Komatsu Avance Loader WA380-3 Wheel Loader Shop Manual SEBM006104 – PDF DOWNLOAD

FILE DETAILS:

Komatsu Avance Loader WA380-3 Wheel Loader Shop Manual SEBM006104 – PDF DOWNLOAD

Language : English
Pages :802
Downloadable : Yes
File Type : PDF

DESCRIPTION:

Komatsu Avance Loader WA380-3 Wheel Loader Shop Manual SEBM006104 – PDF DOWNLOAD

SERIAL NUMBERS WA380-3 – 50001 and UP

FOREWORD
GENERAL

• This shop manual has been prepared as an aid to improve the quality of repairs by giving the serviceman an accurate understanding of the product and by showing him the correct way to perform repairs and make judgements. Make sure you understand the contents of this manual and use it to full effect at every opportunity.
• This shop manual mainly contains the necessary technical information for operations performed in a service workshop. For ease of understanding, the manual is divided into the following chapters; these chapters are further divided into the each main group of components.

STRUCTURE AND FUNCTION
This section explains the structure and function of each component. It serves not only to give
an understanding of the structure, but also serves as reference material for troubleshooting.
TESTING AND ADJUSTING
This section explains checks to be made before and after performing repairs, as well as
adjustments to be made at completion of the checks and repairs.
Troubleshooting charts correlating “Problems” to “Causes” are also included in this section.
DISASSEMBLY AND ASSEMBLY
This section explains the order to be followed when removing, installing, disassembling or
assembling each component, as well as precautions to be taken for these operations.
MAINTENANCE STANDARD
This section gives the judgement standards when inspecting disassembled parts.

TABLE OF CONTENTS:

