MODEL 187LS Large Rectangular Saler
DIMENSIONS AND WEIGHTS
Length
without baie chute 7239 mm
with roller baie chute
operating position, maximum 9093 mm
storage and roading position 7544 mm
Height
top of knotter shielding 27 43 mm
top of hand railing 3556 mm
Width ( overall)
shipping, less tires 2667 mm
operating 2972 mm
Weight (approx )
Single Axle
baler 7980 kg
tongue (empty) 1338 kg
Tandem Axle
baler 8741 kg
tongue ( empty) 1356 kg
Tandem Axle with cutter
baler 9084 kg
tongue (empty) 1814 kg
TIRES
Saler – single axle early production
tire size 700/50-22 5, 12 ply
wheel nut size 3/4-16 UNF-2S
torque 270 to 290 N•m
tire pressure 1 8 bar
Saler – single axle late production
tire size 700/50-22 5, 12 ply
wheel nut size M22 x 1,5
torque 475 N•m
tire pressure 1 8 bar
Saler – tandem axle
tire size 500/50-17, 14 PR
wheel nut size M18 x 1,5
torque 270 N-m
tire pressure 2 5 bar
IMPORTANT: The maximum Joad of the baler when
roading at 65 kph must be no more than 2500 kg per
tire Make sure the baler is emptv
2
BRAKING SYSTEM
Service Tractor activated hydraulic
Parking Manual contrai, mechanical activated
Drum size
single axle early production 400 x 80 mm
single axle late production 406 x 120 mm
tandem axle 300 x 135 mm
TRACTOR REQUIREMENTS
Horsepower
minimum 90 kw

Model . .. .. .. 185SII Mid Size (3×3) Rectangular Saler
DIMENSIONS AND WEIGHTS
Length

without baie chute 7265 mm
with baie chute 9009 mm
with roller baie chute
operating position, maximum 9070 mm
storage and roading position 7544 mm
Height
top of knotter shielding 2731 mm
top of hand railing 3162 mm
Width ( overal?
shipping, less tires 2270 mm
operating 2540 mm
Weight (approx )
Single Axle
baler 5942 kg
tangue (empty) 930 kg
Tandem Axle
baler 6827 kg
tangue (empty) 2250 lg
TIRES
Saler-single axle
standard tire 600 x 50 x 22,5, 12 ply
wheel nut size 18 mm
torque 270 to 290 N-m
tire pressure 2 6 bar
NOTE: If the baler wi/1 be operated on a 15 percent or
greater slope, tubes must be installed in the tires
Saler – tandem axle
tire size 500/50-17, 14 PR
wheel nut size M18 x 1,5
torque 270 N •m
tire pressure 2 5 bar
IMPORTANT: The maximum /oad of the tandem
equipped baler when roading at 65 kph must be no
more than 2500 kg per tire Make sure the baler is
emptv
SPECIFICATIONS
BRAKING SYSTEM
Service tractor actuated hydraulic
Parking manual contrai, mechanical actuated
Drum Size
single axle 400 x 80 mm
tandem axle 300 x 100 mm
TRACTOR REQUIREMENTS
Horsepower
minimum 67 kw
