Komatsu PC58UU-3 Hydraulic Excavator Shop Manual SEBM023909 PDF

Description

Komatsu PC58UU-3 Hydraulic Excavator Shop Manual SEBM023909  – PDF DOWNLOAD

FILE DETAILS:

Komatsu PC58UU-3 Hydraulic Excavator Shop Manual SEBM023909  – PDF DOWNLOAD

Language : English
Pages : 521
Downloadable : Yes
File Type : PDF

IMAGES PREVIEW OF THE MANUAL:

TABLE OF CONTENTS:

Komatsu PC58UU-3 Hydraulic Excavator Shop Manual SEBM023909  – PDF DOWNLOAD

       MACHINE MODEL SERIAL NUMBER

• PC58UU-3                 20001 and up

COVER 1
CONTENTS 2
01 GENERAL 27
GENERAL ASSEMBLY DRAWING 28
WORK EQUIPMENT RANGE DRAWING 29
SPECIFICATIONS 30
WEIGHT TABLE 37
LIST OF LUBRICANTS AND COOLANT 40
10 STRUCTURE,FUNCTION AND MAINTENANCE STANDARD 41
PTO 42
COOLING SYSTEM 43
POWER TRAIN 44
SWING CIRCLE 45
SWING MACHINERY 46
TRACK FRAME,IDLER CUSHION 48
IDLER 51
TRACK ROLLER 52
CARRIER ROLLER 53
SPROCKET 54
TRACK SHOE 55
HYDRAULIC EQUIPMENT LAYOUT DRAWING 62
HYDRAULIC TANK AND FILTER 63
HYDRAULIC PUMP 64
CONTROL VALVE 73
CLSS 81
CENTER SWIVEL JOINT 104
TRAVEL MOTOR 105
SWING MOTOR 113
TRAVEL PPC VALVE 120
PPC VALVE 124
HYDRAULIC CYLINDER 133
SOLENOID VALVE 136
MULTI CONTROL VALVE 142
WORK EQUIPMENT 143
AIR CONDITIONING PIPING 149
ENGINE CONTROL 150
ELECTRICAL CONTROL SYSTEM 152
ELECTRICAL SYSTEM 158
MONITOR SYSTEM 176
20 TESTING AND ADJUSTING 181
STANDARD VALUE TABLUE FOR ENGING 182
STANDARD VALUE TABLE FOR CHASSIS 184
STANDARD VALUE TABLE FOR ELECTRICAL PARTS 192
TESTING AND ADJUSTING 197
TOOLS FOR TESTING, ADJUSTING, AND TROUBLESHOOTING 198
MEASURING ENGINE SPEED 199
MEASURING ENGINE OIL PRESSURE 199
MEASURING COMPRESSING PRESSURE 200
AD JUSTING VALVE CLEARANCE 201
TESTING AND ADJUSTING FUEL INJECTION TIMING 202
TESTING AND ADJUSTING ALTERNATOR BELT TENSION 205
ADJUSTING FUEL CONTROL LINKAGE 206
MEASURING EXHAUST COLOR 207
TESTING CLEARANCE OF SWING CIRCLE BEARING 208
CHECKING WEAR OF SPROCKET 209
TESTING AND ADJUSTING TRACK SHOE TENSION 210
ADJUSTING BRADE CONTROL LEVER 211
TESTING AND ADJUSTING HYDRAULIC PRESSURE IN WORK EQUIPMENT, SWING, AND TRAVEL CIRCUITS 212
TESTING AND ADJUSTING LS DIFFERENTIAL PRESSURE 214
ADJUSTING PC VALVE 215
TESTING AND ADJUSTING HYDRAULIC PRESSURE IN CONTROL PUMP CIRCUIT 216
MEASURING SOLENOID VALVE OUTPUT PRESSURE 217
MEASURING PPC VALVE OUTPUT PRESSURE 219
ADJUSTING PPC VALVE 221
TESTING SWING HOLDING BRAKE INLET PRESSURE 221
TESTING AND ADJUSTING TRAVEL DEVIATION 222
MEASURING OIL LEAKAGE FROM WORK EQUIPMENT CYLINDER 224
BLEEDING AIR FROM EACH PART 226
RELEASING RESIDUAL PRESSURE FROM HYDRAULIC CIRCUIT 228