Komatsu Avance Loader WA380-3 Wheel Loader Shop Manual SEBM006104 – PDF DOWNLOAD

SERIAL NUMBERS WA380-3 – 50001 and UP

MAIN MENU 0
CONTENTS 2
01 GENERAL 24
GENERAL ASSEMBLY DRAWING 25
SPECIFICATIONS 27
WEIGHT TABLE 30
LIST OF LUBRICANT AND WATER 32
10 STRUCTURE AND FUNCTION 34
POWER TRAIN 35
POWER TRAIN SYSTEM 36
TORQUE CONVERTER, TRANSMISSION PIPING 38
TRANSMISSION HYDRAULIC SYSTEM DIAGRAM 39
TRANSMISSION HYDRAULIC CIRCUIT DIAGRAM 40
TORQUE CONVERTER 41
TORQUE CONVERTER OIL FILTER 43
TRANSMISSION 44
TRANSMISSION CONTROL VALVE 54
DRIVE SHAFT 76
AXLE 77
DIFFERENTIAL 79
FINAL DRIVE 83
AXLE MOUNT, CENTER HINGE PIN 84
STEERING PIPING 86
STEERING COLUMN 87
STEERING VALVE 88
ORBIT-ROLL VALVE 102
STOP VALVE 106
EMERGENCY STEERING PUMP 107
DIVERTER VALVE 108
BREAK PIPING111
BRAKE HYDRAULIC CIRCUIT DIAGRAM 112
BRAKE VALVE 113
ACCUMULATOR CHARGE VALVE118
ACCUMULATOR (FOR BRAKE) 124
BRAKE126
PARKING BRAKE CONTROL 128
PARKING BRAKE 129
PARKING BRAKE SOLENOID VALVE 130
PARKING BRAKE VALVE 131
PARKING BRAKE EMERGENCY RELEASE SOLENOID VALVE 132
HYDRAULIC PIPING133
WORK EQUIPMENT HYDRAULIC SYSTEM DIAGRAM134
WORK EQUIPMENT HYDRAULIC CIRCUIT DIAGRAM135
WORK EQUIPMENT LEVER LINKAGE 139
HYDRAULIC TANK 140
PPC VALVE 142
PPC RELIEF VALVE147
ACCUMULATOR (FOR PPC VALVE) 148
MAIN CONTROL VALVE 149
WORK EQUIPMENT LINKAGE 164
BUCKET 166
BUCKET POSITIONER AND BOOM KICK-OUT 167
CAB173
ROPS CAB 175
AIR CONDITIONER 176
ELECTRIC CIRCUIT DIAGRAM 187
MACHINE MONITOR SYSTEM 188
MAIN MONITOR 189
MAINTENANCE MONITOR 194
WORK EQUIPMENT CONTROL SYSTEM 197
ECSS (Electronically Controlled Suspension System) 204
SENSORS 208
ENGINE STARTING CIRCUIT 212
ENGINE STOP CIRCUIT 213
PREHEATING CIRCUIT214
ELECTRIC TRANSMISSION CONTROL 215
KICK-DOWN SWITCH 218
KICK-DOWN ELECTRIC CIRCUIT DIAGRAM 219
TRANSMISSION CUT-OFF SWITCH 224
TRANSMISSION CUT-OFF FUNCTION 225
ELECTRIC PARKING BRAKE CONTROL 227
20 TESTING AND ADJUSTING 239
STANDARD VALUE TABLE FOR ENGINE 240
STANDARD VALUE TABLE FOR CHASSIS 241
STANDARD VALUE TABLE FOR ELECTRICAL SYSTEM 245
TOOLS FOR TESTING, ADJUSTING, AND TROUBLESHOOTING 249
ADJUSTING VALVE CLEARANCE 250
MEASURING COMPRESSION PRESSURE 251
MEASURING BLOW-BY PRESSURE 252
TESTING AND ADJUSTING FUEL INJECTION TIMING 253
MEASURING EXHAUST COLOR 255
MEASURING INTAKE AIR PRESSURE (BOOST PRESSURE) 256
MEASURING EXHAUST GAS TEMPERATURE 257
MEASURING ENGINE OIL PRESSURE 258
MEASURING ENGINE SPEED 259
TESTING AND ADJUSTING FAN BELT TENSION 260
METHOD FOR ADJUSTING ENGINE STOP MOTOR CABLE 261
MEASURING ACCELERATOR PEDAL 263
MEASURING OPERATING FORCE, TRAVEL OF SPEED LEVER 265
MEASURING STALL SPEED 266
MEASURING TORQUE CONVERTER, TRANSMISSION, PARKING BRAKE OIL PRESSURE 268
METHOD OF OPERATING EMERGENCY MANUALSPOOL 270
MEASURING CLEARANCE BETWEEN TIRE AND WHEEL 272
TESTING AND ADJUSTING STEERING WHEEL 273
TESTING AND ADJUSTING STEERING CONTROL 276
MEASURING STEERING OIL PRESSURE 277
MEASURING OPERATING FORCE, TRAVEL OF BRAKE PEDAL 279
MEASURING BRAKE PERFORMANCE 280
TESTING BRAKE OIL PRESSURE 281
TESTING FOR BRAKE DISC WEAR 282
BLEEDING AIR FROM BRAKE SYSTEM 283
MEASURING PARKING BRAKE PERFORMANCE 284
MANUAL RELEASE METHOD FOR PARKING BRAKE 285
TESTING WEAR OF PARKING BRAKE DISC 286
MEASURING WORK EQUIPMENT CONTROL LEVER 287
MEASURING WORK EQUIPMENT HYDRAULIC PRESSURE 289
MEASURING PPC VALVE PRESSURE 291
MEASURING WORK EQUIPMENT 293
TESTING AND ADJUSTING BUCKET POSITIONER 295
