Liebherr TUNNEL EXCAVATOR R 900 HDS Litronic Operation and Maintenance Manual SN3015 – 8558 – PDF DOWNLOAD

Description

Liebherr TUNNEL EXCAVATOR R 900 HDS Litronic Operation and Maintenance Manual SN3015 – 8558 – PDF DOWNLOAD

FILE DETAILS:

Liebherr TUNNEL EXCAVATOR R 900 HDS Litronic Operation and Maintenance Manual SN3015 – 8558 – PDF DOWNLOAD

Language : English
Pages :116
Downloadable : Yes
File Type : PDF
Size:23.0 MB

DESCRIPTION:

Liebherr TUNNEL EXCAVATOR R 900 HDS Litronic Operation and Maintenance Manual SN3015 – 8558 – PDF DOWNLOAD

FOREWORD

This manual is primarily for the operator and the maintenance crew and contains information that is vital to the correct and secure operation and proper maintenance of the LIEBHERR excavator. It includes:

• Accident Prevention Guidelines
• Operating Instructions
• Maintenance Instructions.

This Operation and Maintenance manual should be given to the OPERATOR and any other person who might work on the machine. It is very important that they read the manual carefully before operating or working on the LIEBHERR excavator and at regular intervals thereafter, for example:

• Operation, including installing and removing attachments, troubleshooting during operation, removing production residue, care, disposing of operating and auxiliary fluids.
• Maintenance work (maintenance, inspection, repair).
• Transportation.

The manual will make it easier for the operator to get accustomed to the hydraulic excavator and to prevent any problems due to improper handling. All maintenance personnel should follow the operating and maintenance instructions, and your LIEBHERR excavator will provide constant and reliable service with excellent performance, reducing repair costs and downtime.

• In addition to the operating and maintenance guidelines in this manual, additional local and national accident prevention guidelines and environmental regulations might be applicable and must be observed.
• The Operation and Maintenance Manual is part of the machine and should be left in the glove compartment of the operator’s cab. Please take notice that we cannot honor any claims that could arise due to careless handling, improper operation, inadequate maintenance, use of unauthorized oils or lubricants, non-observance of the safety instructions, etc.
• LIEBHERR reserves the right to cancel any warranty claims, service contracts, etc., without prior notice if any other than Original LIEBHERR parts or parts sold by LIEBHERR are being used for maintenance and repairs.
• This Operation and Maintenance manual contains all necessary information to operate and maintain your Litronic excavator. However, should you need additional information or explanations, please contact LIEBHERR’s Technical Documentation, Service School, or Customer Service Department.

TABLE OF CONTENTS:

Liebherr TUNNEL EXCAVATOR R 900 HDS Litronic Operation and Maintenance Manual SN3015 – 8558 – PDF DOWNLOAD

Foreword 0 1
Index 0 3
Notes regarding Operation and Maintenance Manual 0 5
Data tag locations 0 7
1/ MACHINE DESCRIPTION, TECHNICAL DATA
(See enclosed brochures)
2/ SAFETY INFORMATION
General Safety Information 2 1
Crushing and Burn Prevention 2 3
Fire and Explosion Prevention 2 3
Machine Start Up Safety 2 3
Engine Start up and Operating Safety 2 4
Machine Operating Safety • 2 4
Machine Parking Safety 2 5
Machine Transporting Safety 2 5
Machine Towing Safety 2 6
Machine Maintenance Safety- Hydraulic hoses and lines 2 8
3/ CONTROLS AND INSTRUMENTATION
Operator’s Seat 3 1
Control and Instrument Panel in the Cab 3 2
Safety lever/ Servo control 3 3
Control and Instrument Panel in the Cab 3 4
Functions of Gauges and Indicator Lights 3 6
Entering and leaving the cab, cab door lock, front window 3 11
Electric windshield washer system 3 12
Heater or air conditioner 3 13
4/ CONTROL AND OPERATION
Pre-Starting Inspection 4 1
Machine Start Up Safety 4 3
Starting the Diesel Engine 4 4
After the Engine is Running 4 5
Stopping the Engine 4 6
External Starting Procedure 4 6
Machine Operating Safety 4 7
Travel Functions 4 8
Fast speed (Rapid Gear) 4 9
Travel Brake 4 9
Joysticks 4 11
Swing Brake 4 12
Uppercarriage lock 4 13
0 3
Operation of attachments 4 13
Stick Cylinder 4 13
Boom Cylinder 4 14
Bucket or Grapple Cylinder 4 14
Reduced Output Control 4 15
Towing the Excavator 4 16
Machine Transporting Safety 4 17
Transporting the Excavator 4 18
Safety Guidelines for loading the Machine with a Crane 4 19
Removal and installation of Attachments 4 21
Backhoe, ditch cleaning bucket , ripper 4 22
Grapple on stick 4 24
Stick to boom 4 26
5/ LUBRICANTS AND SERVICE FLUIDS
General 5 1
Lubricants, Fuel and Oil Specification Chart 5 2
Lubricants, Fuel and Oil Specifications 5 4
Lubrication Chart 5 9
The Diesel Engine 5 11
Changing the Oil in the Swing Gear 5 11
Travel Gear Oil Change 5 12
Oil in the Hydraulic System 5 13
Swing Ring Lubrication 5 15
Lubricating the Attachment Bearing Points 5 15
Grapple Lubrication 5 16
6/ MAINTENANCE
Machine Maintenance Safety 6 1
The Fuel System 6 4
The Diesel Engine 6 5
The Swing and Travel Brakes 6 5
The Track Components 6 6
The Hydraulic System 6 8
The Dry Air Filter 6 12
The Electrical System 6 14
Fuses 6 15
Location of Fuses 6 16
Replace the Bucket Teeth 6 18
Replacing Wear and Tear Items 6 19
Welding 6 19
Maintenance Chart 6 20
7/ SPECIAL INSTALLATIONS
INDEX 7 1