RELEASING RESIDUAL PRESSURE FROM HYDRAULIC TANK 228
PRESSURIZING HYDRAULIC TANK 228
RESETTING PROCEDURE OF ELECTRIC SYSTEM AND CHECK OF ITS OPERATION 229
PROCEDURE FOR REPLACING POTENTIOMETER 242
PROCEDURE FOR TESTING DIODE 243
TROUBLESHOOTING 244
TROUBLESHOOTING POINTS TO REMEMBER 245
SEQUENCE OF EVENTS IN TROUBLESHOOTING 246
POINTS TO REMEMBER WHEN CARRYING OUT MAINTENANCE 247
CHECKS BEFORE TROUBLESHOOTING 255
CONNECTOR TYPES AND MOUNTING LOCATIONS 256
CONNECTOR ARRANGEMENT DIAGRAM 260
CONNECTION TABLE FOR CONNECTOR PIN NUMBERS 266
T-ADAPTER-BOXES AND T-ADAPTER TABLE 290
EXPLANATIONS OF CONTROL MECHANISM OF ELECTRICAL SYSTEM 293
METHOD OF USING JUDGEMENT TABLE 309
METHOD OF USING TROUBLESHOOTING CHARTS 310
TROUBLESHOOTING OF CONTROLLER AND ELECTRIC SYSTEM(E-MODE) 312
ACTIONS OF SELF-DIAGNOSIS FUNCTION AND PROBLEMS IN MACHINE 313
JUDGMENT TABLE FOR MACHINE CONTROL 319
E-MODE RELATED ELECTRICAL CIRCUIT DIAGRAM 321
PUMP CONTROLLER 322
ENGINE CONTROLLER 323
PRECAUTIONS FOR TROUBLESHOOTING CONTROLLER SYSTEM 325
PRECAUTIONS FOR OPERATING SYSTEM RESET SWITCH WHEN ERROR CODE IS DISPLAYED AND WORK EQUIPMENT STOPS 327
E-1 ERROR CODE [24](TROUBLE IN ENGINE SPEED SENSOR SYSTEM) IS DISPLAYED 328
E-2 ERROR CODE [31](TROUBLE IN BOOM POTENTIOMETER SYSTEM) IS DISLAYED 329
E-3 ERROR CODE [32](TROUBLE IN ARM POTENTIOMETER SYSTEM) IS DISPLAYED 330
E-4 ERROR CODE [34](TROUBLE IN OFFSET POTENTIOMETER SYSTEM) IS DISPLAYED 331
E-5 ERROR CODE [41](TROUBLE IN PPC LOCK SOLENOID SYSTEM) IS DISPLAYED 332
E-6 ERROR CODE [42](TROUBLE IN LEFT OFFSET STOP SOLENOID SYSTEM) IS DISPLAYED 333
E-7 ERROR CODE [48](TROUBLE IN TRAVELING ACCELERATOR SOLENOID SYSTEM) IS DISPLAYED 334
E-8 ERROR CODE [51](TROUBLE IN BOOM RAISE STOP SOLENOID SYSTEM) IS DISPLAYED 335
E-9 ERROR CODE [52](TROUBLE IN ARM IN STOP SOLENOID SYSTEM) IS DISPLAYED 336
E-10 ERROR CODE [54](TROUBLE IN TVC-EPC SOLENOID SYSTEM) IS DISPLAYED 337
E-11 ERROR CODE [62](TROUBLE IN CONTROLLER POWER SOURCE SYSTEM) IS DISPLAYED 338
E-12 ERROR CODE [64](TROUBLE IN SENSOR POWER SOURCE SYSTEM) IS DISPLAYED 339
E-13 ERROR CODE [71](MOTOR DRIVE RELAY(ACCELERATOR) IS DISPLAYED 340
E-14 ERROR CODE [72](MOTOR DRIVE RELAY(DECELERATOR)) IS DISPLAYED 341
E-15 ERROR CODE [74](MOTOR DRIVE RELAY(DECELERATOR)) IS DISPLAYED 342
E-16 ERROR CODE [78](ABNORMALITY IN MOTOR STALL SYSTEM)IS DISPLAYED 343
E-17 ERROR CODE [EE](FAULT IN CONTROLLER) IS DISPLAYED 345
a) WHEN CONTROLLER HAS FAULT IN IT 345
b) WHEN COMMUNICATION SYSTEM BETWEEN CONTROLLER AND MONITOR PANEL IS TROUBLED 346
E-18 DEFECTIVE ENGINE CONTROL SYSTEM 347