TESTING AND ADJUSTING BOOM KICK-OUT 296
ADJUSTING MAIN MONITOR (SPEEDOMETER MODULE) 298
ADJUSTING BOOM, BUCKET ANGLE POTENTIOMETER 299
TROUBLESHOOTING300
POINTS TO REMEMBER WHEN TROUBLESHOOTING 301
SEQUENCE OF EVENTS IN TROUBLESHOOTING 302
PRECAUTIONS WHEN CARRYING OUT MAINTENANCE 303
HANDLING CONNECTORS 310
CHECKS BEFORE TROUBLESHOOTING 311
METHOD OF USING TROUBLESHOOTING CHARTS 312
CONNECTOR TYPES AND MOUNTING LOCATIONS320
CONNECTOR PIN ARRANGEMENT DIAGRAM321
CONNECTION TABLE FOR CONNECTOR PIN NUMBERS 326
TROUBLESHOOTING OF ENGINE SYSTEM (S MODE) 333
S-1 Starting performance is poor (Starting always takes time) 334
S-2 Engine does not start 335
(1) Engine does not turn335
(2) Engine turns but no exhaust gas comes out (Fuel is not being injected)336
(3) Exhaust gas comes out but engine does not start (Fuel is being injected)337
S-3 Engine does not pick up smoothly (Follow-up is poor) 338
S-4 Engine stops during operations 339
S-5 Engine does not rotate smoothly (hunting) 340
S-6 Engine lacks output (no power) 341
S-7 Exhaust gas is black (incomplete combustion) 342
S-8 Oil consumption is excessive (or exhaust gas is blue) 343
S-9 Oil becomes contaminated quickly 344
S-10 Fuel consumption is excessive 345
S-11 Oil is in cooling water, or water spurts back, or water level goes down346
S-12 Oil pressure lamp lights up (drop in oil pressure) 347
S-13 Oil level rises 348
S-14 Water temperature becomes too high (overheating) 349
S-15 Abnormal noise is made350
S-16 Vibration is excessive351
TROUBLESHOOTING OF MAIN MONITOR SYSTEM (M MODE) 352
TROUBLE DATA DISPLAY 354
M-1 Main monitor does not work356
M-2 When starting switch is turned ON and engine is started immediately, all lamps stay lighted up 357
M-3 Speedometer display does not work properly 358
M-4 Abnormality in shift indicator 359
(a) Stays at N even when directional lever is at F359
(b) Stays at N even when directional lever is at R359
(c) Does not display N even when directional lever is at N and displays R when directional lever is at F359
(d) Does not display N even when directional lever is at N and displays F when directional lever is at R360
(e) Does not display lst, 4th360
(f) Does not display 3rd, 4th360
(g) Does not display 2nd, 3rd361
(h) Does not display 1st, 2nd361
M-5 High beam does not light up 362
M-6 Turn signal display does not light up 363
(a) LH turn signal does not light up363
(b) RH turn signal does not light up363
M-7 Abnormality in parking display 364
(a) Parking lamp does not light up364
(b) Parking lamp stays lighted up364
M-8 Abnormality in preheating system (QGS) 365
(a) Does not carry out preheating365
(b) Always carries out preheating for 1 minute366
(c) Preheating stays on366
(d) Preheating time becomes shorter, or there is variation367
M-9 Night lighting does not light up 368
M-10 Abnormality in front working lamp 369
(a) Neither monitor display nor front working lamp light up369
(b) Working lamp lights up but monitor display does not light up369
(c) Monitor lights up but working lamp does not light up369
M-11 Abnormality in rear working lamp370
(a) Neither monitor display nor rear working lamp light up370
(b) Working lamp lights up but monitor display does not light up370
(c) Monitor lights up but working lamp does not light up370
M-12 Abnormality in transmission cut-off372
(a) When monitor switch is pressed, cut-off function is not switched and display is not given372
