Liebherr Telescopic handler T 33-10 4F Operator’s manual – PDF DOWNLOAD

Description

Liebherr Telescopic handler T 33-10 4F Operator’s manual – PDF DOWNLOAD

FILE DETAILS:

Liebherr Telescopic handler T 33-10 4F Operator’s manual – PDF DOWNLOAD

Language : English
Pages :442
Downloadable : Yes
File Type : PDF
Size:94.0 MB

DESCRIPTION:

Liebherr Telescopic handler T 33-10 4F Operator’s manual – PDF DOWNLOAD

Product ID:
Manufacturer: Liebherr-Werk Telfs GmbH
Type: T 33-10 4F
Type no.:1695
From Serial no: 15752

Foreword

This operator’s manual has been written for the operator and for the maintenance staff of the machine. It contains the descriptions for:

• Chapter 1 “Product description”
• Chapter 2 “Safety guidelines”
• Chapter 3 “Control, operation”
• Chapter 4 “Malfunctions”
• Chapter 5 “Maintenance”

The operating instructions must be read and used carefully by all persons who carry out work with or on the machine before putting the machine into service for the first time and later, at regular intervals. Work with or on the machine includes, for example:

• Operation including set up, troubleshooting during work procedure, disposal of production wastes, care, disposal of service and auxiliary materials.
• Service including maintenance, inspection, and repair work
• Transport or loading the machine

This allows the machine operator to familiarize himself with the machine more easily and prevent malfunctions due to improper operation. Observation of the operating instructions by maintenance personnel:

• increases reliability in use
• extends the service life of your machine
• reduces repair costs and downtime

The operating instructions belong with the machine. Make sure that a copy is always readily available in the operator’s cab.

The operating instructions should be supplemented with instructions for accident prevention and environmental protection based on existing national regulations. In addition to the operating instructions and legally binding regulations on accident prevention which apply in the user country and at point of use, authorized specialist rules for safe and correct working procedures are also to be observed.

These operating instructions contain all required information for control, operation, and maintenance of your machine. Some illustrations in these operating instructions may depict details and working devices which differ from your machine. In some illustrations, protective devices and covers have been removed in the interests of better presentation. Improvements, which are always being incorporated into our machines, may result in changes to your machine which are not yet indicated in these operating instructions. If you need additional explanations or instructions, please don’t hesitate to contact the Technical Documentation and Service Department.

Under extreme conditions, more frequent maintenance than specified in the inspection checklist may be required.