a) ENGINE CONTROL SYSTEM DOES NOT OPERATE AT ALL OR IT OPERATES FOR A MOMENT AND DOSE NOT OPERATE ANY MORE 347
b) ENGINE CONTROL SYSTEM DOES NOT OPERATE AT ALL OR IT OPERATES FOR A MOMENT AND DOES NOT OPERATE ANY MORE(ABNORMAL SPEED OR INSUFFICIENT STROKE OF CABLE) 349
c) ONE-TOUCH DECELERATOR DOES NOT OPERATE 350
d) ENGINE CONTROL SYSTEM OPERATES NEAR IDING SPEED BUT DOES NOT OPERATE TO FULL(HIGH-LOAD RANGE) 350
E-19 WHEN STARTING SWITCH IS TURNED TO START POSITION,ENGINE DOES NOT START 351
a) STARTING SYSTEM 351
b) ENGINE STOP SOLENOID SYSTEM 357
E-20 WHEN STARTING SWITCH IS TURNED TO OFF POSITION,ENGINE DOES NOT STOP 359
E-21 WHEN TRAVELING ACCELERATOR PEDAL IS PRESSED,TRAVEL SPEED DOES NOT RISE 361
E-22 WHEN TRAVELING ACCELERATOR PEDAL IS RELEASED,TRAVEL SPEED DOES NOT LOWER FROM RAISED LEVEL 362
E-23 WHEN WORK EQUIPMENT LOCK LEVER IS SET TO FREE POSITION, WORK EQUIPMENT DOES NOT MOVE 363
E-24 AFTER WORK EQUIPMENT LOCK LEVER IS LOCKED, WORK EQUIPMENT STILL MOVES 365
E-25 SYSTEM CANNOT BE INITIALIZED 366
E-26 DEPTH CANNOT BE SET TO 0 OR HEIGHT CANNOT BE SET 368
TROUBLESHOOTING FOR CONTROLLER INPUT SIGNAL SYSTEM(F-MODE) 369
F-1 CONTROLLER DOES NOT DISPLAY [26 (2)] (ONE-TOUCH DECELERATION) 370
F-2 CONTROLLER DOES NOT DISPLAY[26(3)](TRAVELING ACCELERATOR SWITCH) 371
TROUBLESHOOTING FOR HYDRAULIC AND MECHANICAL SYSTEMS(H-MODE) 372
TABLE OF FAILURE MODES AND CAUSES 374
H-1 SPEED OR POWER OF TWO OR MORE OF WORK EQUIPMENT (BOOM,ARM,BUCKET,AND OFFSET),TRAVEL,SWING,AND BLADE SYSTEMS IS LOW 376
a) SPEED OR POWER OF WORK EQUIPMENT (INCLUDING BLADE),TRAVEL,AND SWING SYSTEMS IS LOW 376
b) SPEED OR POWER OF WORK EQUIPMENT(EXCLUDING BLADE),TRAVEL,AND SWING SYSTEMS IS LOW 377
c) SPEED OR POWER OF WORK EQUIPMENT (EXCLUDING BLADE) AND TRAVEL SYSTEM IS LOW 377
d) SPEED OR POWER OF SWING AND BLADE SYSTEM IS LOW 378
e) SPEED OR POWER OF TRAVEL AND BLADE SYSTEMS IS LOW 378
f) SPEED OR POWER OF WORK EQUIPMENT (EXCLUDING BLADE) IS LOW 379
g) SPEED OR POWER OF TRAVEL AND SWING SYSTEMS IS LOW 379
H-2 THERE IS EXCESSIVE DROP IN ENGINE SPEED OR ENGINE STALLS 380
H-3 TWO OR MORE OF WORK EQUIPMENT (BOOM,ARM,BUCKET,AND OFFSET),TRAVEL,SWING,AND BLADE SYSTEMS DO NOT MOVE 382
a) WORK EQUIPMENT(INCLUDING BLADE),TRAVEL,AND SWING SYSTEMS DO NOT MOVE 382
b) WORK EQUIPMENT(EXCLUDING BLADE),TRAVEL,AND SWING SYSTEMS DO NOT MOVE 383
c) WORK EQUIPMENT(EXCLUDING BLADE) AND TRAVEL SYSTEMS DO NOT MOVE 383
d) AWING AND BLADE SYSTEMS DO NOT MOVE 383
e) TRAVEL AND BLADE SYSTEMS DO NOT MOVE 384
f) WORK EQUIPMENT (EXCLUDING BLADE) SYSTEM DOES NOT MOVE 384
H-4 ABNORMAL NOISE GENERATED (FROM AROUND PUMP) 385