(b) Monitor display goes out but cut-off function stays on372
(c) Monitor display lights up but cut-off function is not actuated373
M-13 Abnormality in parking brake dragging warning374
(a) When parking brake is applied, buzzer sounds (intermittently) even when directional lever is at N, and caution lamp flashes374
(b) When parking brake is applied, buzzer does not sound and caution lamp does not light up even when directional lever is at po374
M-14 When parking brake dragging warning is given, buzzer and caution lamp are actuated continuously, or they are not actuated375
(a) Actuated continuously375
(b) Not actuated375
M-15 Abnormality in buzzer376
(a) Buzzer does not sound when starting switch is turned ON (during self-check)376
(b) Buzzer always sounds376
M-16 Condition of monitor switches is not stored in memory377
M-17 Abnormality in failure display mode378
(a) Does not enter failure display mode378
(b) Time for time elapsed since failure on failure display mode does not advance378
M-18 Abnormality in emergency steering normal display379
(a) Emergency steering normal display does not light up379
(b) Emergency steering normal display stays lighted up379
M-19 Abnormality in emergency steering actuation display380
(a) Emergency steering actuation display does not light up380
(b) Emergency steering actuation display stays lighted up380
M-20 Abnormality in auto-greasing system381
(a) Forced greasing cannot be carried out381
(b) Monitor display flashes rapidly (2 times/sec)381
(c) When no more grease remains, monitor display flashes rapidly (2 times/sec)381
(d) Monitor display flashes slowly (1 time/sec)382
(e) Monitor display goes out382
M-21 Abnormality in ECSS system383
(a) Display does not change when switch is pressed383
(b) Monitor display lights up but ECSS function does not work383
M-22 Buzzer does not sound when auto-leveling switch is actuated383
M-23 Failure code is not sent to main monitor (abnormality in network)384
TROUBLESHOOTING OF MAINTENANCE MONITOR SYSTEM (K MODE) 385
K-1 When starting switch is turned ON, all lamps on maintenance monitor do not light up for 3 sec, maintenance monitor does not386
(a) All lamps on maintenance monitor do not light up for 3 seconds386
(b) Some lamps do not light up387
K-2 When starting switch is turned ON, all lamps on maintenance monitor light up but do not go out 387
K-3 When engine is started immediately after starting switch is turned ON (within 3 seconds), all lamps on maintenance monitor do not go out 388
K-4 When starting switch is turned ON (engine stopped), CHECK items flash 389
(a) Engine oil level display flashes389
(b) Engine water level display flashes390
K-5 When starting switch is turned ON (engine started), CAUTION items flash 391
(a) Engine oil pressure display flashes391
(b) Battery charge level display flashes392
(c) Brake oil pressure display flashes393
(d) Air cleaner display flashes394
K-6 CAUTION items are flashing but alarm buzzer does not sound 395
K-7 There is no abnormality in monitor display but alarm buzzer sounds 396
K-8 CAUTION items are flashing but warning lamp (CHECK lamp, CAUTION lamp) does not light up 397
(a) CHECK lamp397
(b) CAUTION lamp397
K-9 There is no abnormality in maintenance monitor display but warning lamp (CHECK lamp, CAUTION lamp) lights up 398
(a) CHECK lamp398
(b) CAUTION lamp398
K-10 Night lighting does not light up when lamp switch is turned ON (only lighting of maintenance monitor does not light up) 399
