Massey Ferguson EU Hay Equipment 1359 Operator Instruction Manual – PDF DOWNLOAD
Original price was: $53.95.$28.95Current price is: $28.95.
Massey Ferguson EU Hay Equipment 1359 Operator Instruction Manual – PDF DOWNLOAD
Part. no : 700726920 A Rev
Description
Massey Ferguson EU Hay Equipment 1359 Operator Instruction Manual – PDF DOWNLOAD
DESCRIPTION:
Massey Ferguson EU Hay Equipment 1359 Operator Instruction Manual – PDF DOWNLOAD
Part. no : 700726920 A Rev
TO OUR CUSTOMER:
- We believe you have exercised excellent judgment in the purchase of your Massey Ferguson® machine. We are most appreciative of your patronage. Your Dealer has performed the pre-delivery service on your new machine. He will discuss with you the operating and maintenance instructions given in this manual, and instruct you in the proper and varied applications of this machine.
- Call on him at any time when you have a question or need equipment related to the use of your machine. We recommend that you carefully read this entire manual before operating the unit. Also, time spent in becoming fully acquainted with it’s performance features, adjustments, and maintenance schedules will be repaid in a Jong and satisfactory life of the product. This equipment is covered by a written warranty which will be provided to you by your Massey Ferguson® Dealer at time of purchase.
- Good safety practices not only protect you, but also the people around you. Study the features in this book and make them a working part of your safety program. Keep in mind that this safety section is written only for this type of machine. Practice all other usual and customary safe working precautions, and above all REMEMBER – SAFETY IS YOUR RESPONSIBILITY.
- YOU CAN PREVENT SERIOUS INJURY OR DEATH. This safety section is intended to point out some of the basic safety situations that may be encountered during the normal operation and maintenance of your machine, and to suggest possible ways of dealing with these FIG. 3 situations. This section is NOT a replacement for other safety practices featured in other sections of this book.
Massey Ferguson EU Hay Equipment 1359 Operator Instruction Manual – PDF DOWNLOAD
SAFETY 1
Safety Alert Symbol 1
Safety Messages 1
Informational Messages 1
Safety Signs 1
Operator’s Manual 2
A Word To The Operator 2
Prepare For Operation 2
Operation 3
Travel On Public Roads 4
Tire Safety 5
Fire Prevention 5
Maintenance 6
Lift Cylinder Locks 8
Tongue Lock 9
Safety Sign Location 1 O
GENERAL INFORMATION 13
Introduction 13
Replacement Parts 13
Units Of Measurement 13
Replacement Parts 13
Machine Identification 14
Component Location 15
Drive line Clutches 15
Overrunning Clutch 15
Slip Clutch 15
OPERATION 17
Connection to the Tractor 17
Disconnecting the Tractor 18
Transporting 19
Pre-Operation Checklist 20
Tongue Position 21
Header Height Position 21
Opening the Conditioning Rolls 21
ADJUSTMENTS 23
Hitch 23
Swath Width 23
Cutting Height 24
Crop Deflector Curtain 24
Header Flotation 25
Stripper Clearance 26
Conditioner Roll Gap 26
Conditioner Roll Timing 27
Conditioner Roll Spring Tension 27
LUBRICATION AND MAINTENANCE 29
Lubrication Chart 29
700726920 A Rev
CONTENTS
Lubrication Details 30
Grease Fittings 30
Gearbox 32
Wheel Bearings 32
Disc Drive Units 33
Bolt Torque Values 34
Standard Bolt Torque Chart 34
Metric Bolt Torque Chart 34
Bearing Replacement (Eccentric Self-Locking Collar) 35
Cutterbar Inspection 36
Knives 36
Knife Removal and Installation 36
Knife Edge Reversing 37
Knife Replacement 37
Cutterbar 38
Description 38
Components 38
Disassembly 39
Drive Shafts 39
Assembly 39
Checking Disc Timing 40
Changing Disc Timing 42
TROUBLESHOOTING 43
SPECIFICATIONS 47
Dimensions And Weights 47
Cutterbar 4 7
Conditioning Rolls 47
Drive 47
Tires 47
Tractor Requirements 48
Lubrication 48
ACCESSORIES AND OPTIONS 49
Topping Skid Shoes 49
18 Degree Knives 49
Lighting Package 49
ASSEMBLY 51
Shipping Damage and Missing Parts 51
Bolt Torque Values 51
Preparation 51
Assembly Procedure 52
Lowering Machine 52
Tongue Installation 53
Steering Cylinder 54
Lift Cylinder Hose Connection 54
Transport Lock 54
Jack 55
Hitch Clevis & Transport Chain 55
IDL (Implement Drive Line) 55
Crop Deflector Curtain 56
Inner Curtain 57
SMV Sign 57
Header Shipping Straps 57
Lift Cylinder Lock Operation 57
Arrival Condition and Predelivery Checklist 59
Delivery Checklist 61
INDEX 63