H-5 FINE CONTROLLABILITY IS POOR OR RESPONSE IS LOW (TWO OR MORE SYSTEMS HAVE POOR FINE CONTROLLABILITY OR LOW RESPONSE SIMULTANEOUSLY 386
H-6 BOOM SPEED OR POWER IS LOW (OTHER WORK EQUIPMENT IS NORMAL) 387
a) BOOM RAISE SPEED OR POWER IS LOW 387
b) BOOM LOWER SPEED OR POWER IS LOW 388
H-7 ARM SPEED OR POWER IS LOW (OTHER WORK EQUIPMENT IS NORMAL) 389
a) ARM IN SPEED OR POWER IS LOW 389
b) ARM OUT SPEED OR POWER IS LOW 390
H-8 BUCKET SPEED OR POWER IS LOW (OTHER WORK EQUIPMENT IS NORMAL) 391
a) BUCKET CURL SPEED OR POWER IS LOW 391
b) BUCKET DUMP SPEED OR POWER IS LOW 392
H-9 OFFSET BOOM SPEED OR POWER IS LOW (OTHER WORK EQUIPMENT IS NORMAL) 393
a) OFFSET LEFT SPEED OR POWER IS LOW 393
b) OFFSET RIGHT SPEED OR POWER IS LOW 394
H-10 BOOM DOES NOT MOVE 395
a) BOOM DOES NOT RAISE 395
b) BOOM DOES NOT LOWER 396
H-11 ARM DOES NOT MOVE 397
a) ARM DOES NOT MOVE IN 397
b) ARM DOES NOT MOVE OUT 398
H-12 BUCKET DOES NOT MOVE 399
a) BUCKET DOES NOT CURL 399
b) BUCKET DOES NOT DUMP 400
H-13 OFFSET BOOM DOES NOT MOVE 401
a) OFFSET BOOM DOES NOT MOVE TO LEFT 401
b) OFFSET BOOM DOES NOT MOVE TO RIGHT 402
H-14 HYDRAULIC DRIFT OF BOOM IS LARGE 403
H-15 HYDRAULIC DRIFT OF ARM IS LARGE 403
H-16 HYDRAULIC DRIFT OF BUCKET IS LARGE 404
H-17 HYDRAULIC DRIFT OF OFFSET BOOM IS LARGE 404
a) HYDRAULIC DRIFT OF OFFSET BOOM TO LEFT IS LARGE 404
b) HYDRAULIC DRIFT OF OFFSET BOOM TO RIGHT IS LARGE 404
H-18 TIME LAG IS LARGE (ENGINE SPEED IS LOW) 405
H-19 PART LOADED MORE MOVES SLOWER IN COMPOUND OPERATION OF WORK EQUIPMENT 405
H-20 TRAVEL DEVIATION IS LARGE 406
a) TRAVEL DEVIATION IS LARGE DURING ORDINARY TRAVEL 406
b) TRAVEL DEVIATION IS LARGE WHEN MACHINE STARTING (BUT NORMAL DURING ORDINARY TRAVEL) 407
H-21 TRAVEL SPEED OR POWER IS LOW (WORK EQUIPMENT,SWING,AND BLADE OPERATIONS ARE NORMAL) 408
H-22 MACHINE CANNOT BE STEERED SHARPLY OR STEERING FORCE IS INSUFFICIENT 409
H-23 TRAVEL SPEED DOES NOT CHANGE 410
H-24 MACHINE DOES NOT TRAVEL 411
H-25 OVERRUN OF TRAVEL IS LARGE 413
H-26 TRAVEL HYDRAULIC DRIFT IS LARGE 413
H-27 FINE CONTROLLABILITY OR RESPONSE IS LOW 414
H-28 SWING SPEED OR POWER IS LOW (WORK EQUIPMENT,TRAVEL, AND BLADE OPERATIONS ARE NORMAL) 415
a) SWING SPEED OR POWER IS LOW IN BOTH DIRECTIONS 415
b) SWING SPEED OR POWER IS LOW IN EITHER DIRECTION 417
H-29 MACHINE DOES NOT SWING (WORK EQUIPMENT,TRAVEL,AND BLADE OPERATIONS ARE NORMAL) 418
a) MACHINE DOES NOT SWING IN EITHER DIRECTION 418
b) MACHINE DOES NOT SWING IN BOTH DIRECTIONS 420
H-30 SWING ACCELERATION IS LOW 421
a) SWING ACCELERATION IS LOW IN BOTH DIRECTIONS 421