K-11 Night lighting lights up even when lamp switch is OFF, night lighting stays lighted up 400
K-12 Service meter does not work 401
K-13 Service meter is running even when engine is stopped401
K-14 Abnormality in gauge items 402
(a) Abnormality in fuel gauge402
(b) Abnormality in engine water temperature gauge403
(c) Abnormality in torque converter oil temperature gauge404
TROUBLESHOOTING OF ELECTRICAL SYSTEM (E MODE) 405
E-1 Engine does not start 406
(a) Starting motor does not turn406
(b) Starting motor turns410
E-2 Engine does not stop 412
E-3 Engine stops when machine is traveling 412
E-4 Parking brake does not work 413
(a) Parking brake has no effect when parking brake switch is turned ON (parking)413
(b) Parking brake has no effect when brake pressure drops (Does not work as emergency brake)413
E-5 Parking brake is applied when machine is traveling 414
E-6 Parking brake is released when starting switch is turned ON 416
E-7 Transmission does when parking brake is applied (but parking brake works normally) 416
E-8 Transmission does not work normally 417
(a) Problem in common circuit for transmission (always stays in 2nd)419
(b) Problem in H-L circuit419
(c) Problem in speed circuit420
(d) Problem in 4th circuit (does not enter 4th)420
(e) Contact in H-L circuit421
(f) Contact in speed circuit423
(g) Contact in 4th circuit (always stays in 4th)425
(h) Problem in FORWARD circuit (REVERSE is normal)426
(i) Problem in REVERSE circuit (FORWARD is normal)428
(j) Problem in common circuit for FORWARD and REVERSE (does not travel forward, parking brake is normal)430
(k) Contact in FORWARD circuit432
(I) Contact in REVERSE circuit434
(m) Problem in common circuit for FORWARD and REVERSE436
E-9 Kick-down switch does not work (the regular F1 to F4 shifts normally)437
E-10 Kick-down works only when kick-down switch is ON (Kick-down switch relay does not hold in position (self-holding function) 439
E-11 Kick-down operation cannot be canceled 439
(a) Not canceled even when directional lever is moved from F to N or R439
(b) Not canceled even when speed lever is moved from 2nd to other position (becomes 4th)440
E-12 Kick-down switch is actuated by mistake when traveling in 2nd 442
TROUBLESHOOTING OF HYDRAULIC AND MECHANICAL SYSTEM (CHASSIS RELATED) (T MODE) 443
POWER TRAIN 444
T-1 Machine does not start 444
T-2 Travel speed is slow, thrusting power is weak, lacks power on slopes 446
T-3 Excessive shock when starting machine or shifting gear 448
T-4 Excessive time lag when starting machine or shifting gear 449
T-5 Torque converter oil temperature is high 450
STEERING SYSTEM 451
T-6 Steering does not turn 451
T-7 Steering wheel is heavy 452
T-8 Steering wheel wobbles or there is excessive shock 453
T-9 Machine steers to one side when traveling 453
T-10 Turning radius to left and right is different 453
BRAKE SYSTEM 454
T-11 Brakes do not work or braking effect is poor 454
T-12 Brakes are not released or brakes drag 455
T-13 Parking brake is not released or brake drags 456
WORK EQUIPMENT 457
T-14 Boom does not rise 457
T-15 Boom movement is slow or boom lacks lifting power 458
T-16 When boom is raised, it moves slowly at a certain height 459
T-17 Bucket cannot be pushed with cylinder (bucket floats) 459
T-18 Excessive hydraulic drift of boom 459
T-19 Boom shakes during operation 459
T-20 Boom drops momentarily when control lever is operated from HOLD to RAISE 460
