KYMCO XCITING 500 SERVICE MANUAL – PDF DOWNLOAD

Description

KYMCO XCITING 500 SERVICE MANUAL

FILE DETAILS:

LANGUAGE:ENGLISH
PAGES:349
DOWNLOADABLE:YES
FILE TYPE:PDF

KYMCO XCITING 500 SERVICE MANUAL – PDF DOWNLOAD:

IMAGES PREVIEW OF THE MANUAL:

DESCRIPTION:

KYMCO XCITING 500 SERVICE MANUAL

PREFACE :

This Service Manual describes the technical features and servicing procedures for the KYMCO XCITING 500. Section 1 contains the precautions for all operations stated in this manual. Read them carefully before any operation is started. Section 2 is the removal/installation procedures for the frame covers which are subject to higher removal/installation frequency during maintenance and servicing operations. Section 3 describes the inspection/ adjustment procedures, safety rules and service information for each part, starting from periodic maintenance. Sections 7 through 13 give instructions for disassembly, assembly and adjustment of engine parts. Section 14 through 16 is the removal/ installation of chassis. Section 17 through 21 states the testing and measuring methods of electrical equipment. Most sections start with an assembly or system illustration and troubleshooting for the section. The subsequent pages give detailed procedures for the section.

TABLE OF CONTENTS:

KYMCO XCITING 500 SERVICE MANUAL

GENERAL INFORMATION 1
FRAME COVERS /EXHAUST MUFFLER 2
INSPECTION/ADJUSTMENT 3
LUBRICATION SYSTEM 4
FUEL SYSTEM/FUEL PUMP/FUEL
TANK/CARBURETOR 5
COOLING SYSTEM 6
ENGINE REMOVAL/INSTALLATION 7
CYLINDER HEAD/VALVES 8
CYLINDER/PISTON 9
DRIVE AND DRIVEN PULLEY 10
FINAL REDUCTION 11
A.C. GENEARTOR/STARTER CLUTCH 12
CRANKCASE/CRANKSHAFT 13
STEERING HANDLEBAR/FRONT
WHEEL/FRONT SHOCK ABSORBER 14
REAR FORK/REAR WHEEL/REAR
SHOCK ABSORBER` 15
BRAKE SYSTEM 16
BATTERY/CHARGING SYSTEM 17
IGNITION SYSTEM 18
ELECTRIC STARTER 19
LIGHTS/METERS/SWITCHES 20
WIRING DIAGRAMS