b) SWING ACCELERATION IS LOW IN EITHER DIRECTION 421
H-31 OVERRUN OF SWING IS LARGE 422
a) OVERRUN OF SWING IS LARGE IN BOTH DIRECTIONS 422
b) OVERRUN OF SWING IS LARGE IN EITHER DIRECTION 422
H-32 LARGE SHOCK IS MADE WHEN MACHINE STOPS SWINGING 423
H-33 LARGE ABNORMAL SOUND IS MADE WHEN MACHINE STOPS SWINGING 423
H-34 SWING HYDRAULIC DRIFT IS LARGE 423
H-35 FINE CONTROLLABILITY OR RESPONSE OF SWING IS LOW 424
H-36 BLADE SPEED OR POWER IS LOW (WORK EQUIPMENT, TRAVEL,AND SWING OPERATIONS ARE NORMAL) 425
H-37 BLADE DOES NOT MOVE (WORK EQUIPMENT,TRAVEL,AND SWING OPERATIONS ARE NORMAL) 426
a) BLADE DOES NOT RAISE 426
b) BLADE DOES NOT LOWER 427
H-38 HYDRAULIC DRIFT OF BLADE IS EXCESSIVE 428
H-39 FINE CONTROLLABILITY IS POOR OR RESPONSE OF BLADE IS LOW 428
H-40 MONITOR PANEL DISPLAYS ERROR CODE [61] AND BOOM RAISE,ARM IN, AND LEFT OFFSET OPERATIONS STOP JUST BEFORE INTERFERENCE 429
H-41 MACHINE DOES NOT STOP BOOM RAISE,ARM IN,AND LEFT OFFSET OPERATIONS AUTOMATICALLY BUT INTERFERES 429
TROUBLE SHOOTING FOR MACHINE MONITOR SYSTEM(M-MODE) 430
ELECTRIC CIRCUIT DIAGRAM OF MACHINE MONITOR SYSTEM 431
M-1 WHEN STARTING SWITCH IS TURNED TO THE ON POSITION,NOTHING IS DISPLAYED(SEGMENTS DO NOT LIGHT UP FOR 3 SECONDS) 433
M-2 WHEN STARTING SWITCH IS TURNED TO ON POSITION,ALL SEGMENTS LIGHT UP BUT DO NOT GO OFF AFTER 3 SECONDS 433
M-3 WHEN STARTING SWITCH IS TURNED TO ON POSITION,SOME ITEMS DO NOT LIGHT UP FOR ALL SEGMENT LIGHT-UP PERIOD OF 3 SECONDS 434
a) GAUGES DO NOT LIGHT UP 434
b) ELECTRIC SYSTEM CAUTION LAMP DOES NOT LIGHT UP 434
c) CHARGE LEVEL CAUTION LAMP DOES NOT LIGHT UP 434
d) ENGINE OIL PRESSURE CAUTION LAMP DOES NOT LIGHT UP 434
M-4 WHEN STARTING SWITCH IS TURNED TO ON POSITION (WITH ENGINE STOPPED),CHARGE LEVEL CAUTION LAMP DOES NOT LIGHT UP 435
M-5 WHEN STARTING SWITCH IS TURNED TO ON POSITION (WITH ENGINE STOOPED),ENGINE OIL PRESSURE CAUTION LAMP DOES NOT LIGHT UP 436
M-6 ENGINE PREHEATING PILOT LAMP DOES NOT LIGHT UP WHILE ENGINE IS PREHEATED 437
M-7 ENGINE OIL PRESSURE CAUTION LAMP LIGHTS UP WHILE ENGINE IS RUNNING (ENGINE OIL PRESSURE IS NORMAL) 437
M-8 CHARGE LEVEL CAUTION LAMP LIGHTS UP WHILE ENGINE IS RUNNING 438
M-9 ENGINE WATER TEMPERATURE GAUGE (COOLANT TEMPERATURE GAUGE) INDICATES ABNORMALLY 440
a) AFTER ENGINE IS STARTED,TEMPERATURE DOES NOT RISE AT ALL FROM LOWEST LEVEL 440
b) AFTER ENGINE IS STARTED,TEMPERATURE RISES IMMEDIATELY 441
c) WATER TEMPERATURE GAUGE GOES OFF 441
M-10 FUEL LEVEL GAUGE INDICATES ABNORMALLY 442
a) AL SEGMENTS OF FUEL LEVEL GAUGE GO OFF 442
b) FUEL LEVEL GAUGE KEEPS INDICATING FULL WHILE FUEL IS CONSUMED 442