T-21 Bucket does not tilt back 461
T-22 Bucket movement is slow or tilt-back lacks power 462
T-23 Bucket movement becomes slow during tilt-back operation 463
T-24 Bucket cannot be pushed with bucket cylinder 463
T-25 Excessive hydraulic drift of bucket 463
T-26 Bucket shakes during loading operation (Main control valve at HOLD) 464
T-27 Bucket dumps momentarily when control lever is operated from HOLD to TILT 464
T-28 Boom, bucket control levers are heavy or do not move smoothly 465
TROUBLESHOOTING OF ECSS (ELECTRONICALLY CONTROLLED SUSPENSION SYSTEM) (D MODE) 466
JUDGEMENT TABLE FOR CONTROLLER ELECTRICAL SYSTEM 467
D-1 ECSS does not work 468
(a) Error code [d0] is displayed469
(b) Error code [d1] is displayed469
(c) Error code [d2] is displayed470
(d) Error code [d3] is displayed470
(e) Error code [d4] is displayed471
(f) No abnormality display is given471
D-2 ECSS cannot be canceled 475
D-3 Output is turned ON (travel speed does not become 5 km/h) (deviates around 5 km/h) 476
D-4 Output is turned ON when transmission476
D-5 Output is turned ON when transmission is in 4th 477
D-6 Controller LED code is not displayed 478
D-7 ECSS is abnormal but main monitor does not give abnormality display 478
TROUBLESHOOTING OF WORK EQUIPMENT CONTROLLER SYSTEM (W MODE) 479
OUTLINE 481
1 Function481
2 When carrying out troubleshooting481
3 Failure code table481
4 Table of troubleshooting modes and causes482
W-1 Failure code [40] Abnormality in bucket dump solenoid system 484
W-2 Failure code [41] Short circuit in power source when bucket DUMP, TILT solenoids are OFF 485
W-3 Failure code [42] Abnormality in bucket tilt solenoid system 486
W-4 Failure code [43] Abnormality in damping solenoid system 487
W-5 Failure code [44]Short circuit in power source at hot end of damping solenoid 488
W-6 Failure code [45]Short circuit in power source at return end of damping solenoid 488
W-7 Failure code [48] Abnormality in bucket lever kick-out relay system 489
W-8 Failure code [49] Abnormality in boom lever kick-out relay system 491
W-9 Failure code [50] Abnormality in auto-leveler relay system 492
W-10 Failure code [51] Disconnection in boom RAISE, LOWER detection pressure switch 493
W-11 Failure code [52] Abnormality in boom angle potentiometer system 494
W-12 Failure code [53] Abnormality in bucket angle potentiometer system 494
W-13 Failure code [54] Abnormality in model selection wiring harness 496
W-14 Sensor cannot be adjusted 497
W-15 Does not carry out auto-leveling 498
(a) Auto-leveler switch system498
(b) Auto-leveler LED system498
(c) Bucket lever neutral switch system499
(d) Engine speed signal system500
W-16 Auto-leveler cannot be set 501
(a) Auto-leveler set switch system501
(b) Auto-leveler set LED system501
W-17 Remote positioner RAISE, LOWER LEDs do not light up 502
(a) Remote positioner switch system502
(b) Remote positioner LED system502
W-18 Remote positioner set LEDs do not flash 503
(a) Remote positioner switch system503
(b) Remote positioner LED system503
W-19 Bucket does not tilt immediately at boom FLOAT detent when remote positioner is at RAISE and auto mode is ON 504
W-20 Buzzer for switch operation does not sound 505
W-21 Bucket correction, boom stop response are slow 506
W-22 Bucket (lever) control 507
(a) Bucket kick-out does not work even when bucket is at maximum tilt507
(b) Lever is not held by detent508
