Kubota L2500F Tractor Illustrated Master Parts Manual – PDF Download

Kubota L2500F Tractor Illustrated Master Parts Manual

LANGUAGE:ENGLISH
PAGES:228
DOWNLOADABLE:YES
FILE TYPE:PDF

KUBOTA L2500F TRACTOR ILLUSTRATED MASTER PARTS MANUAL – PDF DOWNLOAD:

IMAGES PREVIEW OF THE MANUAL:

DESCRIPTION:

• Kubota L2500F Tractor Illustrated Master Parts Manual
• The Parts manual contains all the information you need to properly replace parts on your vehicle. Filled with illustrations and all part numbers. with step-by-step instruction & highly detailed exploded pictures & diagrams to show you how to complete the required job correctly & efficiently.
• Detailed illustrations, exploded diagrams, drawings and photos guide you through every service repair procedure. This manual can be viewed on any computer, as well as zoomed and printed. Complete download comes in PDF format which will work in Android, IOS and all PC based operating systems. The manual gets saved in your hard-drive. So it is there forever, for you to refer to it whenever you so desire.
• INSTANT DOWNLOAD MEANS THERE IS NO SHIPPING COST or WAITING FOR A CD or PAPER MANUAL TO ARRIVE IN THE MAIL. YOU WILL RECEIVE THIS MANUAL TODAY VIA INSTANT DOWNLOAD ON COMPLETION OF PAYMENT VIA OUR SECURE PAYMENT PROCESSOR.

TABLE OF CONTENTS:

Kubota L2500F Tractor Illustrated Master Parts Manual

Instructions for Parts Books..........................  1
L2500F................................................  2
CRANKCASE.............................................  6
OIL PAN...............................................  8
PISTON/CRANKSHAFT..................................... 10
MAIN BEARING CASE..................................... 12
FLYWHEEL.............................................. 14
CYLINDER HEAD......................................... 16
VALVE AND ROCKER ARM.................................. 18
NOZZLE HOLDER/GLOW PLUG............................... 20
NOZZLE HOLDER [COMPONENT PARTS]....................... 22
CYLINDER HEAD COVER................................... 25
INLET MANIFOLD........................................ 27
AIR CLEANER........................................... 29
EXHAUST MANIFOLD...................................... 31
MUFFLER............................................... 33
UNDER MUFFLER [OPTION]................................ 35
CAMSHAFT.............................................. 37
GEAR CASE............................................. 39
WATER PUMP............................................ 41
WATER FLANGE AND THERMOSTAT........................... 43
FUEL CAMSHAFT......................................... 45
INJECTION PUMP........................................ 47
INJECTION PUMP [COMPONENT PARTS]...................... 49
ENGINE STOP LEVER..................................... 51
SPEED CONTROL PLATE................................... 53
GOVERNOR.............................................. 55
UPPER GASKET KIT...................................... 57
LOWER GASKET KIT...................................... 59
STOP ROD.............................................. 61
HAND ACCELERATOR LEVER................................ 63
FUEL TANK............................................. 65
FUEL FILTER/FUEL PIPE................................. 67
FAN................................................... 69
WATER PIPE............................................ 71
RADIATOR.............................................. 73
SHUTTER [MANUAL STRG.]................................ 75
ALTERNATOR............................................ 77
ALTERNATOR [COMPONENT PARTS].......................... 79
STARTER............................................... 81
STARTER [COMPONENT PARTS]............................. 83
BATTERY............................................... 85
SWITCH................................................ 87
LIGHT................................................. 89
METER................................................. 91
ELECTRICAL WIRING..................................... 93
CLUTCH................................................ 95
CLUTCH LEVER.......................................... 97
CLUTCH PEDAL.......................................... 99
CLUTCH HOUSING........................................101
TRANSMISSION CASE.....................................103
MAIN SHAFT............................................105
COUNTERSHAFT..........................................107
PTO COUNTERSHAFT......................................109
REVERSE SHAFT.........................................111
MAIN GEAR SHIFT LEVER.................................113
PTO GEAR SHIFT LEVER..................................115
MAIN GEAR SHIFT FORK..................................117
PTO GEAR SHIFT FORK...................................119
RANGE GEAR SHIFT FORK AND LEVER.......................121
SPIRAL BEVEL PINION...................................124
REAR DIFFERENTIAL.....................................126
DIFFERENTIAL LOCK PEDAL...............................128
REAR AXLE.............................................130
REAR WHEEL (9.5-24)...................................132
REAR WHEEL (11.2-24)..................................134
REAR WHEEL (13.6-16)..................................136
REAR WHEEL (355/80-D20)...............................138
BRAKE.................................................140
BRAKE PEDAL...........................................142
PARKING BRAKE LEVER...................................144
FRONT AXLE............................................146
KNUCKLE SHAFT.........................................148
FRONT WHEEL (4.00-15).................................150
FRONT WHEEL (5.00-15).................................152
FRONT WHEEL (23X8.50-12)..............................154
FRONT WHEEL (25X8.50-14)..............................156
FRONT AXLE FRAME......................................158
STEERING LINKAGE (DRAG LINK)..........................160
STEERING LINKAGE (TIE ROD)............................162
MANUAL STEERING AND HANDLE (MS).......................164
MANUAL STEERING [COMPONENT PARTS].....................166
HYDRAULIC PUMP........................................168
HYDRAULIC PUMP [COMPONENT PARTS]......................170
HYDRAULIC OIL LINE....................................172
CONTROL VALVE.........................................174
CONTROL VALVE (POSITION CONTROL) [COMPONENT PARTS]....176
CONTROL VALVE (DRAFT) [OPTION] [COMPONENT PARTS]......178
DRAFT CONTROL VALVE [OPTION]..........................180
DRAFT CONTROL VALVE [OPTION] [COMPONENT PARTS]........182
HYDRAULIC CYLINDER....................................184
CYLINDER FRONT COVER..................................186
LIFT ARM..............................................188
FEED BACK LEVER.......................................190
POSITION CONTROL LEVER................................192
3-POINT LINKAGE 1 (LOWER LINK/TOP LINK)...............194
3-POINT LINKAGE 2 (LIFT ROD)..........................196
TOP LINK BRACKET/LOWER LINK HOLDER....................198
TOP LINK BRACKET (WITH DRAFT CONTROL) [OPTION]........200
DRAWBAR/HITCH.........................................202
PTO SHAFT PROTECTOR...................................204
FRONT GRILLE..........................................206
HOOD (BONNET).........................................208
HOOD (SIDE COVER).....................................210
REAR HOOD (BONNET)....................................212
FENDER................................................214
FENDER SUPPORT........................................216
SEAT..................................................218
STEP..................................................220
ROPS..................................................222
LABEL 1...............................................224
LABEL 2...............................................226
ACCESSORIES AND SERVICE PARTS.........................228