c) FUEL LEVEL GAUGE DOES NOT INDICATE FULL WHILE FUEL TANK IS FULL 443
M-11 ALARM BUZZER OPERATES ABNORMALLY 444
a) BUZZER DOES NOT SOUND 444
b) BUZZER KEEPS SOUNDING 444
M-12 ALARM BUZZER SOUNDS FOR 7 SECONDS AND ELECTRIC SYSTEM CAUTION LAMP BLINKS WHILE EMERGENCY WORK EQUIPMENT OPERATION SWITCH IS NOT TURNED ON 445
M-13 SERVICE METER DOES NOT OPERATE WHILE ENGINE IS RUNNING 446
a) WHEN CHARGE LEVEL CAUTION LAMP DOES NOT LIGHT UP 446
b) WHEN CHARGE LEVEL CAUTION LAMP LIGHTS UP 446
M-14 LAMPS FOR NIGHT WORK DO NOT LIGHT UP 448
a) LAMP FOR COOLANT TEMPERATURE GAUGE,FUEL LEVEL GAUGE,AND DEPTH INDICATOR DOES NOT LIGHT UP 448
b) LAMP FOR SERVICE METER DOES NOT LIGHT UP 448
M-15 ELECTRIC SYSTEM CAUTION LAMP DOES NOT GO OFF(CONTROLLER DOES NOT DISPLAY ANY ERROR CODE AND OPERATION IS NORMAL) 449
M-16 HEATER DOES NOT OPERATE 450
a) HEATER DOES NOT OPERATE AT BOTH LO AND HI LEVELS 450
b) HEATER DOES NOT OPERATE AT ONLY LO LEVEL 450
c) HEATER DOES NOT OPERATE AT ONLY HI LEVEL 450
M-17 TRAVEL ALARM DOES NOT SOUND OR DOES NOT STOP SOUNDING 452
a) TRAVEL ALARM DOES NOT SOUND 452
b) WHEN MACHINE STOPS,ALARM DOES NOT STOP 452
30 DISASSEMBLY AND ASSEMBLY 454
METHOD OF USING MANUAL 455
PRECAUTIONS WHEN PERFORMING OPERATION 456
SPECIAL TOOL LIST 459
ENGINE AND WORK EQUIPMENT PUMP ASSEMBLY 462
REMOVAL 462
INSTALLATION 467
CENTER SWIVEL JOINT ASSEMBLY 472
REMOVAL 472
INSTALLATION 476
SWING MOTOR AND SWING MACHINERY ASSEMBLY 480
REMOVAL 480
INSTALLATION 481
REMOVAL OF CENTER SWIVEL JOINT ASSEMBLY 482
INSTALLATION OF REVOLVING FRAME ASSEMBLY 486
SWING CIRCLE ASSEMBLY 490
REMOVAL 490
INSTALLATION 490
RUBBER SHOE ASSEMBLY 491
REMOVAL 491
INSTALLATION 491
ROAD LINER IRON SHOE ASSEMBLY 492
REMOVAL 492
INSTALLATION 493
SWING MACHINERY ASSEMBLY 494
DISASSEMBLY 494
ASSEMBLY 497
CENTER SWIVEL JOINT ASSEMBLY 500
DISASSEMBLY 500
ASSEMBLY 501
IDLER CUSHION ASSEMBLY 502
DISASSEMBLY 502
ASSEMBLY 503
INSTALLATION OF IDLER ASSEMBLY 504
INSTALLATION OF TRACK ROLLER ASSEMBLY 506
INSTALLATION OF CARRIER ROLLER ASSEMBLY 507
INSTALLATION OF HYDRAULIC CYLINDER ASSEMBLY 508
ASSEMBLY OF WORK EQUIPMENT VALVE(NOTES) 510
90 OTHERS 513
HYDRAULIC CIRCUIT DIAGRAM 514
HYDRAULIC CIRCUIT DIAGRAM (ADDITIONAL ATTACHMENT CIRCUIT) 515
ELECTRICAL CIRCUIT DIAGRAM (1/2) SERIAL NO :20001-20423 516
ELECTRICAL CIRCUIT DIAGRAM (2/2) SERIAL NO :20001-20423 517
ELECTRICAL CIRCUIT DIAGRAM (1/2) SERIAL NO :20424-22000 518
ELECTRICAL CIRCUIT DIAGRAM (2/2) SERIAL NO :20424-22000 519
ELECTRICAL CIRCUIT DIAGRAM (1/2) SERIAL NO :22001 AND UP 520
ELECTRICAL CIRCUIT DIAGRAM (2/2) SERIAL NO :22001 AND UP 521

