Liebherr R 952 Litronic Excavator Operation & Maintenance Manual – PDF DOWNLOAD

Description

Liebherr R 952 Litronic Excavator Operation & Maintenance Manual – PDF DOWNLOAD

FILE DETAILS:

Liebherr R 952 Litronic Excavator Operation & Maintenance Manual – PDF DOWNLOAD

Language : English
Pages : 89
Downloadable : Yes
File Type : PDF

DESCRIPTION:

Liebherr R 952 Litronic Excavator Operation & Maintenance Manual – PDF DOWNLOAD

FOREWORD:

This manual is primarily for the operator and the maintenance crew and contains information which is vital to the correct and secure operation and proper maintenance of the LIEBHERR R 952 Litronic excavator.

It includes:
Accident Prevention Guidelines
Operating Instructions
Maintenance Instructions.

This manual should be given to the OPERA TOR, who should read it carefully before operating the LIEBHERR R 952 Litronic excavator and at regular intervals thereafter .

• If you follow these instructions, your LIEBHERR R 952 Litronic excavator will give you constant and reliable service with excellent performance, reducing repair costs and down time.
• The Operation and Maintenance Manual is part of the machine and should be left in the operator’s cab.
• Please take notice that we cannot honor any claims which could arise due to careless handling, improper operation, or inadequate maintenance, use of unauthorized oils or lubricants, etc.
• LIEBHERR reserves the right to cancel any warranty claims, service contracts etc. wit hout prior notice if any other than Original LIEBHERR parts or parts sold by LIEBHERR are being used for maintenance and repairs.

TABLE OF CONTENTS:

Liebherr R 952 Litronic Excavator Operation & Maintenance Manual – PDF DOWNLOAD

Foreword 01
Index 03
The operation and maintenance manual 05
1/ MACHINE DESCRIPTION, TECHNICAL DATA
Machine description, technical data11
Digging envelope for backhoe attachment14
Digging envelope for bottom dump bucket 17
Lift capacities 18
Dimensions and weights116
2/ SAFETY INFORMATION
General safety information 21
Crushing and burn prevention 22
Fire and explosion prevention 23
Machine start up safety 23
Engine start up and operating safety 24
Machine operating safety24
Machine parking safety __ 25
Maintenance safety guidelines_ 25
3/ CONTROLS AND INSTRUMENTATION
The operator’s seat3 1
Controls and instrumentation in the cab _ _ __ __ 32
Control and instrument panel_34
4/ OPERATING YOUR EXCAVATOR
Pre starting inspection41
Machine start up safety 43
Diesel engine operation 44
Stopping the engineengine emergency shut-down _ _46
Machine operating safety_ _ _ _ 47
Travel functions _ 48
Joystick operation• 410
Control of the swing 4 10
Attachment control 4 11
Heater and air conditioner 414
03
5/ LUBRICATION
General safety information 51
Lubricant and fuel chart 52
Lubricant and fuel specifications54
Lubrication chart 56
Diesel engine 57
Changing the oil in the splitterbox 58
Changing the oil in the travel gear 59
Changing the oil in the swing gear 59
Oil in the hydraulic system510
Swing ring lubrication 511
Lubrication of attachment bearing pointss 12
Centralized lubricating system (Optional equipment) 513
6/ MAINTENANCE
Safety guidelines for maintenance 61
The diesel engine 62
The swing and travel brakes 63
The air system 64
The track components66
The hydraulic system 68
The air filter614
The electrical system 616
Replacing wear and tear items, welding 618
Maintenance schedule 619
04
