JVC AX-MX70BK Service Manual โ€“ Repair, Schematics & Parts PDF

Original price was: $95.00.Current price is: $18.95.

Original JVC AX-MX70BK Compact Component System Service Manual PDF. Covers safety precautions, disassembly procedures, PCB layouts, block diagrams, wiring & connection diagrams, IC/LSI pinouts, motor control circuits, display tube connections, and complete illustrated parts list. Essential for electronic repair, servicing, and restoration. Instant PDF download.

Buy now
Category: Tags: Vendor: HeavyEquipDocs
โšก
Instant PDF Download
Available immediately
๐Ÿ’พ
Save to Your Device
Download & keep forever
๐Ÿ›ก๏ธ
Antivirus Scanned
100% virus-free
๐ŸŒ
Trusted Worldwide
175,000+ customers

Description

JVC AX-MX70BK Service Manual โ€“ Repair, Schematics & Parts PDF DOWNLOAD

DESCRIPTION

๐Ÿ”Š Manual Overview

This is the official factory service manual for the JVC AX-MX70BK compact component audio system, intended for electronics technicians, service engineers, and audio repair specialists.
The manual provides component-level servicing information, including circuit descriptions, IC pin functions, PCB layouts, schematics, and exploded viewsโ€”making it ideal for troubleshooting, repair, and refurbishment of vintage JVC audio equipment.


๐Ÿ“˜ DETAILED TABLE OF CONTENTS / BOOKMARKS

1๏ธโƒฃ Safety & Servicing Information

  • General safety precautions

  • AC leakage & grounding checks

  • Handling of critical safety parts

  • Fuse, transformer & voltage selector precautions

  • International voltage variants (US, Europe, UK, Australia, etc.)


2๏ธโƒฃ Cooling & Protection Systems

  • Air-cooling fan operation logic

  • Temperature-controlled fan speed behavior

  • Abnormal temperature protection shutdown

  • Fan motor rotation check procedures


3๏ธโƒฃ Disassembly Procedures

  • Top cover removal

  • Front panel removal

  • Main PCB board removal

  • Heat sink removal

  • Illustrated step-by-step disassembly figures


4๏ธโƒฃ Description of Major ICs / LSIs

Includes detailed pin layouts, block diagrams & functions for:

  • System control microcomputer (MN17120JNY)

  • Analog switch ICs (TC9163N / TC9164N)

  • Variable resistor IC for SEA control (LC7522)

  • S.E.A. graphic equalizer ICs (LA3607S)

  • Motor driver IC (LB1639-CV)

  • Remote control receiver IC

  • Display filter IC (XR1091DCP)

  • Decoder & A/D converter ICs

  • Shift registers & logic ICs


5๏ธโƒฃ Display & Control Circuits

  • Display tube internal connections

  • Grid division & terminal mapping

  • Control signal routing


6๏ธโƒฃ Power Supply & Regional Variants

  • Power primary circuits for:

    • Continental Europe

    • UK / Australia

    • Germany / Italy

    • USA / Canada

  • Voltage selector wiring references


7๏ธโƒฃ Schematics & Diagrams

  • Block diagram (full system signal flow)

  • Connection diagrams

  • Printed Circuit Board (PCB) layouts

  • Power amplifier & control board layouts


8๏ธโƒฃ Parts List & Exploded Views

  • General exploded assembly view

  • Complete parts list with:

    • Part numbers

    • Descriptions

    • Quantities

    • Region-specific variations

  • Identification of safety-critical components


๐Ÿ“„ FILE DETAILS

ItemDescription
Manual NameJVC AX-MX70BK Service Manual
Model CoveredAX-MX70BK (CA-MX70BK System)
Unit No.AX-MX70BK
Manual TypeService / Repair / Parts
YearMarch 1991
Pages138
PDF QualityClear scanned pages with schematics & diagrams

๐ŸŽฏ WHO THIS MANUAL IS FOR

  • Audio electronics repair technicians

  • Vintage hi-fi restorers

  • Service centers & workshops

  • DIY electronics enthusiasts


โš™๏ธ WHY THIS MANUAL IS IMPORTANT

This manual provides true component-level schematics, IC pinouts, and PCB layouts, allowing accurate fault diagnosis and repairโ€”information not available in user manuals.


โšก INSTANT DOWNLOAD โ€“ START REPAIRING TODAY

Buy now to instantly download the PDF and confidently service or restore your JVC AX-MX70BK audio system without guesswork.