DESCRIPTION:

Komatsu PC58UU-3 Hydraulic Excavator Shop Manual SEBM023909  – PDF DOWNLOAD

        MACHINE MODEL SERIAL NUMBER

• PC58UU-3                 20001 and up

GENERAL PRECAUTIONS :
Mistakes in operation are extremely dangerous. Read the Operation and Maintenance Manual carefully BEFORE operating the machine.
1. Before carrying out any greasing or repairs, read all the precautions given on the decals which are fixed to the machine.
2. When carrying out any operation, always wear safety shoes and helmet. Do not wear loose work clothes, or clothes with buttons missing.
• Always wear safety glasses when hitting parts with a hammer.
• Always wear safety glasses when grinding parts with a grinder, etc.
3. If welding repairs are needed, always have a trained, experienced welder carry out the work. When carrying out welding work, always wear welding gloves, apron, hand shield, cap and other clothes suited for welding work.
4. When carrying out any operation with two or more workers, always agree on the operating procedure before starting. Always inform your fellow workers before starting any step of the operation. Before starting work, hang UNDER REPAIR signs on the controls in the operator’s compartment.
5. Keep all tools in good condition and learn the correct way to use them.
6. Decide a place in the repair workshop to keep tools and removed parts. Always keep the tools and parts in their correct places. Always keep the work area clean and make sure that there is no dirt or oil on the floor. Smoke only in the areas provided for smoking. Never smoke while working.
PREPARATIONS FOR WORK
7. Before adding oil or making any repairs, park the machine on hard, level ground, and block the wheels or tracks to prevent the machine from moving.
8. Before starting work, lower blade, ripper, bucket or any other work equipment to the ground. If this is not possible, insert the safety pin or use blocks to prevent the work equipment from falling. In addition, be sure to lock all the control levers and hang warning signs on them.
9. When disassembling or assembling, support the machine with blocks, jacks or stands before starting work.
10. Remove all mud and oil from the steps or other places used to get on and off the machine. Always use the handrails, ladders or steps when getting on or off the machine. Never jump on or off the machine. If it is impossible to use the handrails, ladders or steps, use a stand to provide safe footing.

G.B 20/12/24
