Massey Ferguson EU Hay Equipment 1316S Rotary Disc Mower Conditioner Operator’s Manual

Description

Massey Ferguson EU Hay Equipment 1316S Rotary Disc Mower Conditioner Operator’s Manual – PDF DOWNLOAD

DESCRIPTION:

Massey Ferguson EU Hay Equipment 1316S Rotary Disc Mower Conditioner Operator’s Manual – PDF DOWNLOAD

A word to the operator :

• It is your responsibility to read and understand the safety section in this manual and the manual for all implements before you operate this machine. You are responsible for your safety. Good safety procedures prevent injury to you and the persons around you. Make the information in the safety section of this manual a part of your safety procedure. This safety section is written only for this type of machine.
• Safety is your responsibility. You can prevent injury and death. This safety section gives basic safety examples that can occur during the operation and maintenance of your machine. This safety section is not a replacement for safety instruction in other sections of this manual. Injury or death can occur if the safety instruction is not obeyed.
• Learn how to operate the machine and how to use the controls correctly. Do not operate the machine if you do not know how to operate the machine. Do not let persons operate the machine that do not know how to operate the machine. Follow all safety instructions in the manuals and on the safety signs on the machine, the implements, and the attachments. Use only approved attachments and implements. Make sure that your machine has the correct equipment that is necessary by the local regulations.

This manual :

This manual covers general safety practices for this machine. The operator manual must always be kept with the machine. Right-hand and left-hand, as used in this manual, are determined by facing the direction the machine will travel when in use. The photos, illustrations, and data used in this manual were current at the time of printing, but due to possible in-line production changes, your machine can vary slightly in detail. The manufacturer reserves the right to redesign and change the machine as necessary without notification.

Prepare for operation :

• Read and understand all operation instructions and precautions in this manual before you operate the machine or do the servicing. Make sure that you know and understand the positions and operations of all controls. Make sure that all controls are in neutral and that the parking brake is applied before you start the machine.
• Make sure that all persons are away from your area of work before you start and operate the machine. Examine and learn the controls in an area that is clear of persons and obstacles before you start work. Know the machine dimensions and make sure that you have sufficient space available to operate the machine.
• Do not operate the machine at high speeds in crowded areas. It is important to know and use the correct procedures when you do work around and operate the machine. Do not let children or unqualified persons operate the machine. Keep others , especially children, away from your area of work.
• Do not let others ride on the machine. Make sure that the machine is in good condition for operation. Refer to the operator manual. Make sure that the machine has the correct equipment required by local regulations. All equipment has a limit. Make sure you understand the speed, brakes , steering, stability and load characteristics of this machine and the tractor before you start.
