hours 153
Take Engine Oil Sample 153
Lubricate Swing Bearing 153
Maintenance—Initial Service—500 Hours 154
Drain and Refill Track Drive Gear Case Oil 154
Maintenance—Every 500 Hours 155
Drain and Refill Engine Oil and Replace Engine Oil Filter 155
Drain Water and Sediment From Fuel Tank Sump 156
Replace Auxiliary Fuel Filter 157
Replace Primary Fuel Filter 158
Replace Final Fuel Filter 159
Check Swing Gear Pinion Grease Level 159
Check Swing Gear Case Oil Level 160
Check Track Drive Gear Case Oil Level 160
Take Fluid Samples 161
Maintenance—Every 1000 Hours 162
Drain and Refill Swing Gear Case Oil 162
Drain and Refill Track Drive Gear Case Oil 162
Replace Cab Fresh Air and Recirculating Air Filters 163
Replace Engine Air Filters Dust Unloader Valve 163
Lubricate Swing Gear Case Bearing 164
Maintenance—Every 2000 Hours 165
Replace Hydraulic Tank Breather Filter 165
Replace Hydraulic Oil Return Filter 166
Inspect and Clean Hydraulic Pilot Mesh Filter 167
Inspect Belt 168
Check and Adjust Engine Valve Lash 168
Clean Case Drain Screen Fitting 168
Maintenance—Every 4000 Hours 169
Drain and Refill Hydraulic Oil 169
Replace Hydraulic Tank Suction Strainer 172
Maintenance—Every 6000 Hours 173
Drain and Refill Engine Coolant 173
Miscellaneous—Machine 175
Bleed Fuel System 175
Bleed Hydraulic System 175
Do Not Service or Adjust Injection Nozzles or High-Pressure Fuel Pump 175
Do Not Service Control Valves, Cylinders, Pumps, or Motors 176
Precautions for Alternator and Regulator 176
Store Batteries at Proper Temperature 176
Handling, Checking, and Servicing Batteries Carefully 177
Using Battery Charger 178
Using Booster Batteries—24-Volt System 180
Removing and Installing Batteries 181
Replacing Batteries 182
Check, Clean, and Tighten Battery Terminals 183
Welding on Machine 184
Keep Electronic Control Unit Connectors Clean 184
JDLink™ Machine Monitoring System (MMS)—If Equipped 184
Replacing Fuses 185
Keep ROPS Installed Properly 188
Remove and Install Halogen Bulbs 189
Replacing Seat Belt 190
Track Sag General Information 190
Check Track Shoe Hardware 191
Accessory Power Outlets 191
Clean Cooling Package 192
Clean Cooling Package Trash Screens—If Equipped 193
Fill Fuel Tank 194
Fuel Refill Pump Operation—If Equipped 195
Check Air Intake Hoses 196
Clean Crankcase Vent Tube 196
Clean Machine Regularly 197
Removing the Bucket 198
Adjust Bucket Pivot End Play 198
Replacing Bucket Teeth 200
Replacing Bucket Side Cutters 200
Check Polycarbonate Roof Hatch—If Equipped 201
Clean Fuel Filler Neck Strainer 201
Check Bolt-Nut Torque 201
Hardware Torque Specifications 202
Unified Inch Bolt and Screw Torque Values 203
Metric Bolt and Screw Torque Values 204
Miscellaneous—Operational Checkout 205
Operational Checkout Procedure 205
Diagnostic Trouble Codes (DTCs) Check 205
Operational Checks—Ignition Off, Engine Off Checks 205
Operational Checks—Ignition On, Engine Off Checks 206
Operational Checks—Ignition On, Engine On Checks 214
Miscellaneous—Troubleshooting 240
Troubleshooting Procedure 240
Software Update 240
Engine 241
Hydraulic System 244
Electrical System 246
Miscellaneous—Storage 249
Prepare Machine for Storage 249
Preparing Machine after Storage 249
Miscellaneous—Machine Numbers 251
Record Product Identification Number (PIN) 251
Record Engine Serial Number 251
Record Travel Motor Serial Numbers 251
Record Swing Motor Serial Number 252
Hydraulic Pump Serial Number 252
Keep Proof of Ownership 252
Keep Machines Secure 252
Miscellaneous—Specifications 253
Engine Specifications 253
Drain and Refill Capacities 253
Machine Specifications 254
Working Ranges 257
Lift Capacity 259
Machine Design Life 260
Eurasian Economic Union 260
Page Number 29
Section 1-1 33
Section 1-2 35
Section 1-3 45
Section 1-4 53
Section 1-5 56
Section 2-1 70
Section 2-2 86
Section 2-3 101
Section 3-1 121
Section 3-2 136
Section 3-3 143
Section 3-4 148
Section 3-5 151
Section 3-6 153
Section 3-7 154
Section 3-8 155
Section 3-9 162
Section 3-10 165
Section 3-11 169
Section 3-12 173
Section 4-1 175
Section 4-2 205
Section 4-3 240
Section 4-4 249
Section 4-5 251
Section 4-6 253

S.V 04/24
