DESCRIPTION:

Komatsu WA320-3 Wheel Loader Shop Manual VEBM450104 – PDF DOWNLOAD

Serial Number WA320H20051 and up

FOREWORD:
GENERAL:

• This shop manual has been prepared as an aid to improve the quality of repairs by giving the service personnel
  an accurate understanding of the product and by showing them the correct way to perform repairs and make
  judgements. Make sure you understand the contents of this manual and use it to full effect at every opportunity.
• This shop manual mainly contains the necessary technical information for operations performed in a service
  workshop. For ease of understanding, the manual is divided into the following chapters; these chapters are
  further divided into the each main group of components.

STRUCTURE AND FUNCTION
This section explains the structure and function of each component. It serves not only to give an
understanding of the structure, but also serves as reference material for troubleshooting.
TESTING AND ADJUSTING
This section explains checks to be made before and after performing repairs, as well as adjustments
to be made at completion of the checks and repairs.
Troubleshooting charts correlating “Problems” to “Causes” are also included in this section.
DISASSEMBLY AND ASSEMBLY
This section explains the order to be followed when removing, installing, disassembling or assembling
each component, as well as precautions to be taken for these operations.
MAINTENANCE STANDARD
This section gives the judgement standards when inspecting disassembled parts.
The specifications contained in this shop manual are subject to change at any time and
without any advance notice. Use the specifications given in the book with the latest
date.