W-23 Failure code is not displayed on main monitor 510
W-24 Maintenance monitor check 511
30 DISASSEMBLY AND ASSEMBLY512
METHOD OF USING MANUAL 514
PRECAUTIONS WHEN CARRYING OUT OPERATION 515
SPECIAL TOOL LIST 517
STARTING MOTOR 519
REMOVAL AND INSTALLATION519
ALTERNATOR 520
REMOVAL AND INSTALLATION520
ENGINE OIL COOLER 521
REMOVAL AND INSTALLATION521
FUEL INJECTION PUMP 522
REMOVAL522
INSTALLATION523
WATER PUMP 524
REMOVAL AND INSTALLATION524
TURBOCHARGER526
REMOVAL AND INSTALLATION526
NOZZLE HOLDER 527
REMOVAL AND INSTALLATION527
THERMOSTAT 528
REMOVAL AND INSTALLATION528
CYLINDER HEAD529
REMOVAL529
INSTALLATION534
RADIATOR536
REMOVAL536
INSTALLATION539
ENGINE540
REMOVAL540
INSTALLATION545
TORQUE CONVERTER CHARGING PUMP546
REMOVAL546
INSTALLATION547
TORQUE CONVERTER, TRANSMISSION548
REMOVAL548
INSTALLATION552
TORQUE CONVERTER553
DISASSEMBLY553
ASSEMBLY555
TRANSMISSION558
DISASSEMBLY558
ASSEMBLY568
TRANSMISSION CLUTCH PACK582
DISASSEMBLY582
ASSEMBLY588
TRANSMISSION CONTROL VALVE600
REMOVAL600
INSTALLATION602
DISASSEMBLY603
ASSEMBLY605
TRANSMISSION ACCUMULATOR VALVE608
DISASSEMBLY608
ASSEMBLY609
TRANSMISSION MODULATING VALVE610
DISASSEMBLY610
ASSEMBLY611
DRIVE SHAFT612
DISASSEMBLY612
ASSEMBLY615
FRONT AXLE617
REMOVAL617
INSTALLATION619
REAR AXLE620
REMOVAL620
INSTALLATION624
DIFFERENTIAL626
DISASSEMBLY626
ASSEMBLY631
AXLE HOUSING641
DISASSEMBLY641
ASSEMBLY648
CENTER HINGE PIN658
REMOVAL658
INSTALLATION662
STEERING VALVE665
REMOVAL665
INSTALLATION667
DISASSEMBLY668
ASSEMBLY672
ORBIT-ROLL VALVE675
REMOVAL675
INSTALLATION676
DISASSEMBLY677
ASSEMBLY680
STEERING CYLINDER685
REMOVAL685
INSTALLATION686
BRAKE VALVE687
REMOVAL687
INSTALLATION 688
RIGHT BRAKE VALVE (TANDEM) 689
DISASSEMBLY689
ASSEMBLY 690
LEFT BRAKE VALVE (SINGLE) 691
DISASSEMBLY691
ASSEMBLY 692
PARKING BRAKE DISC 693
REMOVAL693
INSTALLATION695
HYDRAULIC TANK696
REMOVAL696
INSTALLATION698
HYDRAULIC FILTER699
REMOVAL AND INSTALLATION699
HYDRAULIC, STEERING, SWITCH, PPC PUMP700
REMOVAL700
INSTALLATION703
MAIN CONTROL VALVE704
REMOVAL704
INSTALLATION 706
DISASSEMBLY707
ASSEMBLY709
PPC VALVE 712
REMOVAL712
INSTALLATION714
DISASSEMBLY715
ASSEMBLY 716
BUCKET CYLINDER717
REMOVAL717
INSTALLATION719
BOOM CYLINDER 720
REMOVAL720
INSTALLATION721
HYDRAULIC CYLINDER 722
DISASSEMBLY722
ASSEMBLY725
WORK EQUIPMENT728
REMOVAL728
INSTALLATION 731
COUNTERWEIGHT 733
REMOVAL AND INSTALLATION733
FUEL TANK 734
REMOVAL734
INSTALLATION 736
CAB, FLOOR FRAME737
REMOVAL737
INSTALLATION740
CAB741
REMOVAL741
INSTALLATION742
MAIN MONITOR743
REMOVAL743
INSTALLATION744
MAINTENANCE MONITOR745
REMOVAL AND INSTALLATION745
AIR CONDITIONER UNIT 746
REMOVAL746
INSTALLATION 751
AIR CONDITIONER CONDENSER752
REMOVAL752
INSTALLATION753
DRY RECEIVER754
REMOVAL AND INSTALLATION754
AIR CONDITIONER CONDENSER COMPRESSOR 755
REMOVAL AND INSTALLATION755
40 MAINTENANCE STANDARD 756
ENGINE MOUNT, TRANSMISSION MOUNT 757
TORQUE CONVERTER CHARGING PUMP 758
TORQUE CONVERTER 759
TRANSMISSION760
TRANSMISSION CONTROL VALVE 768
MODULATION VALVE ASSEMBLY 772
ACCUMULATOR VALVE 773
DRIVE SHAFT 774
DIFFERENTIAL 775
FINAL DRIVE 778
AXLE MOUNT 780
CENTER HINGE PIN 781
STEERING COLUMN 783
STEERING VALVE 784
STEERING CYLINDER MOUNT 785
BRAKE 786
BRAKE VALVE 787
PARKING BRAKE 790
HYDRAULIC PUMP791
MAIN CONTROL VALVE 792
PPC VALVE 796
HYDRAULIC CYLINDER 797
WORK EQUIPMENT LINKAGE 798
BUCKET 800
BUCKET POSITIONER AND BOOM KICK-OUT 801

IMAGES PREVIEW OF THE MANUAL:

S.M 22/12/24
